VMX12 ’91 SUPPLEMENTARY SERVICE MANUAL: 2EN-AE1 VMX12 ’93 SUPPLEMENTARY SERVICE MANUAL: 2EN-AE2 VMX12 ’96 SUPPLEMENTARY SERVICE MANUAL 1995 by Yamaha Motor Co. Ltd. 1st Edition, July 1995 All rights reserved. Any reprinting or unauthorized use without the written permission of Yamaha Motor Co., Ltd.
Page 4
NOTICE This manual was written by the Yamaha Motor Company Ltd. primarily for use by Yamaha dealers and qualified mechanics. It is not possible to put an entire mechanic’s education into one manual, so per- sons using this book to perform maintenance and repairs on Yamaha motorcycles should have a basic understanding of the mechanical concepts and procedures inherent in motorcycle repair technology.
Page 5
HOW TO USE THIS MANUAL CONSTRUCTION OF THIS MANUAL This manual consists of chapters for the main categories of subjects. (See “Illustrated symbols”) 1st title 1 : This is a chapter with its symbol on the upper right of each page. 2nd title 2 : This title appears on the upper of each page on the left of the chapter symbol.
Page 6
EB003000 ILLUSTRATED SYMBOLS Illustrated symbols 1 to 9 are printed on top right of each page and indicate the subject of each chapter. 1 General information 2 Specifications 3 Periodic inspections and adjustments 4 Engine 5 Cooling system 6 Carburetion 7 Chassis 8 Electrical 9 Troubleshooting...
MOTORCYCLE IDENTIFICATION INFO GENERAL INFORMATION MOTORCYCLE IDENTIFICATION VEHICLE IDENTIFICATION NUMBER The vehicle identification number 1 is stamped into the right side of the steering pipe. Starting serial number: JYA2WEE0 TA050101 (USA) JYA2WFC0 TA012101 (California) NOTE: The vehicle identification number is used to identify your motorcycle and may be used to register your motorcycle with the licensing au- thority in your state.
SPECIAL TOOLS INFO SPECIAL TOOLS Refer to the list provided to avoid errors when placing an order. The proper special tools are necessary for com- P/N. YM-jjjjj, YU-jjjjj plete and accurate tune-up and assembly. Us- YS-jjjjj, YK-jjjjj ing the correct special tool will help prevent US, CDN ACC-jjjjj damage caused by the use of improper tools or...
SPEC MAINTENANCE SPECIFICATIONS ELECTRICAL Model VMX12 Rectifier: Model/manufacturer SH662-12/SHINDENGEN Capacity 25 A Withstand Voltage 200 V Electric starter system: Type Constant mesh type Starter motor: Model/manufacturer SM-13/MITSUBA Output 0.65 kW Brush overall length 12.5 mm (0.49 in) <Limit> <5.0 mm (0.20 in)> Commutator diameter 28 mm (1.10 in) <Wear limit>...
INSP ENGINE OIL REPLACEMENT PERIODIC INSPECTION AND ADJUSTMENT ENGINE ENGINE OIL REPLACEMENT 1. Start the engine and let it warm up for several minutes. 2. Stop the engine and place an oil pan under the drain bolt. 3. Remove: S Oil filler cap 1 4.
Page 14
INSP ENGINE OIL REPLACEMENT 6. Install: S Drain bolt Drain bolt: 43 Nm (4.3 mSkg, 31 ftSlb) NOTE: Always use a new gasket. 7. Fill: S Crankcase Recommended oil: At 5_C (40_F) or higher A : SAE 20W40 type SE motor oil At 15_C (60_F) or lower B : SAE 10W30 type SE motor oil Oil quantity:...
INSPECTION AND REPAIR ENGINE OVERHAUL INSPECTION AND REPAIR CRANKSHAFT AND CONNECTING ROD 1. Measure: S Runout (crankshaft) Out of specification ! Replace. Runout: Less than 0.03 mm (0.0012 in) 2. Inspect: S Main journal surfaces S Crank pin surfaces S Bearing surfaces Wear/Scratches ! Replace.
Page 16
INSPECTION AND REPAIR F Put a piece of Plastigauge on each main journal. NOTE: Do not put the Plastigauge over the oil hole in the main journal of the crankshaft. F Install the lower half of the bearings into the crankcase (lower) and assemble the crank- case halves.
Page 17
INSPECTION AND REPAIR F Clean the bearings, crank pins and bearing portions of the connecting rods. F Install the upper half of the bearing into the connecting rod and lower half of the bearing into the connecting rod cap. NOTE: Align the projection of the bearing with the notch of the cap and connecting rod.
Page 18
INSPECTION AND REPAIR 5. Select: S Main journal bearing (J S Crank pin bearing (P Selection of bearings: Example 1: Main journal bearing F If “J ” on the crankcase is “6” and “1” on the crankweb, then the bearing size for “J ”...
INSPECTION AND REPAIR BALANCER SHAFT 1. Measure: S Oil clearance (balancer shaft bearing) Out of specification ! Replace bearing. Oil clearance: 0.020 X 0.048 mm (0.0008 X 0.002 in) Measurement steps: F Clean the bearings, balancer shaft and bear- ing portions of the crankcase. F Place the crankcase (upper) on a bench in an upside down position.
Page 20
INSPECTION AND REPAIR 2. Select: S Balancer shaft bearing Selection of bearings: Example: F If “J ” on the crankcase is “6” and “2” on the balancer shaft, then the bearing size for “J ” Bearing size of J Crankcase J –...
