Bavaria Yachts Bavaria 49 Manual

Sailing yacht
Hide thumbs
Table of Contents

Advertisement

Quick Links

Manual
for owners and skippers
Sailing yacht „BAVARIA 49 "
Bavaria Yachtbau GmbH x Bavariastr. 1 x D – 97232 Giebelstadt
Tel.: +49 (0) 9334 942 – 0; Fax: +49 (0)9334 942 – 116
e-mail : info@bavaria-yachtbau.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Bavaria 49 and is the answer not in the manual?

Questions and answers

Related Manuals for Bavaria Yachts Bavaria 49

Summary of Contents for Bavaria Yachts Bavaria 49

  • Page 1 Manual for owners and skippers Sailing yacht „BAVARIA 49 “ Bavaria Yachtbau GmbH x Bavariastr. 1 x D – 97232 Giebelstadt Tel.: +49 (0) 9334 942 – 0; Fax: +49 (0)9334 942 – 116 e-mail : info@bavaria-yachtbau.com...
  • Page 2 Sailing Yacht Bavaria 49 Bavaria Yachtbau GmbH INDEX Introduction page 3 Category of design page 4 Builder’s plate page 5 Warnings page 5 Declaration of Conformity page 6 Description of the yacht 2.5.4 Important warnings on the DC- Main particulars installation 1.1.1...
  • Page 3 Introduction This manual will help you to handle your yacht safely and with pleasure. Apart from information about the yacht itself and installed or additionally supplied fittings the manual also contains information on operation and maintenance. Please familiarise yourself with everything before you go on your first voyage.
  • Page 4 Sailing Yacht Bavaria 49 Bavaria Yachtbau GmbH Category of design Following the European Recreational Craft Directive each boat has to be classified according to a category of design. All sailing yachts of BAVARIA belong to the category of design A, designed for extended voyages where conditions may exceed wind force 8 (Beaufort scale) and significant wave heights of 4m and above, and vessels largely self-sufficient.
  • Page 5 Sailing Yacht Bavaria 49 Bavaria Yachtbau GmbH Builder’s plate The builder’s plate on the front wall of the cockpit is a demand of the Directive because certain information are required which will be explained in the following. Explanations : Ocean - Category of design A - Max.
  • Page 6 Sailing Yacht Bavaria 49 Bavaria Yachtbau GmbH – 7 – (39)
  • Page 7 Sailing Yacht Bavaria 49 Bavaria Yachtbau GmbH 1.Descripton of the yacht 1.1 Main particulars 1.1.1 Principal dimensions Length overall 15,40 m Length of hull 14,95 m Length on waterline 13,10 m Breadth max. 4,46 m Draught - normal keel D...
  • Page 8 Sailing Yacht Bavaria 49 Bavaria Yachtbau GmbH 1.2 General arrangement 1.2.1 Rigging plan Reference The valid measuring of the foresail reefing gear are on the enclosure note at the carton of the Furlex-foresail reefing gear – 10 – (39)
  • Page 9 Sailing Yacht Bavaria 49 Bavaria Yachtbau GmbH 1.2.2 Deck arrangement – 11 – (39)
  • Page 10 Sailing Yacht Bavaria 49 Bavaria Yachtbau GmbH Explanations in the deck plan: BAVARIA 49 1 Fue de navigation av Bow navigation light Navigationsbeleuchtung 2 Ferrure d'etrave inox Bow fitting Bugbeschlag 3 Balcon avant Bow pulpit Bugkorb 4 Filiers laterales Life lines...
  • Page 11 Sailing Yacht Bavaria 49 Bavaria Yachtbau GmbH 1.2.2 Accommodation plan (3 cabin) Ruderanlage Steering gear Doppelbett Double berth Schrank Shelf Niedergang / Motorraum Companion way / engine room Badezimmer Bathroom Sitzgruppe Seating Salontisch Saloon table Hängeschrank Hanging locker Badezimmer Bathroom...
  • Page 12 Sailing Yacht Bavaria 49 Bavaria Yachtbau GmbH (5 cabin) Ruderanlage Steering gear Doppelbett Double berth Schrank Shelf Niedergang / Motorraum Companion way / engine room Badezimmer Bathroom Sitzgruppe Seating Salontisch Saloon table Hängeschrank Hanging locker Etagenbett Bunkbed Schrank Shelf Badezimmer WC...
  • Page 13 Sailing Yacht Bavaria 49 Bavaria Yachtbau GmbH 1.3 Drive systems 1.3.1 Sails The SY Bavaria 49 is equipped with the following standard sails: Main sail standard abt 46,3 sqm Main sail (fully-battened) abt 53,2 sqm Furling Genoa abt 70,1 sqm 1.3.2 Rigging...
