Page 3: Table Of Contents
INDEX AIM AND CONTENTS OF THIS MANUAL ............... 5 KEEP THIS MANUAL..............................5 GRAPHIC SYMBOLS................................. 5 SAFETY LAWS ......................5 GENERAL SAFETY GUIDELINES ..................5 HEALTH SAFETY WORKERS ............................6 PERSONAL PROTECTION EQUIPMENTS ..........................6 SAFETY SYMBOLS.................................. - Page 4 OPERATING MODES................................17 8.4.1 OPERATION MODE SETTING............................17 PROCEDURE..................................17 8.5.1 SET‐POINT SELECTION ..............................17 DESCRPTION FUNCTIONS ..............................17 8.6.1 ACCESS TO THE FUNCTIONS............................17 ALARMS ....................................18 ADJUSTMENT SANITARY WATER VALVE.......................... 18 MICROPROCESSOR USER INTERFACE ................. 18 DISPLAY ....................................19 LED......................................
- Page 5 ACCESS PROCEDURE TO INTERNAL PARTS ..............35 20.1 INDOOR UNIT ..................................35 20.2 OUTDOOR UNIT..................................35 COMPONENTS OF INDOOR AND OUTDOOR UNITS ............ 36 21.1 INDOOR UNIT ..................................36 21.2 OUTDOOR UNIT..................................36 WIRING DIAGRAMS ....................37 22.1 INDOOR UNITS..................................37 22.2 OUTDOOR UNITS .................................. 38 ...
-
Page 6: Aim And Contents Of This Manual
1 AIM AND CONTENTS OF THIS MANUAL This manual provides basic information as for the installation, the operation and the maintenance of the PACK DUE units. It is addressed to machine operators and it enables them to use the equipment efficiently, even if they do not have any previous specific knowledge of it. This manual describes the characteristics of the equipment at the time it is being put on the market; therefore, it may not capture later technological improvements introduced by A2B ACCORRONI E.G. as part of its constant endeavour to enhance the performance, ergonomics, safety and functionality of its products. 1.1 HOW TO KEEP THIS MANUAL The manual has to be always kept with the unit it refers to. It has to be stored in a safe place, away from the dust and moisture. It has to be accessible to all users who shall consult it any time they are in doubt on how to operate the equipment. A2B ACCORRONI E.G. reserves the right to modify its products and related manuals without necessarily updating previous ... -
Page 7: Health And Safety Of Workers
3.1 HEALTH AND SAFETY OF WORKERS The European Community has adopted a number of directives on workplace’s health and safety, which include 89/391/CEE, 89/686/CEE, 89/655/CEE, 86/188/CEE and 77/576/CEE directives. Every employer shall implement such provisions and ensure that workers respect them: Do not tamper with or replace parts of the equipment without the specific consent of the manufacturer. The manufacturer shall have no responsibility whatsoever in case of unauthorised operations. ... -
Page 8: Refrigerant Safety Data Sheet
3.4 REFRIGERANT SAFETY DATA SHEET Name: R410A (50% Difluoromethane (R32); 50% Pentafluoroethane (R125). RISKS IN DICATIONS Major risks: Asphyxia Specific risks: The rapid evaporation can cause freezing. FIRST AID General informations: Never give anything by mouth to an unconscious person. Inhalation: Outdoors opens transport. Use oxygen or artificial respiration if necessary. Do not give adrenaline or similar drugs Eyes contact: Rinse carefully with water for at least 15 minutes and consult a doctor. Contact with skin: Wash immediately with plenty of water. Take off immediately the contaminated clothes. FIRE PREVENTION Extinguishing Media: Whatever. Specifc risks: Increase in pressure. Specifics methods: Use water spray to cool containers MISURE IN CASO DI FUORIUSCITA ACCIDENTALE Personal precautions: Evacuate personnel to safe areas. Provide adequate ventilation. Use personal protective equipment. Environmental precautions: Evaporate. ... -
Page 9: Technical Characteristics
