  • Page 1 XAIRCRAFT X600-D Assembling Manual V0.3...
  • Page 2: Table Of Contents

    目录 Packing Description ....................... 3 Structure design of X600-D ....................5 Technical Specification ......................6 Before assembling ......................... 6 Install Motors .......................... 6 Install ESC board ........................8 Install Fuselage ........................10 Install Flight Control Board ....................12 Install Receiver and Battery....................13 Install Propeller .........................
  • Page 3: Packing Description

    1. Packing Description All the packing material for X600-D are environmental materials, you can fold for depositing facility after final assembling, or take-out for flying outdoors . There are three packages A,B,C in the box ,including a piece of high quality color...
  • Page 4 Inner of package A Inner of package B Inner of package C Package of PCB board...
  • Page 5: Structure Design Of X600-D

    2. Structure design of X600-D Front Left Right Back USELAGE PPER LATE ECEIVER (ESC) LECTRONIC PEED ONTROLLER OWER USELAGE OWER LATE LOCKWISE ROPELLER LIGHT ONTROL OARD LOCKWISE ROPELLER OTOR NTENNA OLDER...
  • Page 6: Technical Specification

    3. Technical Specification 1. Motor diameter: 250mm 2. Fuselage dimension: (distance between motor shaft): 600×600mm 3. Empty weight: (without battery and receiver) 620g 4. Batter requirements: 3S(11.1V)15C/2200mAh 5. Radio and Rx: Compatible with 4ch PPM,PCM,2.4GHz PCM of many type 4. Before assembling The package is furnished with two alley key for assembling, in addition you need prepare needle nose plier ,straight screwdriver 5.
  • Page 7 lease notice the three distinction between parts,choose the first one for installing motors ② ① ① ② ② is shorter than① The length of two holes of ①is shorter than② Long pitch-row Short pitch-row Fasten the motor mount with motor shaft until 2 Fix the two black grub screws into the slit no gap of the motor mounts...
  • Page 8: Install Esc Board

    3 Please be careful when assemble head screw 4 Turn around the motor to check the through pole of the motor arms with Allen key, smooth of rotation ,pay particular attention bypass the electric wire in the arm. that whether any tiny screw attached to it 5 Finished motors is as follows , the yellow one is head 6.
  • Page 9 Double heat sink 6 Open the package of heat sink and conducting Attach the two heat sink with heat silicon. conducting silicom. 8 Fix the heat sink (among with rounded 9 Notice the white arrow on the ESC board as the hole) above the bottom with 20mm white head direction nylon screw...
  • Page 10: Install Fuselage

    hole )above the top of ESC board washer when installing the heat sink 7. Install Fuselage Spare Parts List: Product ID Goods& Description Package A,FUP Fuselage Upper Plate Package A,FLP Fuselage Lower Plate Package A,FVF Velcro Fastener Package C,FAH Antenna Holder Package C,PAHMM5 Antenna Holder Nut Package C,FAMBI...
  • Page 11 Front Left Right Back 14 let the motor arm go through the Arm Mounting Bracket Inboard, fix the three electric wires into the green ?? ,connect the motor wires with ESC board, connection order clockwise :yellow, black, red 15 screw the four nylon pillars on to the upper cover 16 Connect the lower cover with the frame that have been installed...
  • Page 12: Install Flight Control Board

    17 The top view of the fusage after installtion 18 The top view of reverse side ,notice that the power wire go through the squre hole of the lower cover 8. Install Flight Control Board Spare Parts List: Product ID Goods&...
  • Page 13: Install Receiver And Battery

    21 Fix the flight control board on the four nylon pillars .Ensure the white arrow on the board is facing toward towards the yellow motor arm. The follow-up operation can be choose after the PC tools setting ,please refer to the document “XAircraft Tools Manual ” 9. Install Receiver and Battery Spare Parts List:...
  • Page 14: Install Propeller

    The black wires ←CH1 ←CH2 ←CH3 ←CH4 ←CH5 ←CH6 24 Check the order of the channels 25 Choose whether connect steering engine to meet flight needs 26 Fix the battery below upper cover using the antenna into antenna Velcro fastener tightly holder ,and wind the wire around the antenna...
  • Page 15: Test Motors

    XAIRCRAFT Anti-Clockwise Propeller 28 There are two kinds of propellers, where the XAIRCRAFT logo is on the upper side of the propeller this is an clockwise propeller, where the XAIRCRAFT logo is on the lower side this is a anti-clockwise propeller...
  • Page 16: Package List

    12. Package List X600-D 装箱单 Package List 箱号 序 商品编码 规格 数量 Package 号 品名 Goods&Description 单位 Product ID Spec 机身上板 Fuselage Upper Plate 片 机身下板 Fuselage Lower Plate 片 接收机固定板 Receiver Platform 片 扎带 Velcro Fastener 条 FNSS 尼龙条脚架...
  • Page 17 箱号 序 商品编码 规格 数量 Package 号 品名 Goods&Description 单位 Product ID Spec PFCWM303 飞控板垫片 Flight Control Washer M3×3mm 个 PHSM217 内六角螺丝 Hex Socket Head Screw M2×17mm 个 PHSM225 内六角螺丝 Hex Socket Head Screw M2×25mm 个 PAHMM5 螺母 Antenna Holder Nut 个...
