Bosch TDA56 Series Operating Instructions

solving Minor Problems Yourself
Problem Possible Causes
Iron does not Temperature control (H) set
work or is not to minimum.
heating up
Connection problems.
The automatic shut-
off system has been
activated.*
Iron is not There is no water in the
steaming tank (D)
The steam regulator (A) is
in the position
Temperature control (H)
setting is too low.
Steam regulator (A) is set
too high in conjunction with
a low temperature.
You have pressed the
shot of steam button (L)
Water is
repeatedly without waiting
dripping
for 5 seconds between
from the holes
each press.
in
Water has been left in the
the soleplate
tank (D) when the sole p late
was cold, with the steam
regulator (A) set at or .
Distilled water has not
been used (see "Filling the
water tank" section) or other
products such as fragrant
water have been added to
the tank.
No water in the tank.
Spray does
not work.
Obstructed mechanism.
During first use: Certain
The iron components on the
begins to appliance have been lightly
smoke when greased at the factory and
switched on. may produce a little smoke
when initially heated.
Deposits Traces of lime scale are
come out coming out of the steam
through the chamber
holes in the
soleplate.
Auto-shut off has been
Flashing lamp
activated.
on top of
handle.*
* Model dependent
Thank you for buying the TDA56 steam iron from Bosch.
This iron has been designed according to ecological criteria,
related to the sustainable development; analyzing its whole
lifecycle, from material selection to its later reusing or recycling;
evaluating the improvement possibilities, from a technical,
economical and environmental point of view.
Please visit www.bosch-home.co.uk for more product information
or to register your product, just follow the link to the Online
guarantee registration.
Carefully read through the operating instructions for the appliance
and safeguard them for future reference.
You can download this manual from the local homepages of
Bosch.
General safety instructions
• The iron must not be left unattended while it is
connected to the supply mains.
• Remove the plug from the socket before filling
the appliance with water or before pouring out the
remaining water after use.
• The appliance must be used and placed on a stable
surface.
• When placed on its stand, make sure that the
surface on which the stand is placed is stable.
• The iron should not be used if it has been dropped,
if there are visible signs of damage or if it is leaking
water. It must be checked by an authorized Technical
Service Centre before it can be used again.
• With the aim of avoiding dangerous situations, any
work or repair that the appliance may need, e.g.
replacing a faulty mains cable, must only be carried
out by qualified personnel from an Authorised
Technical Service Centre.
• This appliance can be used by children aged from
8 years and above and persons with reduced
physical, sensory or mental capabilities or lack
of experience and knowledge if they have been
given supervision or instruction concerning use of
the appliance in a safe way and understand the
hazards involved. Children shall not play with the
appliance. Cleaning and user maintenance shall
not be made by children without supervision.
solution
Turn the temperature
control to the desired
position.
Check that the plug is
inserted into the mains
socket correctly.
Move the iron gently
from side to side to re-
start it.
Fill the water tank
Set the steam regulator
to the relevant position.
Set the temperature
control within the steam
area (between the "••"
and "max") or turn the
steam regulator (A) to
Turn the steam regulator
to a lower setting.
Wait 5 seconds between
each press of the jet of
steam button.
Always empty the tank
after ironing and set the
steam regulator to
after ironing and when
filling the tank.
Mix distilled water with
tap water as directed
in the "Filling the water
tank" section and never
add any other products to
the water tank.
Add water to the water
tank.
Contact an Authorised
Technical Service Centre.
This is completely normal
and will stop after a short
while.
Carry out a cleaning
cycle (see "self cleaning"
section)
Move the iron gently from
side to side to re-start it.
The lamp will then flash
once before it re-heats.
• Keep the iron and its cord out of reach of children
less than 8 years of age when it is energized or
cooling down.
• C AUTION. Hot surface.
Surface is liable to get hot during use.
• This appliance is designed only for household use
up to 2000m above sea level.
• This appliance is to be connected and used in accordance with the
information stated on its characteristics plate.
• This appliance must be connected to an earthed socket. If it is
absolutely necessary to use an extension cable, make sure that it
is suitable for 16A and has a socket with an earth connection.
• If the safety fuse fitted in the appliance blows, the appliance will be
rendered inoperative. To restore normal operation the appliance will
have to be taken to an authorised Technical Service Centre.
• In order to avoid that, under unfavourable mains conditions,
phenomena like transient voltage drops or lighting fluctuations can
happen, it is recommended that the iron is connected to a power
supply system with a maximum impedance of 0.27Ω . If necessary,
the user can ask the public power supply company for the system
impedance at the interface point.
• The appliance must never be placed directly under the tap to fill the
water tank.
• Unplug the appliance from the mains supply after each use, or if a
fault is suspected.
• The electrical plug must not be removed from the socket by pulling
the cable.
• Never immerse the iron in water or any other fluid.
• Do not leave the appliance exposed to weather conditions (rain, sun,
frost, etc.).
TiPs TO helP YOu sAve enerGY
Steam production consumes the most energy. To help minimise the
energy used, follow the advice below:
• Regulate the steam according to the selected ironing temperature.
• Try to Iron the fabrics while they are still damp and reduce the steam
setting. Steam will be generated from the fabrics rather than the iron.
If you tumble dry your fabrics before ironing them, set the tumble
drier to the 'iron dry' programme.
• Stand the iron upright during pauses. Resting it horizontally with the
steam regulator on generates wasted steam.
Customer service
Great Britain
Bosch Customer Service
Grand Union House
Old Wolverton Road Milton Keynes
MK12 5PT
UK +44 (0)344 892 8979
IRL +353 (0)1450 2655
www.bosch-home.co.uk
007 TDA56..GB/02/15
Register your new Bosch now:
http://www.bosch-home.co.uk
TDA56..
en Operating instructions
CleAninG AnD MAinTenAnCe
! Attention! risk of burns!
Always unplug the appliance from the mains supply before
carrying out any cleaning or maintenance operation on it.
1. Never decalcify the water tank (E) or treat it with detergents or
solvents, otherwise the iron will drip water whilst steaming!
2. If the iron is only slightly soiled, allow the soleplate (G) to cool down.
Wipe the housing and the soleplate with a damp cotton cloth only.
3. If the cloth is synthetic, it may melt due to the high temperature on the
soleplate. Switch off the steam and rub off any residue immediately
with a thickly folded, damp cotton cloth.
4. To keep the soleplate smooth, you should avoid hard contact with
metal objects. Never use a scouring pad, or chemicals to clean the
soleplate.
GuArAnTee TerMs
The terms of the guarantee for this appliance are in accordance with that
stated by our representative for the country in which it is sold. Details
of those conditions can be obtained from the retailer from whom the
appliance was purchased. The SALES RECEIPT must be presented
when making any claims against the terms of this guarantee. We
reserve the right to make technical modifications.
DisPOsAl
Our goods come in optimised packaging. This basically consists in
using non-contaminating materials which should be handed over to
the local waste disposal service as secondary raw materials. Your
local town council can give you information about how to dispose of
obsolete appliances.
This appliance is labelled in accordance with european
Directive 2012/19/eu –concerning used electrical and
electronic appliances (waste electrical and electronic
equipment – Weee).
The guideline determines the framework for the
return and recycling of used appliances as applicable
throughout the eu..
