- Page 1 Important: Read this whole manual before assembling Engage Interact Satisfy Owners Manual for Document Kiosk with WiFi, Mag Strip Reader, VOIP and/or printer options. AK-DK-OM-5/23/2019...
-
Page 2: Table Of Contents
Equipment Manuals ..........................16 ..........................17 OLVING ROBLEMS Troubleshooting Tips ...........................17 MAINTENANCE OF KIOSK ........................18 .........................18 LEANING AND AINTENANCE Touch Screen ............................18 WARRANTY ...............................19 ..............................19 OLICY Limited Warranty ..........................19 Returned Item ............................19 Shipping ...............................19 5/23/2019 Document Kiosk Assembly and Operation Instructions www.advancedkiosks.com... -
Page 3: Introduction
• Do not use kiosk with an extension cord that does not have grounding. • The Document Kiosk has been designed for indoor use only. Outdoor use to the Document Kiosk may result in damage to the kiosk, or injury to persons. - Page 4 5/23/2019 Document Kiosk Assembly and Operation Instructions www.advancedkiosks.com...
-
Page 5: Our Support
Our Support The Document Kiosk is a reasonably priced, high quality kiosk. We are happy to help you with any problems after you have read the manuals to learn about this product. Advanced Kiosks will support you in ownership as long as you own your kiosk, within reason. -
Page 6: Installation
Installation Installing the Kiosk One of the unique features of the Document Kiosk is that it can be secured to the ground, the wall or left free standing. Location The location for the kiosk should not be in an area where a heating vent is directly venting on the kiosk and is level. - Page 7 Use the allen head screws + allen wrench to attach to kiosk. (Note: Kiosk standard color is black. White kiosk is used for clarity) Wall Mounts Facing Inward Wall Mounts Facing Outward 5/23/2019 Document Kiosk Assembly and Operation Instructions www.advancedkiosks.com...
-
Page 8: Earth Quake Zones
Earth Quake Zones The Document kiosk is a freestanding unit but for those that are located in an area prone to earthquakes it is recommended that a professional engineer review the mounting for the codes in your area. Also note the following. -
Page 9: Installing Optional Equipment
Installing Optional Equipment Printers A variety of printers can be housed in the Document kiosk. It is recommended that a small laser printer type is used. These use toner as a print medium rather than ink that can spill. The printer that is shown in the drawing below is the OKI B410 monochrome laser printer. -
Page 10: Setup And Operation
The kiosk is shipped with a full, standard installation of Windows 10 Professional. See our Quick Start Guide for software setup located at https://advancedkiosks.com/about- advanced-kiosks/product-documentation/ Assembly of the Kiosk The Document Kiosk has two main sections. The Head area and the Printer area. Assembled Views 5/23/2019 Document Kiosk Assembly and Operation Instructions www.advancedkiosks.com... -
Page 11: Head Area
In this area you have access to the monitor controls, keyboard, computer and other peripherals. Kiosk With Front Face Open Vibration Mounted Computer Note: Do not overtighten the vibration mounts, only hand-tighten. 5/23/2019 Document Kiosk Assembly and Operation Instructions www.advancedkiosks.com... -
Page 12: Computer
• Speaker – USB and 3.5 mm plug to USB - Credit Card Reader • Keyboard – USB - Handset • Power Cable - Scanner • Wi-Fi - Camera - Finger print reader Note: Our kiosks come with all cables labeled. 5/23/2019 Document Kiosk Assembly and Operation Instructions www.advancedkiosks.com... -
Page 13: Startup
Turn power strip under the printer shelf “ON”. Turn the computer power switch “ON”. Adjust the speaker volume with Windows control panel. Wi-Fi is standard with the Document Kiosk and will arrive installed; however, you will need to configure the settings to connect with your network. -
Page 14: Specifications
1 x Headphone Jack 2 x USB Back Panel I/O 1 x D-Sub 1 x HDMI 1 x LAN (RJ45) Port 4 x USB 1 x Power Port Operating Temperature 50ºF ~ 95ºF 5/23/2019 Document Kiosk Assembly and Operation Instructions www.advancedkiosks.com... -
Page 15: Power Requirements
If you are planning on adding graphics to the kiosk use the dimensions from the customer drawing to size your graphics. These are all in inches, call us if you need more information. Customer drawing can be accessed from: https://www3.advancedkiosks.com/hubfs/Drawings/Document_Kiosk_DD.pdf 5/23/2019 Document Kiosk Assembly and Operation Instructions www.advancedkiosks.com... -
Page 16: Equipment Manuals
Equipment Manuals With your Document Kiosk, all the software and documentation for all your components has been included. Please keep these in a safe place. We recommend you write down the serial number and other useful information for future reference. -
Page 17: Solving Problems
USB cable is making good connections at the computer and monitor. Drivers can be accessed at our website by completely filling out the Technical Support Form. See our support section for our knowledge base and our support ticket creator. 5/23/2019 Document Kiosk Assembly and Operation Instructions www.advancedkiosks.com... -
Page 18: Maintenance Of Kiosk
Use a mixture of warm water and dish soap to gently clean the outside of the enclosure. Use a soft cloth and avoid excess scrubbing. DO NOT wipe down any electronics (keyboard, credit card reader, etc) with a wet solution. 5/23/2019 Document Kiosk Assembly and Operation Instructions www.advancedkiosks.com... -
Page 19: Warranty
The electronics in the kiosk are guaranteed for 3 years including the monitor. In the case of any item not working you must call Advanced Kiosks to obtain an RMA # before shipping back the item. All items must be well packaged for return shipment and insured for their full value.
