ICD PROMASTER™ MANUAL-REV1
1) Treat every marker as if it were loaded.
2) Never look down the barrel of a paintball marker.
3) Keep your finger off the trigger until ready to shoot.
4) Never point the marker at anything you don't wish to shoot.
5) Keep the marker on safe until ready to shoot.
6) Keep the barrel blocking device in/on the marker's muzzle when not
shooting.
7) Always remove paintballs and propellant source before disassembly.
8) After removing propellant source, point marker in safe direction and dis-
charge until marker is degassed.
9) Store the marker unloaded and de-gassed in a secure place.
10) Follow warnings listed on propellant source for handling and storage.
11) Do not shoot at fragile objects such as windows.
12) Every person within range must wear eye, face, and ear protection
designed specifically to stop paintballs and meeting ASTM standard
F1776.
13) Always measure your marker's velocity before playing paintball and
never shoot at velocities in excess of 91.44 meters (300 feet) per second.
6/15/05
6:00 PM
RULES FOR SAFE MARKER HANDLING
Page 1
ProMaster
TM
Manual 1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PROMASTER and is the answer not in the manual?

Questions and answers

Related Manuals for Indian Creek Design PROMASTER

Summary of Contents for Indian Creek Design PROMASTER

  • Page 1 ICD PROMASTER™ MANUAL-REV1 6/15/05 6:00 PM Page 1 RULES FOR SAFE MARKER HANDLING 1) Treat every marker as if it were loaded. 2) Never look down the barrel of a paintball marker. 3) Keep your finger off the trigger until ready to shoot.

  • Page 2: All Rights Reserved

    Indian Creek Design, Inc., its assigns and/or its distributors. Notice is hereby given that this manual is part of the article owned in whole by Indian Creek Design, Inc., its assigns and/or its distributors, known as indicated in this manual and drawings. All rights of manufacture and reproduction of such articles or any part thereof are reserved by Indian Creek Design, Inc., its assigns and/or its distributors.

  • Page 3: Statement Of Liability

    Design, Inc., its assigns and/or its distributors assumes no responsibility for physical injury or property damage resulting from its use. Indian Creek Design, Inc., its assigns and/or its distributors, makes no warranties with respect to this documentation and disclaims any implied warranties of merchantability or fitness for a particular pur- pose.

  • Page 4: Limited Warranty

    Such warranty service will be provided only if the warranty registration card included with this manual is filled in completely and on file at Indian Creek Design, Inc. All other service will be duly charged for and returned via UPS C.O.D.
  • Page 5 , thereby providing the end user with a high-quality, precision-engineered marker. Paintball markers get a lot of abuse. Indian Creek Design, Inc., has designed the PROMASTER with this in mind. All internal parts, wear and contact surfaces have been heat treated or hard anodized.

  • Page 6: Operation

    Keep your finger out of the trigger guard and away from the trigger; point the muzzle of the marker in a safe direction at all times. Keep the marker turned off until ready to operate. The PROMAS- uses an on-off switch as one of its safety features. Always keep your PROMASTER point- ed in a safe direction.
  • Page 7 PROMASTER , or a recognized and competent airsmith, for instruction in the safe handling of compressed-air cylinders before purchasing or connecting one to your PROMASTER Adjustable regulator compressed air systems: The input pressure from your compressed air system should be regulated down to 450-500 PSI output pressure.
  • Page 8 Only a qualified and trained technician should perform work to your tank and tank regulator. Before pressurizing your PROMASTER , check to make sure that you and anyone within range are wearing eye protection designed specifically for paintball. Be sure you have a barrel blocking device in place and make sure there are no paintballs in the marker.
  • Page 9 ICD PROMASTER™ MANUAL-REV1 6/15/05 6:03 PM Page 9 PAINTBALLAND LOADER USAGE The PROMASTER comes equipped to accept 1.03" OD feed neck loaders. Fit the loader directly into the vertical feed tube. Always twist it down in a CLOCKWISE direction. Always twist it off in...
  • Page 10 The PROMASTER will fire “Semi-Auto” or single shot per trigger pull with a maximum rate of fire governed to 15 balls-per-second or unlimited. The PROMASTER may also be set in three differ- ent enhanced modes. These include “Ramp”, “Ramp-Auto” and “Ramp-Burst”.
  • Page 11 ICD PROMASTER™ MANUAL-REV1 6/15/05 6:04 PM Page 11 SETTING MODES, RATE-OF-FIRE AND DWELL Rate of Fire - Balls Per Second (BPS) Controlling Switch Switch #1 is only used to control BPS limits. When Switch #1 is in the ON position the BPS is limited to 15.