4 TECHNICAL CHARACTERISTICS The PACK DUE water chillers and heat pumps series are designed for applications in residential and commercial areas, These units are extremely versatile and can operate in heat pump mode with the ability of producing hot water at a temperature of 55°C for environmental heating and sanitary applications. The INVERTER compressor with brushless DC motor technology, matched with electronic expansion valve, pump and variable speed blower are generally used for optimizing the power consumption and efficient operation of the refrigerating components. 4.1 FRAME All PACK DUE units are made up of hot‐galvanised thick sheet metal, painted with polyurethane powder enamels at 180°C to ensure the best resistance against atmospheric agents. The frame is self‐supporting with removable panels. All screws and rivets for outdoor installations are in stainless steel. 4.2 REFRIGERANT CIRCUIT The refrigerant gas used in these units is R410A. The refrigerant circuit has been manufactured by means of international primary brands components and according to the UNI EN 13134 rule concerning welding procedures. The refrigerant circuit includes: Safety device on the gas side, 4 way reverse cycle valve, electronic expansion valve, liquid receiver, valves for maintenance and control, pressure safety device according to PED regulation (high pressure switch), pressure transducers to accurately adjust the evaporating and condensing pressures, filters for throttling valve to avoid its clogging. 4.3 COMPRESSORS The used DC inverter compressors are a rotary hermetic single‐phase type (only for the models PACK DUE 7 and PACK DUE 9) and twin rotary single‐phase (for the model PACK DUE 12), and scroll 3‐phases type (for PACK DUE 16) designed to be ... -
Page 10: Monitoring And Protection Devices
When installing or servicing the unit, it is necessary to strictly follow the rules listed in this manual, to conform to all the specifications of the labels on the unit, and to take any possible precautions. Not observing the rules reported on this manual can create dangerous situations. After receiving the unit, immediately check its integrity. The unit left the factory in perfect condition; any eventual damage has to be questioned to the carrier and recorded on the Delivery Note before signing it. A2B ACCORRONI E.G. to be informed, within 8 days, of the extent of the damage. The customer should prepare a written statement of any severe damage. ... -
Page 11: Lifting And Handling
6.3 LOCATION AND MINIMUM TECHNICAL CLEARANCES 6.3.1 INDOOR UNIT L1 L2 H1 H2 Models. (mm) (mm) (mm) (mm) PACK DUE 7‐9‐12‐16 300 300 1500 300 ‐ Place the unit on the wall. ‐ Use the provided template to mark the mounting holes. ‐ Drill holes in the marked positions and insert the plugs. ‐ Hook the unit. 6.3.2 OUTDOOR UNIT The all PACK.DUE units are designed for outdoor installation: any cover over the unit and location near trees (even if they ... -
Page 12: Plant Layout Design
the system. All pipes have to be insulated with closed‐cell material of adequate thickness. Chillers have to be connected to piping by means of flexible joints. Piping should include: • Hole thermometers to monitor the system’s temperature. • Manual shut‐off valves to separate the chiller from the hydraulic circuit. • Y‐shaped metallic filter (to be mounted on the inlet pipe) with a mesh not larger than 1 mm. • Charging group and discharge valve, where necessary. • Anti‐vibration joints. Manometer Anti‐vibration joint (recommended for Connections carried out by manufacturer Connections to be carried out by the installer indoor unit joints) Stop valve Air vent valve Flow switch System outlet Thermometer Filter Safety valve Expansion vessel 9* Additiona expansion vessel 10. Discharge valve 11. Load valve/reintegrate 12. Temperature sensor System inlet 13. Circulator ... -
Page 13: Connections Positions
6.4.3 CONNECTIONS POSITIONS 6.4.3.1 INDOOR UNIT A. Sytem outlet pipe (1”M) B. System inlet pipe (1”M) C. Gas line (see Paragraph 13.2) D. Liquid line (see Paragraph 13.2) E. Power supply F. Condensate drain (joint Ø 16 mm) 6.4.3.2 OUTDOOR UNIT Units 7 and 9 A. Power supply cover (access to the terminal A block) B. Gas connections cover C. Gas connections Models Liquid line Gas line PACK DUE 7 1/4 SAE 1/2 SAE B C ... -
Page 14: Refrigerant Diagram
