TransTalk
Kit of Parts (Order Number D-182866)
This kit contains parts that you must use to install the radio module for a single MDW 9031/9031DCP Wireless
Pocket Phone. You use similar parts that are packaged with the telephone to install the battery charger. Refer to
the installation guide packaged with the telephone for additional information.
Parts List
Radio Module 11-foot (3.4 m)
Installing a Single Radio Module
Install high on wall, leaving at least 6-12 inches (15.2-30.5 cm) between antenna and ceiling.
1
Check to make sure the radio module's power cord
is unplugged from the wall outlet before
continuing.
2
Detach the four rubber feet. Apply them to marked
areas on the underside of the radio module.
Kit of Parts 503-801-167 (108406828)
®
9000 Digital Wireless System
MDW 9031/9031DCP Kit of Parts
Power Cord and
Standard AC Adapter
Philips Head
Wood Screws (2)
Rubber Feet (4)
Wall Mounting
Plate
Issue 2 February 1999 1
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Lucent Technologies D-182866
Summary of Contents for Lucent Technologies D-182866
- Page 1 9000 Digital Wireless System MDW 9031/9031DCP Kit of Parts Kit of Parts (Order Number D-182866) This kit contains parts that you must use to install the radio module for a single MDW 9031/9031DCP Wireless Pocket Phone. You use similar parts that are packaged with the telephone to install the battery charger. Refer to the installation guide packaged with the telephone for additional information.
- Page 2 Plug the power cord/AC adapter into a properly grounded 3-prong wall outlet. CAUTION: Never connect or disconnect line cords while the radio module is plugged into the wall outlet. TransTalk is a trademark of Lucent Technologies. 2 Issue 2 February 1999 Kit of Parts (108406828) 503-801-167...
