  • Page 1 BAVARIA Owner‘s Manual...

  • Page 2: Table Of Contents

    Owner‘s manual Content Introduction Responsibility of the coxswain/skipper/owner/captain 2.1. Maintenance intervals About this manual 3.1. Safety Labels 3.2. Explanations of those Warning signs and symbols Design category and CE-certification 4.1. Certification 4.2. Boat Identification & CE Certificate of design category 4.3. Explanations on the CIN and the builders plate Examination report of the notified Body GL 5.1.
  • Page 3 General considerations 8.1. Recommended safety equipment 8.2. Rough weather conditions – Measures to be taken 8.3. Securing loose equipment. 8.4. Ventilation/Aeration of cabins 8.5. Risk of loss of stability 8.6. Man-over board (MOB) – Risk of falling overboard - Reboarding 8.7. Reboarding devices 8.8. Overview aft deck with swim/rescue ladder 8.9. Emergency plugs 8.10. In general 8.11. Risk of Flooding/Sinking 8.12. Protective baskets or nets 8.13. Risk of fire 8.14. Fire fighting equipment 8.15.

  • Page 4: Introduction

    Owner‘s manual 1. Introduction For your own comfort and safety, please make sure, that crew should be taken into consideration before you em- you have received all the necessary information and doc- bark on any journey. umentation about the ships systems from the previous owner of the craft. Please keep this manual in a secure As the scope of delivery may vary depending on the in- place and hand it over to the new owner when you sell the dividual order, the equipment of your sailing yacht may...

  • Page 5: Responsibility Of The Coxswain/Skipper/Owner/Captain

    Responsibility of the coxswain/skipper/owner/captain 2. Responsibility of the coxswain/skipper/owner/captain The owner or boat captain is fully responsible and shall adhere to the following principal rules: 1. Know and get to know about the limitations of your boat. 2. Always follow the rules of the road - make sure you know about the local rules and regulations. 3. Keep a good and sharp lookout for people and objects in the water. 4. Ensure, that the anticipated wind and sea conditions do always correspond to the design category of the boat and that you and your crew are able to handle the boat in these conditions; 5.

  • Page 6: Maintenance Intervals

    Owner‘s manual 2.1. Maintenance intervals We impose the highest standards on the quality and safety of our products. For routine service checks the following components and equipment must be inspected and replaced if necessary. Also please be sure to comply with the re- quirements for service intervals for the engines, generators and associated equipment. Failure to comply with these regular inspection and replacement intervals for these safety-related components can lead to an elevated risk of injury and death.

  • Page 7: About This Manual

    About this manual 2.1.1. Maintenance and replacements intervals System Necessary maintenance measures Interval frequency Batteries Check poles for corrosion and tight fit Seacocks and control of tightness and function hull penetra- control corrosion tions/fittings Navigation lights Control function Bilge areas Clean & limber holes free Bilge pump control switch and function Zinc anodes Check and replace if necessary wherever possible Hull Check for loose, damaged or missing parts Rudder system check for faultless and smooth operation...

  • Page 8: Safety Labels

    Owner‘s manual 3.1. Safety Labels The craft and this manual show symbols which advise the owner/operator and crew of imperative safety precautions to follow when operating and/or servicing equipment. The following symbols may be found on your craft.  They should be respected at all times. Danger, with descriptive text, the Read the manual, equipment or symbol may be colored or b/w systems will be covered there. Electrical hazard Fuel filler Electrical danger Current Letter „D“ denotes Diesel fuel Fire hazard Sling position for the safe hoisting of the boat Fire extinguisher, may also identify Opening for discharge of a extin-...

  • Page 9: Explanations Of Those Warning Signs And Symbols

    About this manual 3.2. Explanations of those Warning signs and symbols In some chapters of this manual you will find advice concerning the trouble free operation, the maintenance but also some warning about dangers and hazards. For better contrast and visibility those signs are displayed in warning triangles or other panels, they may also be rasterized. Stick to and apply good seamanship at all times! You as the boat captain bear the sole respon- sibility for the boat and the well-being of your crew. Never remove or cover a sign or label.

  • Page 10: Design Category And Ce-Certification

    Owner‘s manual 4. Design category and CE-certification This vessel carries the CE marking (shown here to the right): This is to indicate that it complies with the EU Recreational Craft Directive. The assigned design category will be described in the following paragraph: Your BAVARIA Vision 46 has been assigned the Design Categories A and B, depending on maximum crew and load- ing. A boat given design category A is considered to be designed for extended voyages where conditions may exceed wind force 8 (Beaufort scale) and significant wave heights of 4 m and above but excluding abnormal conditions, and vessels largely self-sufficient. A boat given design category B is considered to be designed to operate in winds up to force 8 (Beaufort scale) and the associated wave heights (significant wave heights up to and including 4m). Such conditions may be encountered on offshore voyages of sufficient length or on coastal waters when unsheltered from the wind and waves for several dozens of nautical miles. These conditions may also be experienced on inland seas of sufficient size for the wave height to be generated.

