ORIGINAL INSTRUCTIONS
OPERATOR'S MANUAL
Workmaster
Tier 4B (final)
Compact Tractor
Part number 90441870
2
edition English
nd
December 2020
Replaces part number 51414247
25
™

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Workmaster 25 Tier 4B and is the answer not in the manual?

Questions and answers

Ralph Edward Johnson
May 13, 2025

how to open hood ??????????

0
1 comments:
Mr. Anderson
May 21, 2025

To open the hood of a New Holland Workmaster 25 Tier 4B:

1. Move the latch release lever forward.
2. Lift the hood to its fully raised position. A gas shock will hold it open.

This answer is automatically generated

0

Subscribe to Our Youtube Channel