• Locate the hole at the base of the unit between the finned coil and fan, A. • Connect to the hole the provided fitting joint, B. • Connect a hose to the nozzle of the supplied fitting joint. • Direct the hose into thedisposal place for condensate water. • Maintain a sufficient slope to ensure the smooth flow of condensate water. 6.5 REFRIGERANT DIAGRAM C COMPRESSOR COMPRESSOR LIQUID SEPARATOR (only for the models i‐SHWAK/WP CLS 05, 07 e 10) ... -
Page 15: Terminal Block Connections
6.6.1 TERMINAL BLOCK CONNECTIONS Electrical wiring have to be done only by qualified personnel. 6.6.1.1 WIRING BETWEEN INDOOR AND OUTDOOR UNITS The indoor unit must be connected to the outdoor unit as shown in the below figure. INDOORUNIT OUTDOORUNIT P Q E GF: General differential switch (not included) A: RS485 connection B: Power supply connection 230V-1Ph-N-50Hz 6.6.1.2 INDOOR UNIT TERMINALS OF THE ELECTRIC BOX Single‐phase power supply terminals (ground – phase ‐neutral) max. 4 mm for the units i‐ For the connection, please use a cable with a maximum section of 4/6mm. U‐N PACK DUE 7‐9 and 6mm for the units i‐ Follow the regulations for the section of the cable. PACK DUE 12 and 16. For the connection, please use a cable with a minimum section of 1mm for Terminals RS485 to be connected with those of P(‐) ‐ Q(+) ‐ ... -
Page 16: Start Up
6.6.1.3 OUTDOOR UNIT The electrical connections have to be realized by qualified personnel. For the models PACK DUE 7 and PACK DUE 9, the terminal block is located under the plastic cover on the right side of the outdoor unit (for the PACK DUE 12 and PACK DUE 16 models, it is necessary to remove the protective carter). The wiring to the terminal block has to be realized in accordance to the below notes. GND: grounding wire; N1: power supply neutral wire; L1: power supply live wire; L2: If it exists, connect the live wire coming from the system L3: If it exists, connect the live cable coming from the system NO: generic alarm output (closed when the alarm is not activated); CO: generic alarm output common terminal; NC: NO terminal generic alarm output (closed when the alarm is activated); R+: modbus + signal for connection with indoor unit; R‐: modbus ‐ signal for connection with indoor unit; WARNING: The grounding of the signal cable must not be connected and must be protected from accidental contact with the sheet: cut it or isolate it with tape. ... -
Page 17: Indoor Unit Control Panel
8 INDOOR UNIT CONTROL PANEL The control panel is composed of a display and buttons for programming. MODE ON/OFF 8.1 LED 1 Heat pump in heating mode 2 Heat pump in cooling mode 3 Circulation pump in sanitary mode 1+3 Circulation pump in cooling mode with sanitary boiler priority 2+3 Heat pump in heating mode with sanitary boiler priority 4 Heat pump compressor is on 5 Hydraulic pump of the heat pump system 6 Electric heater of heating system in heat (winter) mode 7 Sanitary boiler electric heater 8 Hydraulic pump of solar system 8.2 FUNCTIONS OF BUTTONS Alarm reset Esc Menu exit User menu scrolling MODE Change in heat pump mode ON/OFF To power on and off the heat pump To select parameters Prg ... -
Page 18: Description Of The Main Display
8.3 DESCRIPTION OF THE MAIN DISPLAY DISPLAY VISUALISATION NOTE MAIN Date and time DISPLAY Return temperature from the heating or cooling system Display 1 Set point of heating or cooling system Temperature of the sensor of the sanitary sanitary Display 2 termoaccumulatore Set‐point of sanitary sanitary termoaccumulatore Display 3 Outdoor air temperature Temperature of the solar panel collector Screenshot available only in the presence of Display 4 Temperature of the sanitary thermo‐accumulator solar panel Screenshot available only in the presence of Display 5 ... -
Page 19: Alarms
8.7 ALARMS Alarm type Alarm description Cause Hydraulic pump is off, burnt, ecc.. the pressure Lack of water circulation on the hydraulic side of the of the water side is zero bar. Water flows alarm heating/cooling/sanitary boiler system. The faucet for interception of the system are closed. Outdoor unit link A lose or bad serial connection between indoor and Electrical connections reversed or interrupted ... -
Page 20: Display