  • Page 11: Explanations On The Cin And The Builders Plate

    Design category and CE-certification 4.3. Explanations on the CIN and the builders plate The CIN (Craft Identification Number) Consists of a two-digit country code (DE for Germany), followed by the three letter yard identifier BAV for BAVARIA. The following combination of 5 letters or numbers is assigned by the yard and usually identifies the model. The 4th from last place letter denotes the month when the build of the craft began (A for January, etc.) the third from last number identifies the year the building of the craft started. The last two digits denote the model year, the numbers 13 would denote the model year 2013. The builder‘s plate is affixed in the cockpit or near the helm, station and displays the following information. RCD Design Category A A boat given design category A is considered to be designed for extended voyages where conditions may exceed wind force 8 (Beaufort scale) and significant wave heights of 4 m and above but excluding abnormal conditions, and vessels largely self-sufficient RCD Design Category A boat given design category B is considered to be designed to operate in winds up to force 8 (Beaufort scale) and the associated wave heights (significant wave heights up to and including 4m). Such conditions may be encountered on offshore voyages of sufficient length or on coastal waters when unsheltered from the wind and waves for several dozens of nautical miles.

  • Page 12: Examination Report Of The Notified Body Gl

    Owner‘s manual 5. Examination report of the notified Body GL 5.1. Certificate Category A...

  • Page 13: Certificate Of Gl For Category B

    Examination report of the notified Body GL 5.2. Certificate of GL for category B...

  • Page 14: Main Dimensions

    Owner‘s manual 5.3. Main dimensions Main dimensions of category A versions with either standard deep or shallow draft keel. Description of the dimension Denom. Standard deep Shallow keel keel (Cat A) (Cat A) Maximum length (incl. anchor fitting) 13,99 m 13,99 m Length of the hull 13,70 m 13,70 m Maximum beam...
  • Page 15 Examination report of the notified Body GL 5.3.1. Sail plan (Options furling main, including Gennaker) E=6,05 m J=4,68 m...
  • Page 16 Owner‘s manual 5.3.2. Sail dimensions Description of the dimension Denom. Value Main sail Luff length of mainsail from tack to head 16,71 (16,56) m Foot length of mainsail along boom from tack to clew 6,05 m Area of the main sail furling version ca. 54 m Area of the main sail standard ca. 54 m Jib (Standard furling) The Foretriangle height measured along the foreside of the mast 17,20 m...
  • Page 17 Examination report of the notified Body GL 5.3.3. Displacement, weights Warning The boat should never carry more than the manufacturer‘s recommended load. Load the boat carefully, and evenly distributed. The load should be suitably distributed, with their centers as low as possible, to ensure that the boat floats on its design trim. Bear in mind that stability is most significantly reduced by any weight added high up in the boat. The following weights have been identified as the basis of the stability calculations performed according to the rel- evant EN-ISO standards. Description of the dimension Abbrev. Value Light craft mass (deep standard keel) Cat A & B 11.484 kg Light craft mass (shallow keel) Cat A & B 11.791 kg Maximum weight of the people on board (10 persons), weighing each 75kg on an average 750 kg Maximum weight of the people on board (16 persons), weighing each 75kg on an average 1.200 kg Personal baggage & other carry on weights (20 kg per person) Cat B 150 kg Personal baggage & other carry on weights (20 kg per person) Cat A 150 kg...

  • Page 18: Interiour Layout

    Owner‘s manual 5.3.4. Maximum recommended load (additional to the light displacement) • The weight of all crew (where each person is calculated with a weight of 75 kg each) • the weight of the personal equipment of all crew • the weight of permanent stores • the equipment, that is not included in the light displacement • Payload and weight of Fluids such as diesel and fresh water 5.4. Interiour layout Description Aft cabin Locker/cabinet Engine room...

  • Page 19: Deck Plan

    Examination report of the notified Body GL 5.5. Deck plan...
  • Page 20 Owner‘s manual 5.5.1. Denotations for the deck plan (with optional equipment) Pos. Part/item Pos. Part/item Anchor Companionway with washboards and sliding lid Bow fitting with anchor (Option) Companionway sump Anchor locker lid Halyard winch Anchor locker lid lock Jib winch Anchor windlass Main sail winch Gennaker boom (Option) Cockpit table Furlex (Option) Steering console Pulpit Compass Railing Chart plotter (Option) Pushpit Rudder bearing Cleats Cockpit locker for life raft Deck hatch...

  • Page 21: Permanently Fitted Tanks

    Examination report of the notified Body GL 5.6. Permanently fitted tanks (apart from black water tanks - see separate chapter) Warning Be advised that nominal tankage may not be fully used due to loading conditions and associ- ated trim and heel. Make sure you take into account a reserve of approximately 20% for safety. 5.6.1. Fuel tank Designation Position Max. Filling charge (L) Position of the filler Drain Diesel fuel, fee- Under the raised At the starboard helm, di- Only via the ins- ding engines, ge- floor in starboard...

  • Page 22: Systems (Some Are Optional Only)

    Owner‘s manual 6. Systems (some are optional only) 6.1. Bilge pumps Bilge pumps are fitted as follows: Position of Pump Power source Designation Capacity (l/min) Bilge compartments Cockpit side structure stb, suc- manual Whale Smart- 40 at 45 strokes All bilge compart- tion from bilge compartment, floor bail 5021B per minute ments connected board saloon (boiler)
  • Page 23 Systems (some are optional only) Information regarding bilge pumps » The electrical bilge pumps may only be operated via a manual switch from the helm stand. » The bilge should always be checked after launch. A small amount of water in the bilge is normal. Large amounts of water or any signs of fuel or oil require immediate investigation. Never pump fuel or oil overboard when your boat is in the water. »...