  • Page 14 Sailing Yacht Bavaria 49 Bavaria Yachtbau GmbH Engine plant Motor Volvo Engine Volvo Motor Auspuffsystem Engine exhaust System Auspuff Wassersammler Exhaust Waterlock Kraftstoffzulauf Engine Fuel Intake Kraftstoffrückführung Feed back Fuel Kraftstoffeinfüllstutzen Fuel Tank filling Hose Tankentlüfter Fuel Tank Ventilator Kraftstofffilter...
  • Page 15 Sailing Yacht Bavaria 49 Bavaria Yachtbau GmbH 2. Installations and circuits 2.1 Tanks and piping – water 2.1.1 Fresh water, drinking water –cold The yacht has two water tanks with a capacity of altogether abt 650 l. Fresh water is supplied via a water inlet (with a blue cover) at the transom, port side and on the forecastle near the chain locker.
  • Page 16 Sailing Yacht Bavaria 49 Bavaria Yachtbau GmbH Einfüllstutzen Deck Plate (inlet) Tankentlüftung Tank venting Boiler Water heater Rücklauf Boiler Reflux water heater Druckgefäß + Druckschalter Accumulator tank + pressure switch Spüle Sink Frischwasserpumpe Fresh water pump 2 – Wegehahn 2 – way valve...
  • Page 17 Sailing Yacht Bavaria 49 Bavaria Yachtbau GmbH 2.1.2 Sea-water circulation Sea-water is necessary for both WC flushing and engine cooling (see: 2.9). 2.1.3 WC –installation: see enclosed directions for use Attention If you are not aboard for a longer time you should close all sea-valves.
  • Page 18 Sailing Yacht Bavaria 49 Bavaria Yachtbau GmbH Borddurchlass Outlet Fäkalientankentlüftung Waste water tank venting Kugelhahn Ausgang el. Duschpumpe El. Shower drain valve Kugelhahn Ausgang Waschbecken Wash basin drain valve Kugelhahn Ausgang WC Toilet drain valve Fäkalientank Waste water tank Kugelhahn Eingang WC Toilet Water drain valve Kugelhahn Ausgang Fäkalientank...
  • Page 19 Sailing Yacht Bavaria 49 Bavaria Yachtbau GmbH Attention A trouble free operation of the engine and heating is only possible, if the fuel is clean. That’s why a regular inspection and cleaning of filter/water separator is unavoidable. The fuel tank should be completely emptied and cleaned once a year.
  • Page 20 The chain locker is made watertight against the yacht. It is self-bailing through two holes in the skin. All BAVARIA yachts have got a self-bailing cockpit, too. The drain wells are situated at the rear and lowest part of the cockpit and are led outboard through the transom with hoses.
  • Page 21 Sailing Yacht Bavaria 49 Bavaria Yachtbau GmbH 2.5 The electric installation 2.5.1 The AC-installation The yacht has got a shore connection (option) by which it can be supplied with electric power from ashore when being berthed in a port. The plug box ( meeting the CEE-norm) is installed at the transom of the yacht.
  • Page 22 Sailing Yacht Bavaria 49 Bavaria Yachtbau GmbH 2.5.4 Important warnings on the DC-installation Warning To avoid freezing also maintenance-free batteries have to be recharged in winter if their capacity becomes less than 50%. Once a year all contacts should be checked and protected with a special spray.
  • Page 23 Sailing Yacht Bavaria 49 Bavaria Yachtbau GmbH 2.5.6 Distribution of electric devices: (3 cabin) – 25 – (39)
  • Page 24 Sailing Yacht Bavaria 49 Bavaria Yachtbau GmbH (5 cabin) – 26 – (39)
  • Page 25 Sailing Yacht Bavaria 49 Bavaria Yachtbau GmbH Explanation on the distribution of electric devices BAVARIA 49 Description Beschreibung 1 Navigation light Zweifarbenlaterne 2 El. windlass Elekt. Ankerwinde 3 Windlass switch Ankerwinde - Bedienteil 6 Fresh water gauge Vorratgeber für Frischwassertank...
  • Page 26 Sailing Yacht Bavaria 49 Bavaria Yachtbau GmbH 2.5.7 Wiring plans – 28 – (39)
  • Page 27 Sailing Yacht Bavaria 49 Bavaria Yachtbau GmbH 2.5.8 Distribution plans – 29 – (39)
  • Page 28 Sailing Yacht Bavaria 49 Bavaria Yachtbau GmbH 2.5.9 AC-distribution – 30 – (39)
  • Page 29 Sailing Yacht Bavaria 49 Bavaria Yachtbau GmbH 2.6 L.P.G. installation The gas installation for the stove meets the European norm EN ISO 10239. Attached please find the test- certificate. The gas pipe leading to the stove from the standard 3 kg–gas cylinder is an 8mm copper pipe. It is placed into a self-bailing casing moulded into the deck in the rear cockpit area.
