Memotec CX950 Hardware Reference Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

CX950 Hardware
Reference Manual
Part #3021M100-002
Date:March 2000

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CX950 and is the answer not in the manual?

Questions and answers

Related Manuals for Memotec CX950

Summary of Contents for Memotec CX950

  • Page 1 CX950 Hardware Reference Manual Part #3021M100-002 Date:March 2000...
  • Page 2 Any reproduction, disclosure or unauthorized use of this publication is expressly prohibited except as Memotec Communications Inc. may otherwise authorize in writing. Memotec Communications Inc. reserves the right to make changes without notice in product or component design as warranted by evolution in user needs or progress in engineering or manufacturing technology.
  • Page 3 Software is warranted to substantially conform to Memotec’s specifications for a period of ninety (90) days from the date of delivery. Memotec’s sole obligation under this warranty shall be limited to using its best efforts to correct such Software as soon as practical after Distributor/Business Partner or end-user has notified Memotec of such defects.
  • Page 5 T1 I/O card, DIM I/O card (T1), or ATM I/O card. Part 68 Advisements: The CX950 complies with Part 68 of the FCC Rules. The FCC registration number and ringer equivalence (REN) are indicated below and on the label attached to the bottom of the chassis cover.
  • Page 6 CX950. If this happens, the telephone company will provide advance notice in order for you to make necessary modifications to maintain uninterrupted service. If you encounter problems or have trouble with the CX950 and require service or warranty information, please contact: Memotec Communications Inc.
  • Page 7 Shielded cables must be used for the serial port line interface drivers to ensure continued compliance with emission requirements. All cables are available from Memotec Communications Inc. Directive PH-01: AVIS: L’étiquette d’Industrie Canada identifie le matériel homologué. Cette étiquette certifie que le matériel est conforme à...
  • Page 8 Cet appareil numérique de la classe A respecte toutes les exigences du règlement sur le matériel brouilleur du Canada. Des câbles blindés doivent être utilisés pour les interfaces de jonction au port série afin de respecter les normes d’émission. Ces câbles sont disponibles chez Memotec Communications inc.
  • Page 9 23/EEC and the European EMC Directive, number 89/336/EEC (and amendments that apply to both directives). This marking on the chassis identifies the CX950 chassis as fully compliant with the requirements of the European Telecommunication Terminal Directive, number 91/ 263/EEC (and amendments) and continued compliance with the LVD and EMC Directives mentioned above.
  • Page 10 The ATM I/O is an SELV port and must be connected only to an SELV service. All cabling connected to telecommunications ports must be TS 008 compliant. Inherent delays in packet-switched technology prevent the CX950 from meeting certain Standard Telephone Service requirements as defined by the Telecommunications Act 1997.

  • Page 11: Table Of Contents

    TABLE OF CONTENTS OVERVIEW 1. 1 Functional Overview ........1-2 1.
  • Page 12 SERIAL I/O CARDS 4. 1 V.24 Serial I/O Card ........4-2 4.1.1 V.24 Serial I/O Card Components.
  • Page 13 CX950 I/O Bus ........6-2...
  • Page 14 8. 2 SLIM Line Interface Drivers (SLIM LIDs) ..... . 8-4 8.2.1 FXS ..........8-5 8.2.2 FXO .
  • Page 15 12 BRI DIGITAL VOICE I/O CARD 12-1 12. 1 BRI Digital Voice I/O Card Components ..... . 12-2 12.1.1 BRI Digital Voice I/O Jumper Settings ....12-3 12.1.2 BRI Port Signal Handling .
  • Page 16 18.1.1 CX950 I/O Bus ........18-2 18.1.2...
  • Page 17 21. 1 Installation Preparations........21-2 21.
  • Page 19 Figure 1-1 The CX950 Access Switch ........1-1 Figure 1-2 CX950 System Functional Diagram, Typical ......1-2 Figure 3-1 Motherboard Layout .
  • Page 20 Figure 21-1 Releasing the CX950 Cover ........
  • Page 21 LIST OF TABLES Table 1-1 Recommended Configurations ........1-7 Table 3-1 Summary of Memory Devices .
  • Page 22 Table 19-2 ATM I/O Card Configuration ........19-5 Table 21-1 Cables Available from Memotec....... . . 21-13...

  • Page 23: Overview

    The CX950 Access Switch provides a multiservice platform which supports broad range of LAN/WAN communications protocols, capabilities, and environments. The CX950 converges data, voice and video over a choice o services including ATM, Frame Relay, IP and ISDN. This chapter presents a functional and hardware overview of the components that make up the CX950.

  • Page 24: Functional Overview

    LAN on the user side, and WAN protocols, such as ATM, X.25, ISDN, and Frame Relay, on the network side. The I/O cards also provide the port connectors that physically connect the CX950 to the user and network devices.

  • Page 25: Hardware Overview

    1.2.2 Power Supply The CX950 contains one universal-input (85V - 264 VAC) DC power supply that provides +5V and +12V to the motherboard. Voice applications require a Ring Generator card to provide -12VDC, -48VDC, and 86 VAC (ringing voltage) to th Voice I/O cards.

  • Page 26: I/O Cards

    Kbps (G.726), or 64 Kbps (G.711) on the system bus. Dual Analog The Dual Analog Voice (DAV) I/O cards enable the CX950 to transmit and Voice I/O Card receive voice and fax data. Each card supplies two analog voice/fax ports controlled by FXO, FXS, or E&M SLIM Line Interface Drivers (SLIM LIDs).
  • Page 27 The CSU/DSU cards enable the CX950 to exchange data over digital networks. 56K/64K CSU/ DSU Card The cards feature 56K, switched-56, and 64K Clear Channel capabilities. The T1/E1 I/O card enables the CX950 to connect to a full or fractional public T1/ T1/E1 I/O Card E1 network. 3021M100-002...

  • Page 28: Constraints

    1.2.5 Constraints Certain I/O cards cannot coexist in the same CX950 chassis due to the use o faster DSPs (Digital Signaling Processors). A C.54 DSP is used on the DAV I/O card, the BRI-DV I/O card, the DIM I/O card. These cards therefore cannot be used in the same chassis as the DDVC card (which must be used with the ISDN S/T I/O Card) and the Analog Voice I/O card, which use a C.31 DSP.

  • Page 29: Table 1-1 Recommended Configurations

    1 OVERVIEW Table 1-1 Recommended Configurations Maximum Max. cards of this Slot Slot Slot Slot Slot Slot Slot Slot I/O Card Speed type (per port) Multi EIA-232/V.24 128 Kbps OK with SEM Universal I/O 2.048Mbps OK with SEM EIA-232/V.24 128 Kbps OK with SEM V.35H or V.35EU 2.048 Mbps...