  • Page 24: Lights Under Deck

    Owner‘s manual 6.2. Lights under deck The drawing below describes the installed lights below and on deck: Item Description LED- Stripes LED- courtesy lights floor no number Ceiling- LED Item Description Navigation lights stb/port deck Masttop light Stern light without number Reading or wall mounted light...

  • Page 25: Electrical System On Board

    Systems (some are optional only) 6.3. Electrical system on board Caution - Adhere to the below, these are the fundamental rules to follow » Always check the batteries and the charging system condition before going to sea » Always disconnect and remove the battery when the craft is in winter storage (cold weather areas) or long term storage. » Remove the negative cable first, only then the positive cable. To replace the cables, first replace the positive cable, then the negative one. » Never work on the electrical installation while the system is energized. » Never disconnect shore-power connections when the system is in use. »...
  • Page 26 Owner‘s manual 6.4.2. Image of the two installed electric panels The panel pictured below is installed according to the drawing seen in chapter „6.4.7. Plan 12 Volt“ page 29. The panel serves the 12 Volt System. The 12 Volt Systems circuits switched on the above panel (12 Volt) are fused on the front of an additional fuse panel which is situated, below the switch panel. Danger - fuse ratings » Please install fuses with the correct values, installing fuses with higher values may cause damage to the panel due to over heating.
  • Page 27 Systems (some are optional only) 6.4.3. Drawing of 12 volt fuse panel front side with the fuses locations The following fuses are installed on the fuse panel. The power supply part is installed behind the settee backrest of the saloon settee. You must respect the nominal values of the fuses when replacing them. Please install fuses with the correct values, installing fuses with hig- her values may cause damage to the panel or the circuits cabling due to over heating. Make sure you carry enough spares in case you need them.
  • Page 28 Owner‘s manual 6.4.5. Power module II with remote battery switch The following fuses are installed on the fuse panel. The power supply part is installed behind the settee backrest of the saloon settee. You must respect the nominal values of the fuses when replacing them. Please install fuses with the correct values, installing fuses with higher values may cause damage to the panel or the circuits cabling due to over heating. Make sure you carry enough spares in case you need them. You will find the german denominators on the circiut board, the following list lists these german expressions and translates those in the coloumn which is named „Beschreibung“. 6.4.6. Caption for the above 12 Volt fuse panel Pos. Engraved Description Pos.
  • Page 29 Systems (some are optional only) 6.4.7. The DC system consists of the following circuits/consumers Pos. Description Pos. Description Antenna Radio el. anchor windlass Engine panel Controls anchor windlass/socket Fuel gauge Sensor fresh water Display Garmin GMI 10 Multisensor (Log- Echosounder) Garmin GHP12 iPod- Station Compass Consumer batteries Bow-/stern thruster (Option) Main switch consumers/bow thruster Control unit bow thruster (Option) *1 Fresh water pump Control unit Revo- winch (Jib)/ engine Shower sump pump Electr. jib winch drive (Option) El. bilge pump (also sump) Heater (Option) El.
  • Page 30 Owner‘s manual 6.4.8. Plan 12 Volt...

  • Page 31: Work On The Batteries

    Systems (some are optional only) 6.5. Work on the batteries The batteries should not be easily accessed without the use of tools, poles should be covered with covers to avoid the danger to get into contact with the poles. Make sure all people on board are aware of the danger. Caution - Battery replacement To disconnect the battery cables from the poles: 1. Disconnect all consumers drawing current from the battery 2.

  • Page 32: Ac System (Alternating Current 230/110 Volt)

    Owner‘s manual Please observe the instructions of the manufacturer: The batteries are AGM batteries, an absorbed glass mat battery has the electrolyte absorbed in a fiber-glass mat separator. While these batteries are often colloquially called sealed lead–acid batteries, they always include a safety pressure relief valve. As opposed to vented (also called flooded) batteries, a VRLA cannot spill its electrolyte if it is in- verted. Because AGM VRLA batteries use much less electrolyte (battery acid) than traditional lead–acid batteries, they are sometimes called an „acid-starved“ design.These batteries are well suited to marine applications. 6.6. AC System (alternating current 230/110 Volt) The 230/110 Volt panel serves as the control unit with connected shore power or the generator running. The system is polarized. The below image designates the single control lamps, switches and breakers on the 230/110 Volt panels.
  • Page 33 Systems (some are optional only) 6.6.1. The 230 Volt Panel The below panel may vary from the original in details showing the pictograms in design and size. AC 230V/50 Hz 6.6.2. Key to the above Panel Pos Meaning Further explanations Voltage to the system Pilot light on means that there is tension on the panel Voltmeter The digital display indicates the voltage present , either shore power or sup- plied by the inverter...
  • Page 34 Owner‘s manual 6.6.3. The 110 Volt Panel The below panel may vary from the original in details showing the pictograms in design and size. AC 115V/60 Hz 6.6.4. Key to the above Panel Pos Meaning Further explanations Voltage to the system Pilot light on means that there is tension on the panel Voltmeter The digital display indicates the voltage present , either shore power or supplied by the inverter...