  • Page 12: Parts List

    ICD PROMASTER™ MANUAL-REV1 6/15/05 6:04 PM Page 12 Parts List Part # Description Main Body Bolt 1/4 Bolt Chrome Bearing Bolt Retention Spring 5/16-24x1/2 Set Screw Hammer Cylinder Body Piston Cylinder Main Spring 1-72x1/2 SHCS H-015 O-Ring Cylinder End Cap...
  • Page 13 ICD PROMASTER™ MANUAL-REV1 6/15/05 6:04 PM Page 13 Parts List (Contʼd.) Part # Description 6-32x1/4 Button Head 6-32x3/8 SHCS 3-8/24x1/4 Set Screw Regulator Cup Spring Anti-Double Feed Spring Circuit Board Barrel Plug Cylinder Spring Assist Sleeve Cylinder Spring Guide Rubber Grip 700 p.s.i.
  • Page 14 The shorter the dwell setting the faster the potential cycling rate but the more likely to experience skipping. CAUTION: Over shortening the dwell time will render the ProMaster inoperable. To Adjust Dwell Setting Turn Switch 4 to ON position.
  • Page 15 Make sure the on-off toggle slide switch is in the off position. Always keep your PROMASTER pointed in a safe direction! Place the empty loader onto the marker. Be sure that it is securely mounted in place.
  • Page 16 ICD PROMASTER™ MANUAL-REV1 6/15/05 6:05 PM Page 16 UNLOADING THE PROMASTER Keep your finger out of the trigger guard and away from the trigger; point the muzzle of your marker in a safe direction at all times during this process. Be sure you and everyone within range is wearing eye protection designed especially for paintball.

  • Page 17: Maintenance

    Cleaning Paint from the Barrel Unscrew the barrel to remove for swabbing/cleaning. Keep the barrel clean to insure the continued accuracy of the PROMASTER . Gelatin from the paintballs has a tendency to build up in the bar- rel. As part of your regular cleaning process, wash out the barrel with hot soapy water and rinse it well.
  • Page 18 ICD PROMASTER™ MANUAL-REV1 6/15/05 6:06 PM Page 18 Removing the Bolt/Cylinder Assembly (Field Stripping) Remove the paintballs and propellant source from the marker. While the marker may be field-stripped while pressurized, this is not recommended. Remove the link pin from the top of the marker. Pull the bolt out the back of the main body.

  • Page 19: Storage And Transportation

    PROMASTER in a suitable marker case or in its original box. If you must ship your PROMASTER for any reason, the box in which you purchased the marker is acceptable to all major carriers. Never ship a pressurized CO2 or compressed gas cylinder.
  • Page 20 ICD PROMASTER™ MANUAL-REV1 6/15/05 6:06 PM Page 20 ADJUSTING THE TRIGGER PULL You will notice three (3) screws in your trigger. These screws adjust the length of pull, actuation point and spring tension of the trigger. The bottom screw adjusts your trigger stop point (length of pull).

  • Page 21: Tuning Guide

    ICD PROMASTER™ MANUAL-REV1 6/15/05 6:07 PM Page 21 PROMASTER TUNING GUIDE Velocity Adjustment - Using the Main Input Pressure Regulator: The PROMASTER operates on a proven and innovative system. Take the time to understand this section. The pressurized gas is regulated internally. The high-pressure air is used to propel the paintball.
  • Page 22 ICD PROMASTER™ MANUAL-REV1 6/15/05 6:07 PM Page 22 LOW PRESSURE REGULATOR ADJUSTMENT Low Pressure Regulator Adjustment: The low-pressure regulator is externally adjustable via the adjustment screw in the front of the low- pressure regulator. The low-pressure regulator is pre-set at the factory to 85-95 PSI to operate the 4- way solenoid actuated valve located in the rear of the marker.

  • Page 23: Troubleshooting Guide

    Try cleaning it with rubbing alcohol. If this does not work, replace it. c) Replace the O-ring around the valve seat. The PROMASTER™ has a leak around the low-pressure regulator seam. Reason: The seal between the regulator body and regulator adapter body is bad, or the regulator is loose.
  • Page 24 ICD PROMASTER™ MANUAL-REV1 6/15/05 6:08 PM Page 24 Ball Breakage Problems The paintballs break in the breech. a) The paintballs in you loader can bind, messing up your trigger timing. Always use an agitated or force feed loader and verify the PDS is on.
  • Page 25 ICD PROMASTER™ MANUAL-REV1 6/15/05 6:08 PM Page 25 BATTERY RELATED PROBLEMS LED functions but the marker does not fire. Alternately missed shots. Velocity drops while firing several shots. Erratic velocities. Jumps of 20 fps or more. Unexplainable paint breakage. Slight leak from the solenoid in the back of the grip.
  • Page 26 ICD PROMASTER™ MANUAL-REV1 6/15/05 6:08 PM Page 26 Part # ICD Item # Description Part # ICD Item # Description 402001 Main Body 402007 Eye Holder 402012 Bolt 402006L Left Eye Cover D250HCB 1/4 Bolt Chrome Bearing 402006R Right Eye Cover...
