BELL SYSTEM PRACTICES
AT&TCo Standard
500E/F, 500H, 500L/M, 500P, 500R/S, 500U, 500W, 500Y, 500AD,
GENERAL
1.
1 .01
This section provides identification, installation,
maintenance, and connection information for
special purpose 500-type telephone sets.
This section is reissued to:
1.02
.•
Add C4B ringer and 516B telephone set.
Add Tables Band G.
Show G3AR handset and 241A amplifier MD
and replaced by G3A4 handset and 241B
amplifier, respectively.
Reference Section 502-500-110 for common
installation and maintenance information (3.01
and 4.01).
Add note t o Tables E and I regarding
inductive noise.
Revise connection diagrams and tables.
Show housing assembly P-87C100 (514B set)
replaced by housing assembly 840205-.
Show 500E/F, 50PL/M, and 501F telephone
sets MD.
Changes or additions in the body of tables are
indicated by shaded areas.
Code numbers such as 500E/F cover both
1.03
manual and dial versions, respectively, of
the same type telephone set to permit converting
to either type· without changing the code number
stamped on the base.
the code number of some sets at one time to
indicate the set was equipped with a retractile
handset cord.