  • Page 35: 230/110 Volt Consumers

    Systems (some are optional only) 6.7. 230/110 Volt consumers The locations on the drawing overleaf marked by a circle denote the sockets of the 230/110 Volt system. The AC (alternating current) system consists of the following components, these are denoted by the numbers 1-11 in the drawing overleaf, the list incorporates the options: Pos. Description Shore connection Air conditioning A/C Shore connection general supply Water pump A/C Microwave Electric panels 12 and 230/110 Volt Air conditioning A/C Generator 230/110 Volt Socket on switchboard Dish Washer (Option)
  • Page 36 Owner‘s manual 6.7.1. Components of the 230/110 Volt system on board:...
  • Page 37 Systems (some are optional only) 6.7.2. Power sources of the 230/110 Volt System The alternating current (AC) system is supplied with power by the sources listed below Power source Number Position Shore connection Aft locker port Caution » Replace fuses with one of the same rating as the original. A higher rating will render the circuit unprotected against overcurrent. » Connect metallic housings or enclosures of installed electrical appliances to the protective conductor system in the craft (green or green with yellow stripe conductor. » Use double insulated or grounded (earthed) electrical appliances Danger » Do not allow the shore-power cable end to hang in the water. An electrical field can be caused which can cause injury or death to nearby people in the water. »...

  • Page 38: Fuel System

    Owner‘s manual 6.8. Fuel system The craft is equipped with a permanently installed diesel fuel system. The following components are supplied by the fuel system: Part Number Place of installation Engine propulsion Engine room Heater (Option) 1 (Stb) Aft, in the accessible locker stb Generator (Option) Engine room Please refer to the manufacturer’s information for the systems listed above. For detailed information about the tanks refer to the chapter „Permanently fitted tanks“.

  • Page 39: Gas System

    Systems (some are optional only) 6.9. Gas system The gas system (LPG) with its gas containers feeds the cooker/stove in the galley. The main components of this system and their respective positions are detailed under chapter „Gas System Galley“. The gas bottles dedicated stowage is in the locker next to the port helm. The gas system complies with the standard EN ISO 10239. Please make sure that the regulations of your flag state are also complied with. Have repairs and work on the gas system executed by adequate personnel only. Any changes to the system must be documented in this manual. The gas stowage compartments drain towards the outside, make sure these drains are not obstructed. Also water may drain through the same opening. The locations of the key components and controls are listed below. Control device Installation position Valve On the bottles neck GOK- Low pressure regulator at the Gas cylinder (bottle) with GOK-Low pressure regulator (Deck, Gas box in wet bottle bar) Check valve In the locker in front of the respective consumer appliance (see pictogram or label on the outside) Manual check valve On the respective consumers/ovens/grills/stoves etc.
  • Page 40 Owner‘s manual Caution » Never use the gas locker to store other parts or hardware. » Never leave craft unattended when LPG consuming appliances are in use. » W hen having the gas system on board the camper cover may not be altered in any way, espe- cially not sealed more than it was when delivered. » Do not change/alter the gas box/locker; Never puncture the gas box and lead pipes through into the interior of the boat. » Never install electrical appliances or wiring in the gas box/locker. Warning »...
  • Page 41 Systems (some are optional only) 6.9.3. Procedure to be followed when replacing a gas bottle Caution » Never drop a gas cylinder. During transport, the valves of the gas bottles must be protected by caps. » Use a special vehicle for transportation of these bottles. Always fasten and lock gas bottles in place. » Close the aft saloon sliding door tight when exchanging bottles, ensure good ventilation. Danger » Be sure that all gas in the system has been burnt off before opening the valve at the cylin- ders head.
  • Page 42 Owner‘s manual 6.9.4. Inspection of the gas system Test the LPG system for leakage regularly. Check all connections for leakage by: 1. Routine checks with a leak detector 2. Manual leak testing: Testing with soapy water or detergent solution (with appliance-burner valves closed and cylinder and system valves open) Caution » LPG lines must be inspected regularly, at least annually, and replaced if any deterioration is found. » If leakage is present, close the cylinder valve and have the system repaired before further use. Gas system repairs should only be executed by a competent person. » To be able to check the gas connections at the stove the front covers must be removed. Danger »...
  • Page 43 Systems (some are optional only) 6.9.5. Gas system galley (Notations see „Notation of the main decks gas system components“ below) 6.9.6. Detail cutout view galley 6.9.7. Notation of the main decks gas system components Pos. Description Rubber hose (Gas box) 6 bar GOK-Low pressure regulator Gas box, drained Angled fixture at bulkhead /Adapter straight galvanised Fixture at bulkhead/ Adapter Rubber hose Gas cook top / Gas oven Valve TRUMA (in locker) Copper pipe 8 mm...

  • Page 44: Side Thrusters (Options)

    Owner‘s manual 6.10. Side thrusters (Options) Thruster Power source Bow thruster Battery forward *is also supplying the windlass fwd. Stern thruster Additional battery aft under the port bunk in the aft cabin, this battery and the thruster are only installed as part of the dock control system The bow thruster may be controlled from the starboard steering position via the control panel, see the panel and the separate instructions that are incorporated within the documentation of the boat. Caution » With people on the fore deck it is extremely important and advisable to inform them before using the bow thruster.
  • Page 45 Systems (some are optional only) 6.11.2. Drawing of the waster water systems layout and components...

  • Page 46: Heads And Waste Water

    Owner‘s manual 6.12. Heads and waste water Head Possibility of discharge Valve positions Day head starboard, to be accessed via Waster water via discharge The valve is accessible via the hatch un- companionway outboard or suction through der the wash basin tank & deck fitting Forward head, starboard (Option) Waster water via discharge The valve is accessible via the hatch un- outboard or suction through der the wash basin deck fitting...