  • Page 31: Chassis

    Ethernet or Token Ring LANs over X.25, Frame Relay, or ATM WANs running on PDN (public or private), PSTN, DDS, T1, E1 or ISDN lines. The CX950 chassis holds a motherboard whose expansion slots can accept up to eight I/O cards. These I/O cards may include: •...

  • Page 32: Specifications

    2.1.1 Physical The CX950 is a standalone, tabletop device with an internal power supply. It is enclosed in a steel case and mounted on four rubber supports. WARNING: Rubber supports must be secured to the chassis bottom at all times.

  • Page 33: Environmental

    We recommend that you power off the CX950 with the ON/OFF switch before you attach or detach the power cable. You need not power off the CX950 to attach or detach cables for the console port or I/O cards.
  • Page 34 1 bit/character Parity: None Speed: 9600 bps The rear panel has a power entry module through which power enters the CX950 Power Entry and goes to the power supply unit. The power entry module consists of: • a male connector for a standard IEC three-lead power cord •...

  • Page 35: Motherboard

    MOTHERBOARD The CX950 Motherboard holds all integrated circuits and other components required to achieve LAN/WAN interoperability. The Motherboard contains eight expansion slots that house the I/O cards which can support a wide range of protocols and technologies including ATM, T1/E1, legacy, Frame Relay, Token Ring, Ethernet 10BaseT, Fast Ethernet, voice, FAX, and ISDN.

  • Page 36: Figure 3-1 Motherboard Layout

    CX950 Hardware Reference Manual Figure 3-1 Motherboard Layout 3021M100-002...

  • Page 37: Processing Section

    3 MOTHERBOARD Processing Section 3.1.1 The PowerPC 603e, located at U30, is a high performance RISC microprocessor featuring high instruction and data throughput, and a system bus clock speed of 65.536 MHz. 3.1.2 Bridge/Memory Controller The MPC106, located at U34, acts as the interface between the central processor (PowerPC 603e), the L2 cache, the main memory, and the PCI bus.

  • Page 38: I/O Section

    CX950 Hardware Reference Manual I/O Section The Motherboard contains three sets of connectors, each one dedicated to I/O card interconnection to one of the following busses: • I/O bus • PCI bus • High voltage bus 3.2.1 I/O Bus In the middle of the motherboard are eight 120-pin card-edge connectors (located at J12 through J19).

  • Page 39: Figure 3-2 Functional Block Diagram, Motherboard

    3 MOTHERBOARD I/O 's (U s e r & N e tw o rk ) H ig h Vo lta g e B u s I/O B U S S L O T S L O T S L O T To I/O S lo ts 1 -4 P C I...

  • Page 41: Serial I/O Cards

    1-4, and in slots 5-8 if the Serial Expansion Module (SEM) is installed. They enable the CX950 to exchange data with a variety of external serial devices. Other serial devices include the Multi I/O, discussed in Chapter 5, and the Universal I/O, discussed in Chapter 6.

  • Page 42: Serial I/O Card

    CX950 Hardware Reference Manual V.24 Serial I/O Card The V.24 Serial I/O card and its single port provide V.24 interface capabilities with unbalanced signals for control, data and timing signals. It supports synchronous or asynchronous transmission at speeds up to 128 Kbps.

  • Page 43: Speeds Supported By The V.24 Serial I/O

    1880 pF cable capacitance while maintaining compliance with the applicable regulatory standards. If using cables other than those supplied by Memotec, ensure that the capacitance does not exceed 1880pF. This can be calculated from the cable manufacturer’s specifications of capacitance per foot (pF/Ft), which differs from one cable to the next.

  • Page 44: Figure 4-3 V.24 Dte/Dce Configuration Jumpers

    CX950 Hardware Reference Manual When configured as a DCE device, the port transmits DCD, DSR and CTS and the synchronous clock signals TXC and RXC. The port must receive DTR and RTS from the attached DTE. Terminals, printers, controllers and hosts are always DTE devices.

  • Page 45: Serial I/O Card Signal Handling

    4 SERIAL I/O CARDS 4.1.4 V.24 Serial I/O Card Signal Handling Signaling through the V.24 Serial I/O Card’s port complies fully with the ITU-T’s (CCITT) V.24 and the EIA-232D standards for a DB-25 connector. Table 4-1 Signal Pin-Outs for V.24 I/O Port V.24 DB-25 Signal...

  • Page 46: Serial I/O Card Power Consumption

    CX950 Hardware Reference Manual 4.1.5 V.24 Serial I/O Card Power Consumption Power consumption for the V.24 Serial I/O Card is 0.35 Watts (1.2 BTU/hr). V.35EU Serial I/O Card The V.35EU (European Union version) Serial I/O card and its single port adhere strictly to the V.35 standard.

  • Page 47: Speeds Supported By The V.35Eu Serial I/O

    V.35EU I/O port can drive up to a maximum of 2150 pF cable capacitance while remaining compliant with applicable regulatory standards. If using cables othe than those supplied by Memotec, ensure that the capacitance does not exceed 2150pF. This can be calculated from the cable manufacturer’s specifications of capacitance per foot (pF/Ft), which differs from one cable to the next.

  • Page 48: V.35Eu Serial I/O Card Signal Handling

    CX950 Hardware Reference Manual When configured as a DTE device, the port transmits DTR, RTS and ETXC and receives DCD, DSR and CTS and the synchronous clock signals TXC and RXC from the attached DCE. A jumper bank socketed at U8 provides DTE/DCE configuration. Permanent metal bands on the top surface of the jumper bank strap signals according to DCE/ DTE requirements.

  • Page 49: V.35Eu Serial I/O Card Power Consumption

    4 SERIAL I/O CARDS Table 4-2 Signal Pin-Outs for V.35EU Port V.35EU M-34 Signal Direction- Circuit Function ITU-T Signal Pin No. RXCA Receiver Clock (Set A) 115-A Data Terminal Ready Ring Indicator External Transmitter Clock ETXCA 113-A (Set A) Separate A and B signals in the V.35 interface indicate differential pair signals. 4.2.5 V.35EU Serial I/O Card Power Consumption Power consumption is 1.45 Watts (5.0 BTU/hr).

  • Page 50: Figure 4-7 V.35H Serial I/O Card

    CX950 Hardware Reference Manual Figure 4-7 V.35H Serial I/O Card The edge connector fixes the card to any one of the motherboard’s expansion slots 1-8. The connector plate fixes the female DB-25 connector to the chassis’ rear panel with two Phillips-head screws and limits dust accumulation and electromagnetic radiation.

  • Page 51: Speeds Supported By The V.35H Serial I/O

    4 SERIAL I/O CARDS The V.35H Serial I/O Card connects to external devices through either of two Cable separately-ordered cables: • three-meter (10 ft) shielded, twisted pair cable with a male DB-25 connector at one end and a male M-34 block connector at the other (part no. CBLA0014-010) •...

