Durite 7 Waterproof 4CH Installation Instructions Manual

7" Waterproof 4CH Digital Wireless CCTV Kit with Recording
12/24VDC
Part 0-775-59
WARNINGS
Before using this unit please read these instructions carefully. Take special care to follow
the warnings and safety suggestions listed below. Keep these instructions for future refer-
ence.
There are no user-serviceable parts within the unit, refer servicing to qualified service
personnel.
PRECAUTIONS
• Please ensure you are familiar and comply with local traffic and driving regulations.
• Connection - The camera should only be connected to a Durite cctv system.
• Heat - Do not install the camera near heat sources. Please install in a ventilated area.
• Mounting - Ensure the camera is facing the desired direction before fixing the camera
base. If fixing to isolated return chassis the camera bracket should be isolated from the
vehicle chassis.
• Service - The user should not attempt to service these units beyond that described in these
instructions. All other servicing should be referred to an authorised service technician.
GENERAL
The camera has a CMOS image sensor which gives a high quality picture and its solid state
circuitry provides extremely long life. Compact size and single connection make it easy
to install. Automatic gain control (AGC) provides a clear image in both strong sunlight
and low light conditions, if lighting conditions fall below a set level the Infra-red LEDs will
illuminate.It is recommended that all camera lead connections are additionally sealed by ei-
ther wrapping with a suitable tape or application of heat shrink sleeving. It is recommend to
connect the system and test before fixing to ensure the correct field of view is displayed.
0-775-59-LEAF