  • Page 47: Emergency Steering

    Systems (some are optional only) Information The boat‘s steering system has the following components: » The boat is being steered via one of the two steering wheels in the cockpit » The steering impulses are transmitted via cable links to the rudder shaft. » Please make sure the mechanical components may work unobstructed and that items stored in the aft compartment are securely fixed in order not to fall into the steering sys- tems components.

  • Page 48: Storage Of The Emergency Tiller

    Owner‘s manual 6.15. Storage of the emergency tiller The letter T denotes the place where the emergency tiller in stored. The emergency tiller is stored in the large aft locker under cockpit sole level, it is accessible via the deck hatch that is situated in the passageway from the cockpit to the aft lowered platform. The tiller is mounted transversally on a raised position. The optimum steering position is probably being seated on the aft cockpit lockers, legs braced sideways to give a good stableness.

  • Page 49: Anchor Windlass

    Systems (some are optional only) 6.16. Anchor windlass The craft is fitted with a powered anchor windlass on the foredeck, the attached chain is lead under deck in the chain locker situated fwd. The windlass control is connected via a spiralling cable with the windlass, this control unit is stored in the chain locker at the very front end, suspended under deck level. Windlass Power source Windlass forward (Option) Battery below the fwd. double bunk, stb side Caution Winches and windlasses generate large forces. Bear in mind the following: » Keep hands and feet away from the windlass and the lines or chain. » Have only experienced crew operate the windlass. » Prevent accidental pressing of switches. Information »...

  • Page 50: Fresh Water System

    Owner‘s manual 6.17. Fresh water system The yacht is equipped with two fresh water tank, with a combined capacity of ca. 580 Liter, situated in the bow below the salon floor boards. The filler is situated on the starboard side deck. The cap displays the marking (WATER). Water extraction from the tanks is via plastic tubing leading to a fresh water pressure pump. The system is always set under pressure. Should the pump keep on pumping even after you close all appliances, then you should check the tubes and fittings for leakage. The pump itself is protected by a filter, check this filter regularly, if necessary clean the filter. 6.17.1. Fresh water system component plan Pos. Description Fresh water filler (Deck) Fresh water pump Cockpit shower Wash basin...

  • Page 51: Navigation And Handling

    Navigation and Handling 7. Navigation and Handling 7.1. Operation of the engines The installed engine on board is a Volvo Typ D2-55 with a saildrive gear and drive. The standard propeller is a 3-blade prop! These systems are highly efficient and complex – please observe the manufacturers guide and recommendations. Have your dealer explain these systems, if in doubt, please ask. Your local Yanmar-Expert is happy to assist, even via telphone. The Yanmar manual is provided in English, it is part of your documentation, if it is not, you may find it here: http://www.volvopenta.com Or call the local Volvo Penta representative to assist. Check fuel lines for damage & leaks. Do not damage fuel lines, check their condition periodically. Never place flammable material on top or in the vicinity of hot parts. Warning » In order to avoid touching and being hurt by high-speed moving parts, never run a motor with the cover removed. » So as to avoid moving parts, never access the engine space when engines are running. » Never remove the guards from moving parts of engines unless the engine is not running. Information - before starting the engine »...

  • Page 52: The Peripheral Equipment - A List

    Owner‘s manual 7.2. The peripheral equipment - a list Pos. Description Engine Volvo Penta Exhaust system propulsion engine Volvo D2-55 or alternatively D2-75 Waterlock Diesel feeder line Diesel return line Diesel- filler Tank vent Diesel filter Fuel solenoid valve Ventilation engine room, intake and discharge aft Engine controls (Deck) Fuel tank gauge Water seperator/ seacock engine Vakuum valve engine Ventilation engine room Engine coolant - compensating reservoir of 7.2.1.
  • Page 53 Navigation and Handling 7.2.2. The engine, tank and exhaust system in plan view 7.2.3. Exhaust system This yacht has been equipped with a wet exhaust system, sea water is being injected in the exhaust manifold. It cools down and binds the exhaust gases. This mixture is then lead into the water trap/silencer, is then lead aft and exits the boat aft above the water surface. The exhaust pipe is made from synthetic rubber and reinforced with a metal spirale. This hose is heat resistant to a certain degree. The sea water supply must be compromised. Ensure unrestricted flow in this sea water system. The connections are all clamped with two hose clamps. Should the water flow be interrupted and the temperature rises, the systems alarm will activate an optical and acous- tical alarm.
  • Page 54 Owner‘s manual 7.2.4. Propeller Information In case a folding propeller is used, the gear transmission has to be in reverse gear when sailing. With a fixed propeller used it has to be in reverse or neutral gear. A fixed propeller on reverse produced an extra bit of drag, but causes less noise Caution » In order to avoid touching and being hurt by high-speed moving parts, never run a motor with the cover removed. » So as to avoid moving parts, never access the engine space when engines are running. » Never remove the guards from moving parts of engines unless the engine is not running. » Reduce your speed when navigating at high traffic, with limited visibility, rough water, people or structures in the water nearby. »...