  • Page 52: V.35H Serial I/O Card Signal Handling

    CX950 Hardware Reference Manual Figure 4-9 V.35H DTE/DCE Configuration Jumpe 4.3.4 V.35H Serial I/O Card Signal Handling Signaling through the V.35H Serial I/O Card’s port complies fully with the ITU- T’s (CCITT) V.35 standard. Signaling, however, occurs through a DB-25 connector rather than an M-34 block connector.

  • Page 53: V.35H Serial I/O Card Power Consumption

    4 SERIAL I/O CARDS Table 4-3 Signal Pin-Outs for V.35H Port V.35H DB-25 Signal Direction Circuit Function ITU-T Signal Pin No. *Unassigned not used not used Ring Indicator *Unassigned not used not used ETXCA External Transmitter Clock (Set A 113-A *Unassigned not used not used...

  • Page 54: Figure 4-10 X.21 Serial I/O Card

    CX950 Hardware Reference Manual Figure 4-10 X.21 Serial I/O Card The edge connector fixes the card to any one of the motherboard’s expansion slots 1-8. The connector plate fixes the female DB-15 connector to the chassis’ rear panel with two Phillips-head screws and limits dust accumulation and electromagnetic radiation.

  • Page 55: Speeds Supported By The X.21 Serial I/O

    4 SERIAL I/O CARDS 4.4.2 Speeds Supported by the X.21 Serial I/O The X.21 port can operate, without split clocking, at the following speeds: • 50 bps - 2,048 Kbps for external clocking • 375 bps - 2,048 Kbps for internal clocking 4.4.3 X.21 DTE/DCE Interface Configuration The X.21 Serial I/O Card’s port can be configured either as a DTE or a DCE...

  • Page 56: Serial I/O Card Signal Handling

    CX950 Hardware Reference Manual 4.4.4 X.21 Serial I/O Card Signal Handling The following table identifies the X.21 signals supported on the I/O port connector. The information identifies the pin through which the signal passes on the DB-15 port connector. Table 4-4 Signal Pin-Outs for X.21 Port X.21...

  • Page 57: Multi I/O Card

    The Multi I/O card mounts on the motherboard in any of slots 1-4 and also slots 5- 8 if the Serial Expansion Module (SEM) is installed. When used with the Multi I/ O cable, the card provides a higher serial port density for the CX950. Each Multi I/O supports five V.24/EIA-232 ports. Each V.24/EIA-232 can support synchronous or asynchronous transmission at speeds up to 128 Kbps.

  • Page 58: Multi I/O Card Components

    CX950 Hardware Reference Manual Multi I/O Card Components Important components of the Multi I/O Card include: • edge connector • port connector • port configuration jumpers • signal LEDs • multi I/O cable Figure 5-1 Multi I/O Card The edge connector fixes the card to any one of the motherboard’s expansion slots 1-8.

  • Page 59: Dte/Dce Interface Configuration

    Each of the five V.24/EIA-232 ports can be configured either as a DTE or DCE device. NOTE: Other V.24/EIA-232 ports in the CX950 are DTE/DCE configured with a jumper bank. Each port on the Multi I/O are DTE/DCE configured with a jumper bank and a suitcase jumper.

  • Page 60: Multi I/O Cable

    CX950 Hardware Reference Manual Figure 5-3 Multi I/O DTE/DCE Configuration 5.1.2 Multi I/O Cable The Multi I/O Card connects to external devices through a Multi I/O cable (part no. CBLA0017-024 or CBLA0017-124) with one DB-60 and five DB-25 connectors. Each DB-25 is labelled Port 1 through Port 5 to ensure that the DTE/DCE configuration for each port is correct.

  • Page 61: Signal Leds

    5 MULTI I/O CARD 5.1.3 Signal LEDs There are 3 LEDs for each port on the Multi I/O. The DCE LED glows red when the port is configured as a DCE, the RXD LED blinks green when data is received and the TXD LED blinks green when data is transmitted.

  • Page 63: Universal I/O Card

    UNIVERSAL I/O CARD The Universal I/O card supports five serial ports with maximum port speeds of 2.048 Mbps. The physical interface for each port is configured independently as V.24, V.35, or X.21, and DTE or DCE operation. A custom breakout cable is required for the single high-density port connector.

  • Page 64: Universal I/O Card Components

    The CX950 I/O bus carries the address bus, data bus, and clocking/control signals from the motherboard CPU to the Universal I/O card. Transceivers interface th local buses to the CX950 I/O bus. Connection of the I/O bus to the motherboard is via a 120-pin card edge connector.

  • Page 65: Programmable Headers

    6 UNIVERSAL I/O CARD 6.1.3 Programmable Headers Programmable headers enable the hardware configuration of the serial I/O ports. The Universal I/O card contains three sets of five miniature surface-mount sockets that are populated with small PCBs. The orientation of the PCBs determines the configuration of the physical protocol (V.24, V.35, or X.21), interface (DTE or DCE), and clock source (internal or external) for each port.

  • Page 66: Figure 6-3 Universal I/O Card, Connector Plate

    CX950 Hardware Reference Manual LED State Indication √ Link up. Remote DCD active. √ Link down. Remote DCD inactive. √ Link up. Remote DTR active. √ Link down. Remote DTR inactive. √ Receiving (RXD) data from the remote unit √...

  • Page 67: Universal I/O Cable

    6 UNIVERSAL I/O CARD Universal I/O Cable The Universal I/O module is equipped with an octopus cable that features a VHDCI connector on one end and 5 cable legs equipped with RS-232 connectors on the other end. This allows the Universal I/O module to support 5 interfaces through a single port.

  • Page 68: Dte/Dce Configuration

    CX950 Hardware Reference Manual X .21 V.35 Figure 6-4 Configuring the V.35 Protocol 6.3.2 DTE/DCE Configuration DTE/DCE selection for each port is configured by inserting the appropriate edge of the PCB into the connector. DTE/DCE port configuration connectors are located at J11, J21, J31, J41 and J51. Figure 6-5 demonstrates the PCB orientation for DTE configuration.

  • Page 69: Clock Source Configuration

    6 UNIVERSAL I/O CARD 6.3.3 Clock Source Configuration Each port is configurable for TXC or ETXC mode. TXC mode means that only the standard transmit clock TXC is available for the transmit data, i.e., the clock is output from the DCE and input to the DTE. ETXC mode means that only the standard external (or DTE) transmit clock (ETXC) is available for the transmit data (from DTE to DCE).

  • Page 71: Analog Voice I/O Card

    The Analog Voice I/O Cards, which mount on the motherboard in any of slots 1-8, enable the CX950 to transmit and receive voice and fax data. Each card supplies a single analog voice/fax port controlled by a Line Interface Driver (LID).
  • Page 72 CX950 Hardware Reference Manual Analog Voice I/O Card Components User-relevant components on the Analog Voice I/O Card include: • edge connector • port connector • Line Interface Driver (LID) The edge connector fixes the card to any one of the motherboard’s expansion slots 1-8.

