Page 4: Modulation Meter
Modulation Meter Type AFM3 Section A. Introduction Accurate measurements on distorted sig nals are rendered easy by a switch that enables the positive and negative peak value to be measured separately. If in creased resolution is desired, an ext�ar nal indicator, such as a voltmeter, can be employed to extend the measuring range downwards. - Page 11 Section C. Accessories PLUG-IN CRYSTAL OSCILLATOR UNIT, CODE 900-252 COOE \I00.2S2 General The Plug-in Crystal Oscillator Unit, code 900-252, is preferably used within the frequency range 67 - 1 001 MHz to Fig. Cl. The Crystal Oscillator Unit, achieve low residual FM. It is supplied code 900-252.
- Page 16 Fig. D2. Front plate of the Modulation Meter, type AFM3. peak can be measured. The AF detector frequency bands.} The next position is has two time constants, thereby furnish a rest position. In the last position, the ing two meter responses. plug-in Crystal Oscillator Unit (if any} is connected.
- Page 23 Read the modu lotion deviation. Check whether the reading is the same for both peaks of modu lotion: a dif ference indicates distortion of the mod u I at ion envelope. See Fig. E4, and refer to SECTION B - SPECIFICATIONS under "FM MODULATION - Distortion''.