  • Page 55: Visibility From The Main Steering Position

    Navigation and Handling 7.3. Visibility from the main steering position The international regulations for preventing collisions at sea (COLREG‘s) and the rules of the road require that a proper lookout be maintained at all times and observance of right of way. Make certain no other vessels are in the path before proceeding. Operator vision from the helm can be obstructed by high trim or heel angles of the craft and other factors caused by one or more of the following conditions: » Hull trim angles »...

  • Page 56: Navigation Lights

    Owner‘s manual 7.5. Navigation lights The boat is equipped with navigation lights required by the international regulations for preventing collisions at sea (COLREG‘s) and the rules of the road. Observe local regulations. Information Night boating requires running lights. The craft is fitted with the following navigation lights. The navigation lights are switched from the helm command. » STB side navigation light » Port side navigation light »...

  • Page 57: Anchoring, Mooring & Towing - Security Advice

    Navigation and Handling 7.6. Anchoring, Mooring & Towing – security advice Caution - To anchor - being towed - on a mooring Should your yacht be towed by another yacht, make sure the load is evenly distributed on the two forward cleats. Use the same system on a mooring. The bower anchor is located in the bow fitting ready to fall. The chain runs over rollers into an electric anchor windlass, then drops into the anchor locker. The chain is securely fastened here. To adequately moor the vessel the boat has been equipped with cleats at the bow, the stern and on the side decks, the cleats are sufficiently backed by laminate to fulfil the requirements of the directive and to take the loads while moored in a save haven. Should you leave the boat unattended for longer periods, secure the mooring lines against chafe or unintentional loosening. As an option you may have stern windlasses at your disposal – read the respective manuals for safe operation. Information » It is the owners / operators responsibility to ensure that the mooring lines, towing lines, anchor chains, and anchors are adequate for the vessel‘s intended use. Owners should also consider what action will be necessary when securing a tow line on board. » The breaking load of the forward cleats for towing and mooring on an anchorage has been established to be 51,6 kN. This corresponds to a horizontal tow of ca. 5260 kg.

  • Page 58: Preventing Collisions At Sea

    Owner‘s manual 7.7. Preventing collisions at sea The international regulations for preventing collisions at sea (COLREG‘s) and the rules of the road re- quire that a proper lookout be maintained at all times and observance of right of way. Make sure no other vessels or other obstacles are in the path before proceeding. 7.8. Refuelling Information - respect the following when filling the fuel tank »...

  • Page 59: General Considerations

    General considerations 8. General considerations 8.1. Recommended safety equipment BAVARIA Yachts are generally delivered without any safety equipment. It is the duty of the boats captain to ensure that adequate and sufficient equipment is stored on board. The security equipment must be surveyed and checked in regular intervals and before you embarque on a trip. Check its completeness, their proper function and that the equipment is ready to be used instantly. Local authorities, national and international watersport organisations and federations will happily assist you in gaining information about the security equipment needed for the type and size of your craft in the area you intend to navigate in. The sea is unpredictable. Therefore you should close all hatches, portlights and the companionway covers when under way.

  • Page 60: Rough Weather Conditions - Measures To Be Taken

    Owner‘s manual 8.2. Rough weather conditions – Measures to be taken » In bad weather conditions nobody should stay on open deck spaces that are not appropriately secured. » In rough weather, hatches, lockers and companionway/doorways through which water could be enter should be closed to minimise the risk of water ingress. All appliances and parts needed for those openings to be closed should therefore be on board, in good working condition, ready to be used. » All openings that are watertight, slash tight or weather tight should be closed when under way – except the open- ings needed for the safe operation of the craft. It should be possible to close those openings easily at any time. »...

  • Page 61: Risk Of Loss Of Stability

    General considerations 8.5. Risk of loss of stability The stability and buoyancy characteristics of this boat have been assessed on the basis of the weights specified in the section weights: Caution » The boat should never carry more than the manufacturer‘s recommended load. » Bear in mind that stability is most significantly reduced by any weight added high up in the boat. Distribute the load as to make sure the boat floats on level trim. » Stability and your security may be adversely affected by sloshing fluid such as water, check bilge water levels at a regular basis. » The boat may experience extreme motions and accelerations when performing wrong or mistaken maneuvers.

  • Page 62: Man-Over Board (Mob) - Risk Of Falling Overboard - Reboarding

    Owner‘s manual 8.6. Man-over board (MOB) – Risk of falling overboard - Reboarding The working deck area is always a safe place to operate from. Areas outside the specified working deck should only be used whilst leaving or arriving at a mooring or whilst the boat is not underway. On this boat, the working deck area is marked in green in the below plan view of the deck. The area in red is slippery due to the installed glazing in this area. The working deck is defined as the cockpit and the side decks on main deck level without the aft platform. The top of the coach roof (cabintop) and the aft platform are not part of the working deck. Most man-over-board incidents are due to slippery surfaces and happen while boarding or leaving the craft.