  • Page 73: Speeds Supported By The Analog Voice I/O Card

    7 ANALOG VOICE I/O CARD Figure 7-2 Analog Voice I/O Connector Plat Speeds Supported by the Analog Voice I/O Card The card supports transmission rates of 5.8 Kbps or 8 Kbps using Algebraic Code- Excited Linear Prediction II (ACELP II) and 40, 32, 24, or 16 Kbps (G.726), or 64 Kbps (G.711) on the system bus.

  • Page 74: Table 7-1 Jumper Settings For E&M 2/4-Wire Line Impedance

    CX950 Hardware Reference Manual The E&M 2-wire and E&M 4-wire LIDs feature 600 Ohm line impedance. E&M 2-wire and 4-wire Unlike the E&M 4-wire LID, the E&M 2-wire LID does not require the T1 to T1 or R1 to R1 connections in straight-through signalling or the T1 to T or R1 to R in reverse signalling.

  • Page 75: Fxo And Fxs Drivers

    7 ANALOG VOICE I/O CARD 7.3.2 FXO and FXS Drivers The FXS (Foreign eXchange Station) LID is used for connection to a telephone. The FXS LID provides -48 VDC battery voltage, generates the ring signal and supports Loop Start detection, Direct Inward Dialing (DID), and Flash Hook signaling.

  • Page 76: Layouts For E&M Signaling Leads

    CX950 Hardware Reference Manual Table 7-4 Voice Connector Signal Output (PB-45) 8-pin North American European Layouts for E&M Signaling Leads The following diagrams illustrate the arrangements for normal signaling of E&M 4-wire Types I, II, III, IV and V. The same diagrams apply to the E&M 2-wir driver except that T1 to T1 and R1 to R1 connections are not present.
  • Page 77 7 ANALOG VOICE I/O CARD         ! "# !$$ "# ! "# !$$ "#                            Figure 7-4 E&M Signal, 4-Wire Type II   ...
  • Page 78 CX950 Hardware Reference Manual       G .D . ! "# !$$ "# ! "# !$$ "#                          Figure 7-6 E&M Signal, 4-Wire Type IV...

  • Page 79: Analog Voice I/O Cables

    7 ANALOG VOICE I/O CARD Analog Voice I/O Cables The Analog Voice I/O Card connects to external devices through one of th following separately-ordered cables: • three meter (10 ft) straight-through cable with a male RJ-12 connector at each end (part no.

  • Page 80: E&M Pin-Outs And Wiring For Octopus Cables

    CX950 Hardware Reference Manual E&M Pin-Outs and Wiring for Octopus Cables Two types of Octopus cables are available. Each type terminates at the user-end with a USOC standard Telco 25-pair female connector. At the Analog Voice I/O side: • 8-leg cables with RJ-12 connectors, this type is used with E&M (4-wire) Types I and •...

  • Page 81: Table 7-8 Rj-12 Wiring

    7 ANALOG VOICE I/O CARD Table 7-8 RJ-12 Wiring RJ-12 Cable RJ-12 Cable Leg# Conductor Conductor blue/white white/blue orange/white white/orange green/white white/green brown/white white/brown slate/white white/slate blue/red red/blue orange/red red/orange green/red red/green brown/red red/brown slate/red red/slate blue/black black/blue orange/black black/orange green/black black/green brown/black...

  • Page 82: Analog Voice I/O Card Power Consumption

    Table 7-9 PB-45 Wiring RJ-12 Cable RJ-12 Cable Leg# Conductor Conductor green/black black/green brown/black black/brown slate/black black/slate yellow/blue blue/yellow orange/yel- yellow/orange yellow/green green/yellow yellow/brown brown/yellow yellow/slate slate/yellow blue/violet violet/blue orange/violet violet/orange green/violet violet/green brown/violet violet/brown slate/violet violet/slate Analog Voice I/O Card Power Consumption The power consumption is 2.5 Watts (8.5 BTU/hr) with LID.

  • Page 83: Dual Analog Voice I/O Card

    The Dual Analog Voice (DAV) I/O cards, which mount on the motherboard in any of slots 1-8, enable the CX950 to transmit and receive voice and fax data. Each card supplies two analog voice/fax ports controlled by SLIM Line Interface Drivers (SLIM LIDs).

  • Page 84: Cx950 I/O Bus

    The CX950 I/O bus carries the address bus, data bus, and clocking and control signals from the motherboard CPU to the DAV I/O card. Transceivers interface the local buses to the CX950 I/O bus. Connection of the I/O bus to the motherboard is via a 120-pin card edge connector.

  • Page 85: Programmable Logic Device

    8 DUAL ANALOG VOICE I/O CARD 8.1.4 Programmable Logic Device The Programmable Logic Device (PLD) performs three main functions: 1) An interface between the DSP and the motherboard, 2) a logic interface between th DSP and the SLIM LIDs, and 3) a clock distribution circuit for the AICs and the DSP.

  • Page 86: Speeds Supported By The Dav I/O

    CX950 Hardware Reference Manual D U AL AN ALO G VO IC E C H -1 C H -2 Figure 8-3 DAV I/O Connector Plate NOTE: Attachment of the connector plate to the chassis is required at all times for good grounding.

  • Page 87: Fxs

    8 DUAL ANALOG VOICE I/O CARD 8.3.1 The FXS (Foreign eXchange Station) SLIM LID is used for connection to a telephone. The FXS SLIM LID provides -48 VDC battery voltage, generates the ring signal and supports Loop Start detection, Direct Inward Dialing (DID), and Flash Hook signaling.

  • Page 88: Figure 8-4 E&M Signal, 4-Wire Type I

    CX950 Hardware Reference Manual   A S ide                             !   "         #$   Figure 8-4 E&M Signal, 4-Wire Type I...
  • Page 89 8 DUAL ANALOG VOICE I/O CARD         ! "# !$$ "# ! "# !$$ "#                           Figure 8-6 E&M Signal, 4-Wire Type III    ...

  • Page 90: Configuring Voice Slim Lids

    CX950 Hardware Reference Manual             ! "# !$$ "# ! "# !$$ "#                          Figure 8-8 E&M Signal, 4-Wire Type V...

  • Page 91: Fxo

    8 DUAL ANALOG VOICE I/O CARD The default settings are 2-wire, 600 Ohm, Type 1, Normal signaling. Figure 8-9 shows the jumper bank locations for the default configuration. L in e Im p e da n ce AT & T typ e sig na lin g N o rm a l...

  • Page 92: Figure 8-10 Fxo Jumper Settings

    CX950 Hardware Reference Manual Table 8-2 FXO Jumper Settings for Australi Location Australia 900 Ohm Special connect C-D Current Limit For FXO in France, there is a limit on the amount of current that may be drawn for France from the Public Switched Telephone Network (PSTN). There is a transistor on th FXO SLIM LID which monitors and controls the amperage so that it does not draw more than the limit.

