OWNER'S MANUAL
LAWN MOWER
Before operating the mower for the first time, please read this
Owner's Manual. Even if you have operated other mowers,
take time to become familiar with how this mower works and
practice in a safe area until you build up your skills.
20
Oil Change.................................................
6
Oil Level Check............................................
19
Spark Plug .................................................
12
Warranty Coverage....................................
9
TROUBLESHOOTING...............................
9
Engine Will Not Start ..............................
Loss of Power.........................................
11
Vibration .................................................
11
12
13
TECHNICAL INFORMATION ....................
13
Serial Number Locations ........................
13
High Altitude Operation ..........................
14
Specifications .........................................
14
15
CUSTOMER INFORMATION ....................
15
15
Dealer Locator Information.....................
16
How to Contact Honda ...........................
16
Honda Publications ................................
16
SERVICE RECORD...................................
16
LIMITED WARRANTY ...............................
16
16
17
17
HRN216VYU
14
6
15
23
17
17
17
17
17
18
18
18
18
19
20
20
20
20
20
21
23