  • Page 63: Reboarding Devices

    General considerations 8.7. Reboarding devices Man over board (or MOB) manoevre includes all possible measure to rescue the person fallen over board from a vessel. The manouvre has to be executed instantly and always has the first priority. This manouvre is a fundamental part of good seamanship and has to be trained with every new boat and crew. The primary reboarding device on the BAVARIA Cruiser Yacht is the bathing ladder, see the position on the below dra- wing, it pictured here in the final deployed position. Please be aware that these drawings do not reflect the geometry of your specific boat, but are generic drawigs illus- trating the concept. The ladder may not be installed or deployed by a person in the water, in case the platform is not lowered and/or the fixed ladder is not mounted yet BAVARIA YACHTS has installed a rope ladder that might be deployed by removing the grey cap and the pulling out the three-step-ladder. The handholds further help when reboarding The ladder is only operable with the platform re- leased in the lower position. You must release the line that is normally jammed in a cleat on the aft...
  • Page 64 Owner‘s manual 8.7.1. Rope ladder in quiver The following drawings illustrate the use of the rope ladder installes at the transom at stb side, the following figures are generic drawings that differ significantly in details of your specific yacht but illustrate the concept very well. This rope ladder fulfil the requirements set out by the recreational craft directive I and II as is is deployable from a person in the water unaided. With the additional handholds just above the ladder itself the rebording is possible. Drawing No.1: The cover of the ladder is unscrewed with a finger and pulled out of its container/quiver Drawing No. 2 & 3 : Now the ladder may be removed and used to return aboard Please do also use the headband as per drawing to hold onto. These above images are generic sketches that do not comply in every detail with the Cruiser Yacht.

  • Page 65: Overview Aft Deck With Swim/Rescue Ladder

    General considerations 8.8. Overview aft deck with swim/rescue ladder The platform may be lowered by slackening off the release line (pos A). Caution » Stop the engines before using the ladder. Due to the suction the person at the platform may be sucked under the platform and into the props. » Also the pitching motion may be dangerous for a person under the platform. Be advised, that it might be good practice to use a dinghy for a rescue activity. »...

  • Page 66: In General

    8.10. In general A BAVARIA Vision 46 is a powerful vessel. Therefore it should only be handled by trained and experienced helmsmen. Do not leave unreliable people or children without supervision on board. The cabin rooftop with its glazed areas and the aft platform are not part of the working deck. Always switch off the engine controls on the main switch board...

  • Page 67: Protective Baskets Or Nets

    General considerations 8.12. Protective baskets or nets » Bilge pump intakes inside the boat, and intakes of water from outside the boat are fitted with protective baskets to avoid blockage by weed, leaves or other debris. Ensure these are kept clear at all times. 8.13. Risk of fire Our commitments regarding fire prevention has started during the conception and the design of the boat. We choose materials and equipment with a strong focus on preventing and restaining fire risks, this comprises the insulation of the engine room with fire-retardant material, the design of the galley etc. As a resposible and sensible skipper you should adopt the following rules: » Always keep the bilges clean and check for fuel fumes and smell regularly. Caution - Never..» obstruct portable extinguishers in lockers or doorways and lockers that contain equipment which is relevant to the boats security (such gas appliances etc.), controls (shut off valves, switches).

  • Page 68: Fire Fighting Equipment

    Owner‘s manual 8.14. Fire fighting equipment Locations and capacity of extinguishers are given below. It is advisable to produce copies of these drawings and display them in the respective cabins. Please pay attention to the specific manuals of the different extinguishers and fire fighting systems installed. Caution - It is the boat owner/operator‘s responsibility to: » check equipment at intervals as stated on equipment. » replace any extinguisher, if used, with one of same rating and the same make » make sure all extinguishers are freely accessible »...

  • Page 69: Escape Routes

    General considerations 8.15. Escape routes Information » Exits other than the main companion way & hatches with ladders are labeled. » It is advisable to have those plans also as a copy in each cabin, for the crew to be able to read and know about the escape possibilities. Caution - It is the boat owner/operator‘s responsibility to » inform crew of the location of routes and exits. » check the labeling of the escapes and special equipment such as ladders or steps regularly. Warning »...

  • Page 70: Grounding

    Owner‘s manual 8.17. Grounding Caution - in case of grounding » Never obstruct exits and escape routes! » Check for leaks on the entire hull, first at bilge level, the keel and the rudder shafts and in particular at those places where hull fittings and openings have been fitted (Propulsion, sea cocks etc.). » Return to port immediately and drive at reduced speed, reduce sail area, avoid vivid dynamic movements and accelerations » Check the appendages and openings and structure again when returning to port » Have the boat inspected on the dry thoroughly 8.18.

  • Page 71: Life Raft

    General considerations 8.18.1. Positions of through hull fittings (this drawing includes the options) Information - Maintenance With ball valves it is relatively easy to know if they are open or closed: 1. CLOSED: The handle points at a right angle to the pipe or hose 2. OPEN: The handle points in the direction of the pipe or hose »...

  • Page 72: Cockpit Layout With Designated Life Raft Locker Spaces

    Owner‘s manual 8.20. Cockpit layout with designated life raft locker spaces 8.21. Transport, hoisting, slip and storage The Vision 46 is designed to perform on the water but may be transported on a trailer on the road. She will need special transport, it is advises to employ a specialist company with a suitable vehicle. Many marinas and servicing companies hoist the boats using a crane and hoisting gear or a travel lift. Please make sure a a transverse cross beam is used to hold the slings apart so that transvers forced are reduced. Caution »...
  • Page 73 General considerations 8.21.1. Hoist: Many marinas and servicing companies hoist the boats using a crane and hoisting gear or a travel lift. Ensure that the slings are placed according to the boats structure and the weight balance of the boat. The boat should hang level keel in the crane, at the same trim as it would float in the water. Should you be using the same crane with slings regularly, then it is advised that you mark the sling positions on the craft at the deck edge.