  • Page 93: Fxs

    8 DUAL ANALOG VOICE I/O CARD Jum pe r Bank R J-11 600 Ω Figure 8-11 FXO Jumper Settings for Australia 8.4.3 Line impedance is hardware configurable through jumper settings. As an example, Figure 8-12 shows the jumper bank position for configuring 900 Ohm impedance.

  • Page 94: Voice Slim Lid Connector Pin Assignments

    CX950 Hardware Reference Manual Voice SLIM LID Connector Pin Assignments The following tables describe the signal outputs for North America and Europe for the 6-pin RJ-12 connector and the 8-pin RJ-45 connectors. Table 8-4 Voice Connector Signal Output (RJ-12) 6-pin...

  • Page 95: E&M Pin-Outs And Wiring For Octopus Cables

    8 DUAL ANALOG VOICE I/O CARD E&M Pin-outs and Wiring for Octopus Cables The octopus cable terminates at the user-end with a USOC standard Telco 25-pair female connector. The other side of the cable features 6-leg cables with RJ-45 connectors. Table 8-6 PB-45 Pin-out Signal M lead...

  • Page 96: Power Requirements

    CX950 Hardware Reference Manual Power Requirements 8.8.1 Power Supply The DAV I/O card is completely powered by the 5V source from the motherboard. The 5V source supplies the 3.3V switching regulator and the 5V analog powe filter. The 3.3V source supplies the 2.5V regulator.

  • Page 97: Csu/Dsu I/O Card

    There are two types of CSU/DSU I/O cards: 56K (with switched 56K capability and 64K Clear Channel. The I/O mounts on the motherboard in any of slots 1-4 and also slots 5-8 if the SEM is installed. This card enables the CX950 to exchange data over Digital Data Service (DDS) networks.

  • Page 98: Csu/Dsu I/O Card Components

    CX950 Hardware Reference Manual CSU/DSU I/O Card Components Important components on the CSU/DSU I/O Card include: • edge connector • port connector • option sticker (indicating 56K or 64K) • EPROM • programmable logic device Figure 9-1 CSU/DSU I/O Card The edge connector fixes the card to any one of the motherboard’s expansion slots...

  • Page 99: Csu/Dsu I/O Card Signal Handling

    9 CSU/DSU I/O CARD Figure 9-2 CSU/DSU I/O Card, Connector Plate 9.1.1 CSU/DSU I/O Card Signal Handling The following table gives the signal Pin-Outs for the RJ-45 connector. Table 9-1 CSU/DSU Port Signals Signal Pin No. R1 (Ring 1, Transmit Data) T1 (Tip 1, Transmit Data) not used not used...

  • Page 101: Isdn-U I/O Card

    ISDN-U I/O CARD The ISDN-U I/O Card, mounts on the motherboard in any of slots 1-8. It enables the CX950 to exchange data over an Integrated Services Digital Network (ISDN) as a Basic Rate Interface-U (BRI-U). Basic Rate ISDN provides one D channel for signaling and two B channels for data transmission at 64 Kbps each.

  • Page 102: Isdn-U I/O Card Components

    CX950 Hardware Reference Manual 10.1 ISDN-U I/O Card Components Important components on the ISDN-U I/O Card include: • edge connector • port connector • signal LEDs Figure 10-1 ISDN-U I/O Card Figure 10-2 ISDN-U I/O Card, Connector Plate 10-2 3021M100-002...

  • Page 103: Isdn Port Signal Handling

    10 ISDN-U I/O CARD The edge connector fixes the card to any one of the motherboard’s expansion slots 1-8. The connector plate fixes the female RJ-45 connector to the chassis’ rear panel with two Phillips-head screws and limits dust accumulation and electromagnetic radiation.

  • Page 105: Isdn-S/T I/O Card

    ISDN-S/T I/O CARD The ISDN-S/T I/O Card mounts on the motherboard in any of slots 1-8. When used alone, it enables the CX950 to exchange data over an ISDN BRI-S/T interface. With a Dual Digital Voice Compression (DDVC) Card, the ISDN-S/T I/O card can exchange compressed voice over both Bearer (B) channels.

  • Page 106: Isdn-S/T I/O Card Components

    CX950 Hardware Reference Manual 11.1 ISDN-S/T I/O Card Components Important components on the ISDN-S/T I/O Card include: • edge connector • port connector • configuration jumpers • signal LEDs Figure 11-1 ISDN-S/T I/O Card Figure 11-2 ISDN-S/T Connector Plate 11-2...

  • Page 107: Isdn-S/T Jumper Settings

    2-3 Termination For a CX950 with an I/O configured as NT or if it is the last TE on the line, termination must be turned ON by connecting pins 1 and 2 at LK 7 and LK 9. The ISDN-S/T I/O card comes from the factory with the termination set to ON.

  • Page 108: Power

    CX950 Hardware Reference Manual Table 11-2 Signal Pin-Outs for ISDN-S/T Port Pin # TE Signal NT Signal not used not used not used not used +Transmit +Receive +Receive +Transmit - Receive - Transmit - Transmit - Receive not used not used...

  • Page 109: Dual Digital Voice Compression Card

    5.8 or 8.0 Kbps (ACELP II) or 16, 24, 32 or 40 Kbps (G.726), o 64 Kbps (PCM). NOTE: Each CX950 chassis can support a maximum of three DDVC Cards (6 voice channels). The power consumption for the card is 3 Watts (10.3 BTU/hr).

  • Page 111: Bri Digital Voice I/O Card

    The Basic Rate Interface (BRI) Digital Voice I/O card mounts on the motherboard in any of slots 1-8. It enables the CX950 to transmit compressed voice, and data over an ISDN BRI-S/T interface. The B channels can be software configured fo voice compression at 8.0 Kbps (G.729) and 40, 32, 24, or 16 Kbps (G.726), or 64...

  • Page 112: Bri Digital Voice I/O Card Components

    CX950 Hardware Reference Manual 12.1 BRI Digital Voice I/O Card Components Important components on the BRI Digital Voice I/O Card include: • edge connector • port connector • configuration jumpers • signal LEDs e d g e co nn e cto r...

  • Page 113: Bri Digital Voice I/O Jumper Settings

    1-2 pins 2-3 For a CX950 with an I/O configured as NT or if it is the last TE on the line, Termination termination must be turned ON by connecting pins 1 and 2 at LK 7 and LK 9. The BRI Digital Voice I/O card comes from the factory with the termination set to ON.

  • Page 114: Power

    CX950 Hardware Reference Manual Table 12-2 Signal Pin-Outs for the BRI Port Pin # TE Signal NT Signal not used not used not used not used +Transmit +Receive +Receive +Transmit - Receive - Transmit - Transmit - Receive not used...