9.1 DISPLAY In normal view displays the alarm code if at least an alarm is active. In case of multiple alarms activation, it will display the first alarm, while the second appears when the first is reset. 9.2 LED • ON if the compressor is running • OFF if the compressor is off Compressor LED • FLASHING if timings are in progress waiting for compressor’s start up • ON if sanitary water valve is in open position Sanitary water LED • OFF if the sanitary water valve is in closed position • ON in defrost operating mode • OFF if defrosting mode is disabled or completed Defrosting LED • FLASHING if defrosting cycle interval’s time is in progress • The LED is ON if the antifreeze resistance is active. Antfreeze resistance LED • The LED is ON if the water pump is running. Water pump LED • The LED is ON if an alarm is activated. Alarm LED • The LED is ON if the unit is in the heating mode operation. Heat LED • LED is ON if the unit is in the cooling mode operation. Cool LED ... -
Page 21: Alarms List
9.6 ALARMS LIST Error description Code Compressor Pump Resistances Fan Inverter hardware malfunctioning Compressor’s tension too high Power supply tension out of bounds Compressor not power supplied Inverter time out malfunctioning Compressor inlet sensor OFF Compressor outlet sensor OFF High pressure transductor OFF Low pressure transductor OFF Outdoor air sensor for climate adjust OFF High pressure Low pressure 10 SHUTDOWNS FOR LONG PERIODS • Turn off all the indoor terminal units of the users. • Close the water faucet. • Turn off the switch QF general differential to OFF. If the temperature drops below freezing point (0°C) there is serious danger of frost: providing a mixture of water and glycol in the system, otherwise drain the water system and the hydraulic circuits of the heat pump. ... -
Page 22: Environmental Protection
Check the operating pressure, and superheat and subcooling x Check of the efficiency of circulation pump. x Check the expansion tank. x If the unit should be out of service for a long period, discharge water from the piping and from heat exchanger. This operation is necessary if, during seasonal stoppages, ambient x temperature is expected to go down below the freezing point of the employed fluid. 11.1 ENVIRONMENTAL PROTECTION According to the norms dealing with the use of depleting stratospheric ozone substances, it is forbidden to release refrigerants fluids in the atmosphere. They have to be collected and delivered to the seller or to proper gathering points at the end of their operating life. Refrigerant R410A is mentioned among controlled substances and for this reason it has to be subjected to the mentioned ... -
Page 23: Technical Data
13 TECHNICAL DATA 13.1 OUTDOOR UNITS PACK DUE 7 PACK DUE 9 PACK DUE 12 PACK DUE 16 TECHNICAL DATA Power supply 230V/1/50Hz 230V/1/50Hz 230V/1/50Hz 400V/3/50Hz Max. power input kW 2.81 3.80 5.47 6.15 Electrical data Max. starting current A 7.9 10.0 15.6 8.7 Max. current input A 12.6 ... -
Page 24: Indoor Units
13.2 INDOOR UNITS TECHNICAL DATA Units PACK DUE 7 PACK DUE 9 PACK DUE 12 PACK DUE 16 Power supply 230V/1/50Hz 230V/1/50Hz 230V/1/50Hz 230V/1/50Hz Electrical data Max. Power input kW 3.13 3.13 4.13 4.13 Max. input current A 13.68 13.68 17.98 17.98 Cooling capacity (1) kW 4.71 6.09 9.03 10.82 Input power (1) kW 1.52 ... -
Page 25: Effective Head Pressures
15 EFFECTIVE HEAD PRESSURES 07 16 Flow rate [m Head pressure – water flow characteristics curve net of evaporator pressure drops. Optimum operating point for PACK DUE 7 minichillers at compresssor’s limit frequency, at water pump’s high speed under the conditions specified at the top (4) of page 23. Optimum operating point for PACK DUE 9 minichillers at compresssor’s limit frequency, at water pump’s high speed under the conditions specified at the top (4) of page 23. ... -
Page 26: Performances Curves
16 PERFORMANCES CURVES The performances curves reported below are only for indications and could be subjet to modification. 16.1 Mod. PACK DUE 7 air temp. 45 °C air temp. 40 °C air temp. 35 °C air temp. 30 °C Cooling power kW air temp. 45 °C air temp. 40 °C air temp. 35 °C air temp. 30 °C Input power in cooling operation kW air temp. - Page 27 air temp. 21°C air temp. 14°C air temp. 7°C air temp. 0°C air temp. -7°C air temp. -10°C Heat capacity yields kW air temp. 21°C air temp. 14°C air temp. 7 °C air temp. 0 °C air temp. -7°C air temp.
