SPECIFICATIONS

Dimensions

Width
Model (A)
14-5/8"
ITQ-875-1C
(370 mm)
17-5/8"
ITQ-1000-1C
(448 mm)
20"
ITQ-1750-2C
(508 mm)
C
Depth Height
(B) (C)
28-11/16" 16-9/16"
(728 mm) (420 mm)
28-5/8" 18"
(727 mm) (457 mm)
28-11/16" 16-9/16"
(728 mm) (420 mm)
A
H
Specification
D
Front View
Footprint Footprint
Width (D) Depth (E)
9-1/4" 17-3/4"
(235 mm) (450 mm)
13-3/4" 17-3/4"
(349 mm) (450 mm)
16-1/4" 17-3/4"
(412 mm) (450 mm)
Label
Side View
Top View
6
Platform Conveyor
Width (F) Width (G)
9-1/4" 5-5/8"
(235 mm) (143 mm)
13-3/4" 9-7/16"
(349 mm) (240 mm)
16-1/8" 5-5/8"
(410 mm) (143 mm)
B
E
G F
Model ITQ-1000-1C shown.
Form No. ITQM-0317
English
Opening
Height (H)
2-3/16"
(56 mm)
2"
(51 mm)
2-3/16"
(56 mm)
