Summary of Contents for Cairox S-TOUCH
- Page 1 user manual...
-
Page 2: Table Of Contents
SOLANO air curtains ................14 General information SOLANO COMBI air curtain-fan heater combo units ...16 Alarms .......................20 S-TOUCH intelligent controller with touch screen enables control all air curtains SOLANO. Each unit must have its own individual address in S-ECM control module. -
Page 3: Installation
T-box T- box mounted out of area i.e. technical room. max. 50 m In the case, when S-TOUCH in BMS network is the last device, SW1 switch should be set in T120 position. Navigation return to previous screen with save of changes... -
Page 4: First Run
First run Language Data August Selection of language Setting of date active language Time Devices 13PM Setting of time Searching of connected units CAIROX... - Page 5 • power supply of the unit, • correct setting of addresses, each unit must have different address, • if in the last unit dip-switch SW2 is set in T120 position. DRV address Set individual addrress in S-ECM module for each unit. CAIROX...
-
Page 6: Main Screen
BMS settings settings lock active integrated units restore factory settings BMS mode active calendar active calendar active – settings forced CAIROX... -
Page 7: Time
2 s the calendar icon on main screen). Ad hoc settings stays as long as time of current August event in calendar. With start of next event, units will operate according to programmed settings. Setting of date CAIROX... - Page 8 SYSTEM WILL OPERATE USING CURRENT SETTINGS UNTIL NEW EVENT WILL BE SET. copying events on the following days removing the events moving to the next day event – system ON 7:00AM event – system OFF 9:00AM CAIROX...
- Page 9 SYSTEM WILL BE TURNED OFF UNTIL THE NEXT EVENT, ACCORDING TO CALENDAR SETTINGS. day selected for copying events from PN day day with already programmed operation schedule – you can also copy here the events from PN day day without programmed operation schedule CAIROX...
-
Page 10: Language
Calendar – Language Removing events Weekly programer Language Delete task 7:00AM 9:00AM 9:15AM 4:00PM 4:15PM 7:00PM 10:00PM 8:15PM events selected confirmation of active language to remove events removal CAIROX... -
Page 11: Integrated Units
Integrated units Reset Devices Reset to default settings? SOLAN Restore default settings searching for units integrated with system active deactivated unit unit – not operating System information SOLANO01 CURTAIN MAIN DRV-V 2.1 2.0.0-2d-G8B342117 long press displays the S-ECM software CAIROX... -
Page 12: Leading Sensor
1. Set password leading sensor is the sensor built 2. Confirm OK in S-TOUCH controller Free 4-digit password can be set. leading sensor is the local sensor. When it is After returning to main screen and 30s of inactivity, selected, operation of each unit is regulated controller will be locked automatically. -
Page 13: System Information
Information menu B M S – settings System information S-Touch 2.0.10 Compilation 2.0.15-2-gd25434f 14.10.2016 Basic information about software and hardware version ID – setting unit adress: from 1 to 247 BAUD – setting data transmission speed: from 9600 to 115200 bit/s... -
Page 14: Solano Air Curtains
Door sensor has a priority. Without it’s signal unit will not run antifreeze heating – valve is opened when measured temperature is lower than desired temperature ventilation – valve is constantly closed, fan operates continuously at selected step CAIROX... - Page 15 ∞ value, then valve is constantly open. specified period of time or be turned off - select OFF. Valve delay time must be shorter than fan delay time. CAIROX...
-
Page 16: Solano Combi Air Curtain-Fan Heater Combo Units
– 3-steps Readings selection of operating mode SOLANO setting of delay times Readings readings antifreeze To read temperatures near the unit, external temperature sensors PT-1000 must be connected to S-ECM control module. CAIROX... - Page 17 – valve is opened when measured temperature is lower than desired temperature ventilation – valve is constantly closed, fan operates continuously at selected step Fan heater operates always according to temperature set on the controller, regardless K1/K2 mode. CAIROX...
- Page 18 Valve switch off delay time can be set in the ran- heater can operate continously on selected step: ge 0:00–10:00 minutes, every 0:30s. Value ∞ 1, 2, 3 or be turned off – select OFF. – valve is constantly open. CAIROX...
- Page 19 ON/OFF valve fans stops and valve is open to 100%. To read temperatures near the unit, external temperature sensors PT-1000 must be connected to S-ECM control module. CAIROX...
-
Page 20: Alarms
• COMBI heater not connected • Real time clock error no communication between S-ECM set the S-TOUCH time again of fan heater part of SOLANO COMBI, • Internal temperature sensor errror check connection between S-ECM S-TOUCH built-in temperature sensor is... - Page 21 CAIROX...
- Page 22 CAIROX...
- Page 23 CAIROX...
- Page 24 v1.0/PLENFR/10.2016...