  • Page 74: Maintenance

    Owner‘s manual 9. Maintenance Caution » Modifications that may affect the safety characteristics of the craft should be assessed, executed and documented by competent people. » Any change in the disposition of the masses aboard may significantly affect the stability, trim and performance of the boat 9.1. Maintenance of the electrical system Information » Check all terminals for corrosion - corroded terminals and connectors should be replaced or thoroughly cleaned.

  • Page 75: Maintenance

    Maintenance 9.2. Maintenance Cleaning Clean and rinse the boat possibly just after you take out of the water. You may remove marine growth from your boats bottom very effectively with a high pressure cleaner. Different cleaning and caring agents are available for the maintenance of the boats surfaces. For boats navigating in sea water: Salt attracts water from the environment, this speeds up corrosion. Whenever possible the boat should be rinsed with fresh water. Do only utilise biodegradable detergents. Do not use abrasive cleaning agents they scratch and bleech the surfaces. Clean heavy soilings with fresh water and care products. To clean off stains of lime (dried out water), use vinegar.
  • Page 76 Owner‘s manual Maintenance of stainless steel parts The corrosion resistance of stainless steel fittings is based on their ability to constitute a thin skin together with the air, which constitutes a positive electrical potential. Specialists call it CR-passivated (CR stands for chrome). But chrome is negative and a bit less noble than iron in the electrochemical series. If this thin protection skin is damaged the stainless CR gets reactive and less noble than pure chrome. The corrosion then starts. Were you ever annoyed by these little brown spots on the fittings? They are caused by flying rust or particles of iron scale, which are contained in the air and near big towns. As soon as the flying rust settles onto the protective layer of the stainless steel, it destroys the CR-passivity very aggressively and fast.

  • Page 77: Winter Storage

    Maintenance 9.3. Winter storage The boat and its systems may be harmed if you do not cater for the winters cold period. We have already covered issues on winter storage in different paragraphs of this manual. Generally speaking: Companies offering winter storage services should apply latest technological standards. This includes environmental conditions, storage cradles, fire protection and accessibility of your yacht. The work carried out by the owners them- selves should be covered and ruled in order to prevent any interference between the parties.
  • Page 78 Owner‘s manual The winter storage and the associated works on the engine should generally be covered by a specialist, but the follow- ing should be done as an absolute minimum. » Fill the diesel tanks to reduce the effects of condensation » Check the sacrificial anodes and replace as necessary » Empty all cooling-water of the engine and follow the instructions of the manufacturer, add the recommended amount of antifreeze. » Slacken all V-belts (alternator and other engine driven devices). Mast and rigging: It may not always be possible, but it is recommendable: » Lay the mast » Refit all standing and running rigging, » Inspect the cables and other wires, »...

  • Page 79: The Protection Of The Environment

    The protection of the environment 10. The protection of the environment We did our best in building the boat with the least environmental footprint. There are a number of regulations and hints regarding the protection of our environment, may we kindle ask you to respect those while enjoying your boat. In the following paragraphs we do list some special helpful hints for the use of your boat which is compatible with the environment.
  • Page 80 Owner‘s manual Antifouling coatings The surfaces of a boat immersed in water have to be protected with an antifouling coating since marine growth slows the boat down. Today we have access to a wide range of protective coatings with various effects for different sailing areas and water qualities.

  • Page 81: Final Remarks And Notes

    Final remarks and notes 11. Final remarks and notes This manual fulfills the requirements of the harmonised European Standard EN 10240. Much of it shall be self evi- dent. Nevertheless we do hope that dealing with the different chapters of this manual will help you to understand the technical systems and the ideas of the boats concept. As already mentioned in the introduction, the purpose of this manual is to display the information set out by the requirements of the recreational craft directive. Among the things that are not dealt with is the personal safety equipment. This belongs to the domain and the respon- sibilities of the skipper alone. It should be self-evident that a sufficient number of personal life saving equipment are carried on board. This also includes the procurement and maintenance of a life raft, of distress signals and flares, a...

  • Page 82: Proof Of Identity/Acknowledgement Of Receipt

    Owner‘s manual 12. Proof of identity/Acknowledgement of receipt (to be completed by the contracting party) First put into water Date (Delivery to the customer) BAVARIA Vision 46 Type and Version of the craft DE-BAV D46 Commission number Name of the Yacht: Engine (Make, Type): Engine number Gearbox (Make, Type, Reduction ratio) Propeller (make, type, dimensions) Dealer Signature : ..................... Dealers stamp The above acts as a representative of our company, granting you the necessary help, should any problem arise. Shortly after ownership of the boat has been transferred you should complete this acknowledgement of receipt and hand it...

  • Page 83: Acknowledgement Of Receipt

    Acknowledgement of receipt 13. Acknowledgement of receipt At this place you should find a post card glued to rectangular placeholder. Should this post card be removed, please ask your dealer to copy this page and hand the copy over to you, so that you may fill and sign the copy. Acknowledgement of receipt for this owner’s manual: The owner of a new boat is obliged to sign an acknowledgement of receipt for this manu- The undersigned herewith confirms the receipt of the owner’s manual and the respective pertinent documentation for the equipment which have been delivered with the boat. DE-BAV D46 CIN number: Name: ____________________________________________ Adress: ___________________________________________...

  • Page 84: Notes

    Owner‘s manual 14. Notes...