  • Page 115: 34 Modem I/O Card

    The V.34 Modem I/O Card, mounts on the motherboard in any of slots 1-4 and also slots 5-8 if the SEM is installed. It enables the CX950 to establish either a dial backup connection to the network in case its direct connection goes down, or a simple public or private network dialup connection.

  • Page 116: Modem I/O Card Components

    CX950 Hardware Reference Manual 13.1 V.34 Modem I/O Card Components Important components on the V.34 Modem I/O Card include: • edge connector • port connectors Figure 13-1 V.34 Modem I/O Card Figure 13-2 V.34 Modem I/O Card, Connector Plate 13-2...

  • Page 117: Modem Signal Handling

    13 V.34 MODEM I/O CARD The edge connector fixes the card to any one of the motherboard’s expansion slots 1-8. The connector plate fixes the female RJ-11 connector and audio jack to the chassis’ rear panel with two Phillips-head screws and limits dust accumulation and electromagnetic radiation.

  • Page 118: Test Features

    CX950 Hardware Reference Manual 13.2.1 Test Features The V.34 Modem I/O Card implements the following test features: • Central Office (CO) activated loopbacks • V.54 loopbacks including Remote Loop 2 • 511 test pattern insertion and detection, with or without error insertion •...

  • Page 119: Token Ring Lan I/O Card

    The Token Ring LAN I/O Card mounts on the motherboard in any of slots 1-8. It enables the CX950 to connect to a Token Ring local area network. The Token Ring I/O card features a Token Ring 4/16 Mbps physical interface, MAC (Media...

  • Page 120: Figure 14-1 Token Ring I/O Card

    CX950 Hardware Reference Manual 14.1 Token Ring LAN I/O Card Components Important components on the Token Ring LAN I/O Card include: • edge connector • port connectors Figure 14-1 Token Ring I/O Card The edge connector fixes the card to any one of the motherboard’s expansion slots 1-8.

  • Page 121: Token Ring Port Signal Handling

    14 TOKEN RING LAN I/O CARD 14.2 Token Ring Port Signal Handling The following table describes the signal to pin relationships for both the DB-9 and RJ-45 connectors. Table 14-1 Token Ring Port Signal Handling DB-9 RJ-45 Signal Signal Pin No. Pin No.

  • Page 123: Ethernet Lan I/O Card

    ETHERNET LAN I/O CARD Installation of the Ethernet LAN I/O Card is restricted to motherboard slots 1 and 5. The card enables the CX950 to connect with an Ethernet Local Area Network (LAN). The Ethernet LAN I/O card features an LXT901 Ethernet Interface Transceiver, MAC (Media Access Control) Addressing and status and control registers that provide it with bridge/router functionality.
  • Page 124 CX950 Hardware Reference Manual 15.1 Ethernet LAN I/O Card Components Important components on the Ethernet LAN I/O Card include: • edge connector • port connectors Figure 15-1 Ethernet LAN I/O Card The edge connector fixes the card to expansion slots 1 or 5 of the mother- board.

  • Page 125: Ethernet Port Signal Handling

    15 ETHERNET LAN I/O CARD Figure 15-2 Ethernet LAN I/O Card, Connector Plate 15.2 Ethernet Port Signal Handling The following table describes the signal to pin relationships for both the AUI and 10BaseT connectors. Table 15-1 Connector Pin-outs for Ethernet Ports 10BaseT Pin Signal AUI Pin No.

  • Page 126: Power

    CX950 Hardware Reference Manual 15.2.1 Power Power 2.0 Watts (6.8 BTU/hr). Consumption Power The motherboard 120-pin connector supplies +5 VDC to the card and provides the Ground return. Converter A DC-DC converter converts +5 VDC to +12 VDC for the AUI. The power consumption of the converter is 6.0 Watts (500 mA at 12 VDC).
  • Page 127 The Fast Ethernet LAN I/O Card mounts on the motherboard in any of slots 1-8. It enables the CX950 to connect to either a 10BaseT or 100BaseTX Ethernet Local Area Network (LAN). The Fast Ethernet LAN I/O card features autosensing of data transmission speeds of 10 Mbps or 100 Mbps.

  • Page 128: Fast Ethernet Lan I/O Card

    CX950 Hardware Reference Manual 16.1 Fast Ethernet LAN I/O Card Components Important components on the Fast Ethernet LAN I/O Card include: • edge connector • port connector • signal LEDs Figure 16-1 Fast Ethernet LAN I/O Card The edge connector fixes the card to any of slots 1-8 of the motherboard.

  • Page 129: Fast Ethernet Signal Leds

    16 FAST ETHERNET LAN I/O CARD Figure 16-2 Fast Ethernet LAN I/O Card, Connector Plate 16.1.1 Fast Ethernet Signal LEDs The Fast Ethernet connector plate has LEDs labelled TX, RX, 100 and LINK. Th TX LED blinks green when data is transmitted, the RX LED blinks green when data is received, the 100 LED glows green to indicate connection to a 100BaseTX LAN and the LINK LED glows green to indicate a good link to the network.

  • Page 130: Power

    CX950 Hardware Reference Manual 16.1.3 Power Power 3.75 Watts (12.8 BTU/hr). Consumption Power The motherboard 120-pin connector supplies +5 VDC to the card and provides the Ground return. 16-4 3021M100-002...

  • Page 131: T1/E1 I/O Card

    RJ-48 connector. For E1, the card can be jumper configured for connection through either the RJ-48 connector or two Bayonet Nut Connectors (BNCs). The T1/E1 I/O card enables the CX950 to connect to a full or fractional T1 or E1 public network.

  • Page 132: T1/E1 I/O Card Components

    CX950 Hardware Reference Manual 17.1 T1/E1 I/O Card Components Important components of the T1/E1 I/O Card include: • edge connector • port connectors • LID connectors • configuration jumpers Figure 17-1 T1/E1 I/O Card The edge connector fixes the card to any one of the motherboard’s expansion slots 1-4.

  • Page 133: Port Configuration Jumpers

    17 T1/E1 I/O CARD Figure 17-2 T1/E1 I/O Card, Connector Plate 17.1.1 Port Configuration Jumpers The T1/E1 I/O Card has connectors to mount either a T1 or E1 Line Interfac Driver (LID). The I/O also has a number of 2-pin connectors that can be modified with suitcase jumpers to select the port and match line impedance.

  • Page 134: Figure 17-3 T1/E1 Configuration Jumpers

    CX950 Hardware Reference Manual Table 17-2 T1 Line Impedance Jumper Port T1 RJ-48 (100 Ohms) Configuration T1 Transmit Connect pin 1 to 2 T1 Transmit Connect pin 1 to 2 T1 Receive Connect pin A1 to B1 T1 Receive Connect pin A1 to B1...

