Gecko SC-MP-AR1 Quick Reference Card

The Quick Reference Card provides a quick overview of your spa's main functions and the operations accessible with
your digital control pad. Note: Functionality depends on system configuration (system can also be equipped with a K-19).
Starting Pump 1:
Press Jet 1 to turn pump 1 on at low speed. Press a
second time to turn pump 1 to high speed. A third
time turns pump 1 off. A built-in timer turns pump 1
off after 30 minutes, unless it has been manually
deactivated first.
The "Pump 1" indicator lights up when pump
is on. It flashes when pump 1 is on at low
speed.
Starting Pump 2:
Press Jet 2 to turn Pump 2 on. Press a second time
to turn Pump 2 off. A built-in timer turns pump 2 off
after 30 minutes, unless it has been manually
deactivated first.
The "Pump 2" indicator lights up
when pump is on.
Starting the blower:
Press Blower to turn blower on. Press a second
time to turn blower off. A built-in timer turns
blower off after 30 minutes, unless it has been
manually deactivated first.
The "blower" indicator lights up
when blower is on.
Turning the light on:
Press Light to turn light on. Pressing a second time
turns light off. A built-in timer automatically turns light
off after 2 hours, unless it has been manually
deactivated first.
The "Light" indicator is displayed
when light is on.
SC-MP-AR1
QuickReferenceCard
Setting water temperature:
Use Up or Down arrow key to regulate water
temperature. The temperature setting will be
displayed for 5 seconds to confirm your new
selection.
The "Set Point" indicator displays the
desired temperature, NOT the current
water temperature!
Water temperature can be adjusted by 1˚
increments from 59 to 104˚F (15 to 40˚C).
Automatic water heater start:
When water temperature is 1˚F (0.5˚C) lower
than the Set Point, the heater will automatically
turn on until water temperature reaches Set Point
plus 1˚F (0.5˚C).
The "Heater" indicator lights up when
the heater is on. It flashes when there
is a request for more heat but the heater
has not yet started.
N.B.: If your system is configured in Low Current
Mode, the heater will not start if both pumps are
running at high speed.
Digital control pad lockout:
This function allows you to prevent unauthorized
parameter setting of the unit. This feature is
especially helpful when young children have access
to the keypad.
Locking your digital control pad:
1-
Press and hold Pump 1 key for10 seconds.
2- The display will show Loc
3- Press and hold Pump 1 key again
for 10 seconds to unlock keypad.
The display will show Ulc to confirm.
When control pad is locked, all keypad functions are
locked, except the light and pump 1. All automatic
functions of the system run as usual.
