Peak PCAN-Router Pro FD User Manual page 4

PCAN-Router Pro FD - User Manual
6 Firmware Upload
6.1 System Requirements
6.2 Preparing the Hardware
6.3 Firmware Transfer
7 Configurable Data Logging
7.1 Installation
7.2 Configuration
7.2.1 Nominal and Data Bit Rates
7.2.2 CAN Specification and Options
7.2.3 Trace Options
7.2.4 Maximum File Size
7.2.5 Trace Mode
7.2.6 Memory Card
7.2.7 Handling of the USB Connection
7.2.8 Trace Start on Power-Up
7.2.9 Timeouts
7.2.10 Beep Patterns
7.2.11 LED Blinking Patterns
7.2.12 Remote Control via CAN
7.3 Configuration of the Ethernet Connection
7.3.1 IP Address
7.3.2 Subnet Mask
7.3.3 Gateway Address
7.3.4 Output the IP address via CAN
7.3.5 FTP Access
7.3.6 FTP Connection Timeout
7.4 Operation
7.4.1 LEDs
7.4.2 Control with the Log Off Card Button
7.4.3 Handling Trace Files
7.4.4 Memory Card Capacity and Logging
Duration
7.4.5 FTP Data Transfer
7.4.6 WebSocket Remote Control
4
25
25
25
28
31
32
33
34
35
36
36
37
37
38
38
39
40
41
41
42
42
43
44
44
45
46
47
47
48
48
49
49
51