  • Page 135: Power

    17 T1/E1 I/O CARD 17.2 Power 1.5 Watts (5.1 BTU/hr). Power Consumption The motherboard 120-pin connector supplies +5 VDC to the card and provides the Power Source Ground return. 17-5 3021M100-002...

  • Page 137: Digital Interface Module

    Kbps (G.729) and 40, 32, 24, or 16 Kbps (G.726), or 64 Kbps (G.711). WARNING: The DIM I/O card cannot coexist with the following cards in the same CX950 chassis: - Analog Voice I/O Card - DDVC (Dual Digital Voice Compression) Card...

  • Page 138: Dim Components

    The CX950 I/O bus carries the address bus, data bus, and clocking/control signals from the motherboard CPU to the DIM. Buffers interface the local buses to the CX950 I/O bus. Connection of the I/O bus to the motherboard is via a 120-pin card edge connector.

  • Page 139: Figure 18-2 Dim, Simplified Block Diagram

    18 DIGITAL INTERFACE MODULE 18.1.4 Secondary T1/E1 Processor The second T1/E1 port is supported by the Secondary T1/E1 Processor (STEP) card. The STEP is an optional daughterboard that is installed in connector J6 of the DIM. The main components of the STEP are the T1/E1 framer and impedance-matching hardware.

  • Page 140: Figure 18-3 Digital Interface Module Connector Plate

    CX950 Hardware Reference Manual the T1/E1 lines; see Figure 18-3.          Figure 18-3 Digital Interface Module Connector Plate Two tri-coloured LEDs are mounted on the connector plate for indicating the Status- Indicator LEDs status of each T1 or E1 line.

  • Page 141: Table 18-2 Dim Slot Restrictions

    When a DIM I/O card is configured to run channelized data, it MUST reside in slot 8. When this is the case, restrictions apply to other I/O cards (including additional DIM cards if any) in the CX950 chassis. The permitted or preferred slot locations of these I/O cards are listed in Table 18-3.

  • Page 142: Connector Pin-Outs

    CX950 Hardware Reference Manual Recall that a maximum of three (3) DIM I/O cards are permitted in the CX950: up to three (3) may be used for unchannelized data and only one (1) may be used for voice and/or channelized data.

  • Page 143: Atm I/O Card

    ATM I/O CAR The ATM I/O card enables the CX950 to have WAN access to an ATM network at T1/E1 speeds. A maximum of two cards can be installed on the motherboard in slots 1-4. The card performs the following basic functions when transmitting data to th network: •...

  • Page 144: Pci Bus

    PCI Bus An 80-pin card edge connector is used to connect the on-board 32-bit Peripheral Component Interconnect (PCI) bus to the CX950 motherboard. The PCI bus enables the high-speed transfer of data between the ATM I/O SAR Controller and the motherboard CPU. The PCI bus is also used to transfer configuration and status information to and from the SAR Controller’s registers.

  • Page 145: Phy Device

    CX950 I/O Bus The exchange of configuration and status information of the PHY device and T1/ E1 Framer is handled by the CX950 system I/O bus. Connection of the I/O bus to the motherboard is via a 120-pin card edge connector.

  • Page 146: Atm I/O Connector Plate

    CX950 Hardware Reference Manual 19.1.8 ATM I/O Connector Plate Port The ATM I/O connector plate features two Bayonet Nut Connectors (BNCs) and Connectors one RJ-45 connector for external connections to the network; see Figure 19-3. The BNC connectors are used exclusively for connection to ATM E1 lines. Each E1 port is dedicated to either receive or transmit ATM traffic.

  • Page 147: Figure 19-1 Atm I/O Card

    19 ATM I/O CARD  &  '    Figure 19-3 ATM I/O Card, Connector Plate 19.2 Configuration The ATM I/O card is hardware configurable for either a T1 or E1 interface. In th case of an E1 interface, the connector type is also configurable. Suitcase jumpers are inserted to select the appropriate interface, connector type, and matching line impedance;...
  • Page 148 CX950 Hardware Reference Manual 19.3 Power Requirements Power 4.3 Watts (14.7 BTU/hr). Consumption The motherboard 120-pin connector supplies +12 VDC to the card and provides Power Source the Ground return. An on-board switching regulator provides +5 VDC to the card circuits.
  • Page 149 -48V/RING GENERATOR CARD The -48V/Ring Generator card mounts in a special connector on the motherboard near slot 8. It supplies -12 VDC, -48 VDC and 86 VAC (ringing voltage) required by the Analog Voice I/O Card, or the Dual Analog Voice (DAV) I/O Card. The -48V/Ring Generator card must be installed when these cards are used.

  • Page 150: Features

    CX950 Hardware Reference Manual 20.1 -48V/Ring Generator Components Important components on the -48V/Ring Generator card include: • motherboard connector located at J2 • fastener to the chassis’ rear panel Figure 20-1 -48V/Ring Generator Ca 20.1.1 Features Output Voltage: -48 to -52 VDC...
  • Page 151 INSTALLATION AND CONFIGURATION This section provides step-by-step procedures to install and configure the CX950’s hardware components. These procedures will prepare the CX950 for further configuration through its resident software. For more information see the CXTool User Guide, part no. 3008M300-001.

  • Page 152: Installation Preparations

    Procedure 1: Unpacking and Inspecting the CX950 When you receive your CX950 shipment, you should confirm its contents. To unpack and inspect the CX950: Examine the shipping boxes and note if there is any damage. Open the shipping boxes and match their contents with the packing slip. If necessary, make a list of any discrepancies.
  • Page 153 Opening and Closing Chassis Installing or rearranging the CX950’s I/O cards, SEM and/or -48V/Ring Generator card requires that you first remove the CX950’s cover, then replace it when work is done. WARNING: If the chassis is connected to a network, do not remove the CX950 Safety Ground.

  • Page 154: Ram Installation

    CX950 Hardware Reference Manual Figure 21-1 Releasing the CX950 Cover 21.2 RAM Installation At some point you may need to increase the motherboard’s SDRAM. Additional memory can be installed in the Dual Inline Memory Module (DIMM) connector at U2; this is between slot 1 and either the ring generator or the power supply.

  • Page 155: Standard I/O Card Installation

    21 INSTALLATION AND CONFIGURATION 21.3 Standard I/O Card Installation Standard I/O cards are defined as cards which use only the 120-pin edge connector for mounting into the motherboard expansion slot. Standard I/O cards include: • Multi I/O* • V.24 Serial I/O* •...
  • Page 156 CX950 Hardware Reference Manual Align the SEM’s edge connector with the small outline dual inline memory module (SODIMM) connector at J11 on the motherboard. The SEM is keyed so that it can only be installed component side up. Gently insert the SEM into the SODIMM at about a 30° angle. Ensure that the SEM’s connectors are completely in the SODIMM.