  • Page 30 Sailing Yacht Bavaria 49 Bavaria Yachtbau GmbH 2.6.2 Operation Gas installations require care. That’s why you should follow this sequence: Attention Open the stop valve in the gas cylinder casing Open the valve before the stove Open a stove valve and lighten the gas Keep the valve open until the glow timer allows further burning.
  • Page 31 Sailing Yacht Bavaria 49 Bavaria Yachtbau GmbH 2.7 Fire protection When building the yacht special attention was payed to avoid the risks of fire. This includes the choice of materials, the distance of stove flames to the surrounding built-in furniture and an island position of the engine.
  • Page 32 Sailing Yacht Bavaria 49 Bavaria Yachtbau GmbH It is the yacht owner´s or skipper´s duty to make sure that all extinguishers are freely accessible to inform all persons on board about: the position and use of all fire extinguishers and the fire retarding cloth, the position and function of the opening for the extinguisher´s nozzle in the engine room...
  • Page 33 Sailing Yacht Bavaria 49 Bavaria Yachtbau GmbH 2.10 Exhaust gas system The yacht is fitted with a “wet“ exhaust gas system, i.e. cooling sea water is injected into the exhaust gas elbow causing a cooling of exhaust gases. This mixture is led down into a silencer/water lock, runs through a pipe in the locker seat on the starboard side of the aft cabin, is led upwards at the stern and escapes to the side above the water-line.
  • Page 34 Sailing Yacht Bavaria 49 Bavaria Yachtbau GmbH 2.12 Board ducts, sea water valves Openings below the water line are possible weak spots. That is why we pay special attention to them. All board ducts in the underwater part, with the exception of the duct for the transmitter of the echo sounder, consist of brass-made screwed joints with spherical sea valves and hose nipples.
  • Page 35 Sailing Yacht Bavaria 49 Bavaria Yachtbau GmbH (5 cabin) Kühlwasserfilter Cooling water strainer Ausgang el. Duschpumpe El. Shower drain pump Ausgang Waschbecken Basin drain Eingang WC Toilet water drain Ausgang Fäkalientank Waste water drain Echolot Depth sounder Ausgang WC Toilet drain...
  • Page 36 Sailing Yacht Bavaria 49 Bavaria Yachtbau GmbH 3. Environmental protection BAVARIA YACHTBAU has already met the legal requirements referring to exhaust gas regulations with its choice for the inboard diesel installed. An exhaust gas type-examination certificate can be handed in or sent on later.
  • Page 37 Sailing Yacht Bavaria 49 Bavaria Yachtbau GmbH 2. Sails The sails are made of Dacron. This material is very robust and resistant. Thus the sails keep their form for a very long time. Inspect all your running and standing rigging carefully for sharp edges, splints, protruding ends of wire and the like because laminated cloth is especially sensitive against touching them.
  • Page 38 Sailing Yacht Bavaria 49 Bavaria Yachtbau GmbH pure chrome. The corrosion can start. Who is not disapointed about little brown spots on the fittings ? They are caused by flying rust or particles of iron, which are flying in the air and in all harbours placed near big towns. As soon as the flying rust will set down to the protective coat of the stainless steel, it destroys the cr-passivity, and this goes very aggressive and fast.
  • Page 39 Sailing Yacht Bavaria 49 Bavaria Yachtbau GmbH Advice: Before wintering you should pay special attention to the following parts and protect them correspondingly: Rinse and clean the transmitters of the speedometer and echo sounder. Maintain the electrical systems and clean them with suitable materials.
  • Page 40 Sailing Yacht Bavaria 49 Bavaria Yachtbau GmbH 5. Final remarks and notes This manual is in conformity with the directives of the harmonised European Norm EN 10240. Much of it might go without saying for you. Nevertheless we hope, that dealing with the different chapters of this manual will help you to understand the technical systems and the ideas behind them.
  • Page 41 Sailing Yacht Bavaria 49 Bavaria Yachtbau GmbH 6. List of manuals supplied manual with declaration of conformity engine assurance board with corresponding instruction gas test document with corresponding working instruction release checklist leaflets and description of production work working instructions:...
