Cairox S-TOUCH User Manual

V-One User Manual
English
Safety
The V-One is a precision tool for electronics prototyping. As with any such equipment, the V-One and the
accompanying materials and accessories should be handled with care.
Please review the following material to ensure a safe work environment and to maintain optimal machine
performance.
The V-One is not only an excellent tool for the seasoned electrical engineer but it is also a great way to teach
electronics. Never leave the V-One unattended while in use and supervise young and inexperienced users to
ensure safe operation.
The V-One is for use as-is. Any modifications to the machine or improper use without explicit approval and
direction from Voltera may damage the machine, may cause bodily harm, and will void your warranty.
In case of emergency or prior to performing any maintenance, please ensure power cable is disconnected
from the V-One.
Printing Platform
The heated bed is a multipurpose heater with a maximum temperature of 240°C that is used
to dry printing materials and reflow solder paste. When the heater is on, the LEDs on either
side of the V-One will glow red. While the LEDs are red, the printing platform is unsafe to touch
and can cause burns. Remove any combustible materials from the area when heater is in use.
Printing Materials
The V-One comes with 2 mL cartridges of printing material: conductive ink and solder paste.
Do not ingest and keep these materials away from mouth and eyes. Be sure to wash hands
well with soap and water before eating or drinking after handling.
The conductive ink is a combustible liquid and must be kept away from heat/sparks/open
flames/hot surfaces. No smoking. In case of fire, suitable extinguishing agents are: CO2,
powder or water spray. Fight larger fires with water spray or alcohol-resistant foam.
Please refer to the MSDS at voltera.io/msds for detailed information on proper handling and
disposal procedures.
Sharp Tools
The accessories included with the V-One contain sharp tools such as the probe and
dispensing nozzles. Always keep the tip caps on the probe and the dispenser while not in use
to prevent damage to the equipment and accidental injury.
Moving Parts
The V-One is an electromechanical device with motors, gears, and belts. Keep fingers away
from moving parts.