  • Page 157: Figure 21-2 Standard I/O Card Installation

    21 INSTALLATION AND CONFIGURATION Insert the card through the slot’s opening in the rear panel, then align the card’s edge connector over the slot’s associated connector on the motherboard. Connector J19 is associated with slot 1, J18 with slot 2, J17 with slot 3, J16 with slot 4, J15 with slot 5, J14 with slot 6, J13 with slot 7 and J12 with slot 8.

  • Page 158: Analog Voice I/O And Dav I/O Card Installation

    CX950 Hardware Reference Manual 21.4 Analog Voice I/O and DAV I/O Card Installation The Analog Voice I/O Card can be installed in any of slots 1-8. NOTE: If you install an Analog Voice I/O or DAV I/O card, you must also install a - 48V/Ring Generator card.

  • Page 159: Figure 21-3 Ring Generator Card, Installation

    21 INSTALLATION AND CONFIGURATION Figure 21-3 Ring Generator Card, Installation Procedure 7: Installing Analog Voice I/O or DAV I/O Card This procedure assumes that you have installed or will install the -48V/Ring Generator card (Procedure 6). It also assumes that you have removed the cover from the chassis (Procedure 2).

  • Page 160: Atm I/O Card Installation

    Motherboard connectors J16-J19 interconnect the I/O cards to the CX950 I/O bus and J20-J23 interconnect the I/O cards to the PCI bus. Press the card firmly but gently into place.

  • Page 161: External Equipment Cabling

    21.6 External Equipment Cabling Once you have installed the I/O cards you require, you can physically connect them to their network devices after connecting the CX950 to its power source. WARNING: Never connect an I/O card to a network device without first connecting the CX950 to its power source.
  • Page 162 Plug the opposite connector of the power cable to the source of power. Procedure 10: Connecting CX950 to PC This procedure assumes that the CX950 is connected to its power source but remain powered-off. To connect the CX950 to a Personal Computer (PC): Locate the RJ-12 -DB9 cable (part # CBLA0024-610) that is shipped with the unit.
  • Page 163 Determine the kind of I/O card you want to connect to its network device. Determine the kind of cable you need to connect this I/O card to its network device. Table 21-1 Cables Available from Memotec Interface Cable Part # Description male DB-25 to male DB-25 (3 m;...
  • Page 164 F e rrite B o x Figure 21-5 Attaching the Line Filte The CX950 is now ready to be powered up. Once the CX950 is powered up, you can 21-14 3021M100-002...

  • Page 165: Powering Up

    Procedure 14: Checking/Replacing CX950 Fuses This procedure assumes the POWER LED did not light when you powered up the CX950. It further assumes that power is present at the source and that the power cord was properly connected between the source and the CX950.
  • Page 167 APPENDIX A: AFFIDAVIT FOR CONNECTION According to regulations defined by the FCC in Part 68, the customer purchasing the CX950 CSU/DSU I/O Card or T1/E1 I/O Card must complete the attached affidavit and ensure that it is notarized and delivered to the appropriate Telco office prior to connection of the equipment to the Telco lines.
  • Page 168 This page is intentionally blank...
  • Page 169 AFFIDAVIT FOR CONNECTION OF CUSTOMER PREMISE EQUIPMENT (CPE) TO 1.544 MBPS AND/OR SUBRATE DIGITAL SERVICES For the work to be performed in the certified territory of _________________________ (Telco Name). State of ___________________________________ County of _______________________________ I, _________________________________________(name) ___________________________________________(business address) ___________________________________________(business telephone number) being duly sworn, state: I have responsibility for the operation and maintenance of the terminal equipment to be connected to 1.544 Mbps and/or _________ subrate digital services.
  • Page 170 A. A training course provided by the manufacturer/grantee of the equipment used to encode analog signals; or B. A training course provided by the customer or authorized representative, using training materials and instructions provided by the manufacturer/grantee of the equipment used to encode analog signals; or C.
  • Page 171 APPENDIX B: GETTING IN TOUCH WITH US The information in this appendix tells you how to: • get in touch with our Service organization • return equipment for repair • contact our Documentation group 3021M100-001...
  • Page 172 (514) 738-3661 (Fax) Procedures for Returning Equipment for Repair If for any reason, you need to return a piece of equipment to Memotec you will find it much easier to do so if you use the following procedure. NOTE: Returns for repair will not be accepted without prior authorization from Memotec’s head office Sales or Service administration department.
  • Page 173 U.S.A. Goods to be Returned • Obtain RA# from your Memotec representative or by calling Memotec Customer Service (800) 766-7782. • Please mark the outside of the shipping box with the RA#. All paperwork concerning the returned equipment must refer to the RA#. Please include a description of the problem.
  • Page 174 CX950 Hardware Reference Manual Return for Repairs RA#: ___________________________________________ Material being returned: SO#: ___________________________________________ PO#: ___________________________________________ Returned To: _____________________________________ Customer Name: __________________________________ Address: _______________________________________________ _______________________________________________ _______________________________________________ Returned By: _____________________________________ Date: ___________________________________________ Reason for return _______________________________________________ _______________________________________________ _______________________________________________ _______________________________________________ _______________________________________________ _______________________________________________...
  • Page 175 Getting in Touch with the Documentation Group If you have any difficulties using this document or you discover an error, pleas contact the Technical Documentation group in Montreal. E-mail: tech-writing@memotec.com Fax: (514) 738-4436 We invite your comments on this manual. Your feedback is important in producing documentation that best fulfills your needs, and it will be taken into consideration in future revisions of this document.
  • Page 177 CX950 products. Completing the table will ensure that all necessary revision information is available for Memotec service personnel at the time a service request is made. To determine the current hardware and/or software version of a circuit card, follow the procedures outlined below.
  • Page 178 How to Identify the Hardware Revision of a Circuit Card The procedure for identifying hardware revision numbers is the same for all CX950 circuit cards. The location of the revision information, however, varies according to card type. The following paragraph provides an example of how to identify the hardware revision of a CX950 I/O card.
  • Page 179 APPENDIX C: RECORDING SYSTEM CONFIGURATION How to Identify the Software Revision of the CPU Method 1: Using CXView .  /0"  1         /2 3       2.9.0 (XP102901)         4         $   /2 (  ) $       /05*6  0656 7 $        ...
  • Page 180 CX950 Hardware Reference Manual Method 2: Using the Command Line Interface  !       3                              .,-   ...
  • Page 181 APPENDIX D: CARD POWER CONSUMPTION SUMMARY Consumption Card Type (Watts) V.24 Serial I/O V.35EU Serial I/O 1.45 V.35H Serial I/O X.21 Serial I/O Multi I/O Universal I/O Analog Voice I/O Dual Analog Voice I/O CSU/DSU I/O ISDN-U I/O ISDN-S/T I/O BRI-DV I/O V.34 Modem I/O Token Ring LAN I/O...