-
Page 28: Mod . Pack Due 9
16.2 Mod. PACK DUE 9 air temp. 45 °C air temp. 40 °C air temp. 35 °C air temp. 30 °C Cooling power kW air temp. 45 °C air temp. 40 °C air temp. 35 °C air temp. 30 °C Input power in cooling operation kW air temp. - Page 29 air t emp. 21°C air t emp. 14°C air t emp. 7°C air t emp. 0°C air t emp. -7°C air t emp. -10°C 10,0 11,0 Heat capacity yields kW air temp. 21°C air temp. 14°C air temp. 7°C air temp.
-
Page 30: Mod . Pack Due 12
16.3 Mod. PACK DUE 12 air temp. 30 °C air temp. 35 °C air temp. 40 °C air temp. 45 °C 10,0 10,5 11,0 11,5 12,0 12,5 13,0 Cooling power kW air temp. 30 °C air temp. 35 °C air temp. 40 °C air temp. - Page 31 air temp. < 27°C air temp. 20°C air temp. 13°C air temp. 7°C air temp. 2°C air temp. -2°C air temp. -7°C air temp. -10°C air temp. -12°C 10,0 10,5 11,0 11,5 12,0 12,5 13,0 13,5 14,0 14,5 15,0 Heat capacity yields kW air temp.
-
Page 32: Mod . Pack Due 16
16.4 Mod. PACK DUE 16 air temp. 30 °C air temp. 35 °C air temp. 40 °C air temp. 45 °C Cooling power kW air temp. 30 °C air temp. 35 °C air temp. 40 °C air temp. 45 °C Input power in cooling operation kW air temp. - Page 33 air temp.< 27°C air temp. 20°C air temp. 13°C air temp. 7°C air temp. 2°C air temp. -2°C air temp. -7°C air temp. -12°C air temp. -15°C 10,0 11,0 12,0 13,0 14,0 15,0 16,0 17,0 18,0 19,0 Heat capacity yields kW air temp.<...
-
Page 34: Operation Limits
We enclosed below a most accurate table showing the minimum flow rates that to ensure for the plate heat exchanger for a the proper operation of unit according to the model (note: the water flow switch is used for preventing the freezing sensor from failure in the case of insufficient water flow but it does not ensure the minimum flow rate required in order the unit can work properly) Model PACK DUE 7 PACK DUE 9 PACK DUE 12 PACK DUE 16 Cooling capacity for reference [kW] 6,12 8,12 ... -
Page 35: Correction Factors
Operation limits Water chiller mode Ambient temperature Minimum ‐10°C Maximum +46°C Water outlet temperature Minimum +5°C Massima +25°C Heat pump mode Ambient temperature Minimum ‐15°C Maximum +30°C Water outelt temperature Minimum +25°C Maximum +55°C Heat pump mode for sanitary hot water Ambient temperature with maximum water temp. 48°C Minimum ‐15°C Maximum +40°C Ambient temperature with maximum water temp. 55°C Minimum ‐15°C Maximum +35°C Water outelt temperature Minimum +20°C Maximum +55°C 18 CORRECTION FACTORS 18.1 CORRECTION FACTORS: operation with glycol Glycol % (°C) CCF IPCF WFCF PDCF Freezing point 10 ‐3,2 0,985 1,02 1,08 20 ‐7,8 0,98 0,99 1,05 1,12 30 ... -
Page 36: Outdoor Unit
19.2 OUTDOOR UNIT PACK DUE 12 ‐ 16 PACK DUE 7‐9 DIMENSIONS (mm) A B C D E F H MODELS PACK DUE 7 842 560 335 360 312 324 695 PACK DUE 9 895 590 333 355 302 313 862 PACK DUE 12‐16 940 ... -
