Bogen CA10A Specifications

Call-In Switches
CA10A, CA11A, CA15C,
CA17, CA19, & CA21B
The Bogen CA-Series Call-In Switches are attractive, functional units for call-in from classrooms or other staff
Description
locations to Bogen's PI35A and SI35A Intercom Systems, Multi-Graphic
Institutional/School Communication Systems, and Multicom 2000
Features All Models
• Flush or surface mounted in standard single-gang
outlet boxes
• Heavy-duty long-life switches
• Color-coded connecting leads
• Brushed aluminum faceplate
• Mounting screws included
CA10A and CA11A
• Designed for use with the PI35A, SI35A and Multi-
Graphic Series 115B/2223/2233 systems
• SCR holding circuits actuate the annunciator signal
and LEDs in Bogen's SBA-Series room selector
panels
• Provide momentary press-to-call
CA11A
• Offers a fixed privacy position to prevent unau-
thorized monitoring of the staff station from the
control center
• Privacy mode does not interfere with program or
intercom transmissions to the staff station (priva-
cy cannot be used with 2-wire call-in)
CA15C
• Designed for use with Multicom 2000 system staff
stations
• Provides momentary press-to-call functioning
• Can be used to initiate both "normal calls" and
"emergency calls"
Models
© Series 115B, 2223, and 2233
®
Administrative Communication Systems.
CA17
• Designed for annunciator call-in for PI35A, SI35A,
and Multi-Graphic systems that are equipped with
the SCR25A module
• Momentary push-button switch (does not incor-
porate SCR circuitry)
CA19
• Designed for use in Multicom 2000 systems (does
not incorporate SCR circuitry)
• Provides press-to-call function at enhanced staff
stations that are equipped with the MCESS or
MCWESS telephone sets
• Contact Bogen's
Department for CA19 supportive software
CA21B
• Designed for use in Multicom 2000 systems (no
SCR circuitry)
• Provides a press-to-call position and has a fixed
privacy position to prevent monitoring
• Can be used to initiate both "normal calls" and
"emergency calls"
Specifications subject to change without notice.
© 2003 Bogen Communications, Inc.
Part No. 54-7858-02B Printed in U.S.A. 0312
Application Engineering