Page 37: Components Of Indoor And Outdoor Units
21 COMPONENTS OF INDOOR AND OUTDOOR UNITS 21.1 INDOOR UNIT Electric box User interface Plate heat exchanger Thermostat with manual reset Thermostat with automatic reset Safety valve Flow switch Expansion vessel Pump 10. Heater collector 11. Manual air vent valve 21.2 OUTDOOR UNIT Condensor coil assy Fan motor support Fan motor Fan Transductor Expansion valve Coil of the expansion valve Compressor 4‐way valve Note: The figure refers to the outdoor unit model PACK DUE 7 and is included for illustration purposes. The outdoor units PACK DUE 12 and PACK DUE 16 have two fans. ... -
Page 38: Wiring Diagrams
22 WIRING DIAGRAMS 22.1 INDOOR UNITS A1 Electronic controller FU2 Auxiliary fuse A2 Expansion for solar kit (optional) KM1 Heater integration contactor assembly A3 Integration resistance control panel/Sanitary boiler anti‐legionnaires KM2 Contactor for Integration resistance and sanitary boiler anti‐legionnaires A4 Outdoor mono‐condensing unit QF General differential switch (not included) BT1 Water inlet sensor for the plant R1 Plant integration resistance BT2 Water outlet sensor for the plant R2 Integration resistance and sanitary boiler anti‐legionnaires BT3 Sanitary water sensor for boiler TH1 Ambient thermostat BT4 Outdoor air temperature sensor THS1 Resistance R1 of safety thermostat action at 80°C reset at 70°C. E1 Circulating pump of the plant ... -
Page 39: Outdoor Units
22.2 OUTDOOR UNITS 22.2.1 Wiring diagram of PACK DUE 9 ... -
Page 40: Wiring Diagram Of Pack Due 12
22.2.2 Wiring diagram of PACK DUE 12 ... -
Page 41: Wiring Diagram Of Pack Due 16
22.2.3 Wiring diagram of PACK DUE 16 ... -
Page 42: Solar Module (Optional Accessory)
23 SOLAR MODULE (OPTIONAL ACCESSORY) 23.1 ASSEMBLY A) B) FIXE THE SOLAR EXPANSION BOARD IN THE FOUR HOLES OF THE ELECTRIC BOX OF THE INDOOR UNIT AS SHOWN IN THE FRAME REMOVE THE FOUR SCREWS WITH A SPECIAL SCREWDRIVER AND THEN REMOVE THE BOTTOM COVER OF THE ELECTRIC BOX C) D) CONNECT THE WIRE OF THE SOLAR EXPANSION BOOARD TO THE WHITE TERMINAL NAMED EXPANSION OF THE CONTROL BOARD AS SHOWN IN THE FIGURE REMOVE THE FOUR SCREWS OF THE CONTROL PANEL WITH A SPECIAL SCREWDRIVER REMOVE THE CONTROL PANEL TOWARDS LEFT SIDE... -
Page 43: Wiring Diagram
23.2 WIRING DIAGRAM LAY OUT DESIGN WIRING DIAGRAM EXPANSION B A S E Electric box electronic controller BT5 Solar collector probe BT6 Sanitary boiler probe Solar collector circulation pump FU3 Fuse of solar collector c irculation pump ( 5x20 T 1.6A ) KA1 Relay for collector circulation pump General different i al switch (not included) 230V-1Ph-N-50Hz... - Page 48 A2B Accorroni E.G. S.r.l. - Via d’Ancona, 37 - 60027 Osimo (An) Tel. 071.723991 - Fax 071.7133153 - Web Site: www.accorroni.it - E-mail: a2b@a-2-b.it...
