Bricon 100 Manual

Electronic clocking device
Hide thumbs Also See for 100:
Table of Contents

Advertisement

Quick Links

BRICON Electronic Clocking Device
Belgian Racing pigeons Information and registration system
Manual for basketing with BRICON on the loft
Tel: +32 (0)3/ 777 39 74
Fax: +32 (0)3/ 778 07 35
e-mail: bricon@bricon.be
Contacts: Ludo Wille: GSM +32 (0)475/ 25 30 21
BRICON 100/500/1000.
BA-BSC/TW -ENG/08
BRICON nv
Hoge Heerweg,49
9100 Sint-Niklaas
België
Website: www.bricon.be

Advertisement

Table of Contents
loading

Related Manuals for Bricon 100

Summary of Contents for Bricon 100

  • Page 1 BRICON Electronic Clocking Device Belgian Racing pigeons Information and registration system Manual for basketing with BRICON on the loft BRICON 100/500/1000. BA-BSC/TW -ENG/08 BRICON nv Hoge Heerweg,49 9100 Sint-Niklaas België Tel: +32 (0)3/ 777 39 74 Fax: +32 (0)3/ 778 07 35 Website: www.bricon.be...

  • Page 2: Table Of Contents

    1.3. What are the advantages of RFID? 1.4. RFID and electronic clocking. 2. The BRICON range. 2.1. Advantages of the Bricon system. 2.2. The three types of electronic clocks In the BRICON range. 2.2.1. Little BRICON 100. 2.2.2. Little BRICON 500. 2.2.3. .Little BRICON 1000.
  • Page 3 5. Use data. 5.1. View data from the EC. 5.2. Delete data from the EC. 5.3. Printing data from the EC. 5.3.1. The overview list in detail. 5.3.2. Training clocking list in detail. 5.3.3. Race clocking list in detail. 5.3.4. The pigeon list in detail. 5.3.5.

  • Page 4: Introduction

    The BRICON electronic clock (EC). Electronic clocking on the loft. 1. Introduction 1.1. Electronic clocking systems, the basic principles. The basic principle of an electronic clocking device is the identification of a pigeon from a distance or identification without direct contact. RFID (Radio Frequency Identification) is one of the techniques used for this purpose.

  • Page 5: Rfid And Electronic Clocking

    An electronic clocking system actually is an RFID system composed of three elements: - a transponder or chip ring - a part in the club (universal basketing antenna, UBA), the BRICON CLUBSYSTEM, - a part at the fancier's loft (loft antenna) - and a part in which the data are stored.

  • Page 6: The Bricon Range

    - the BRICON antennas don’t need to be adjusted. - the BRICON antennas are easy to install (flat surface; 2cm high ) and can be placed under the arrival board. - BRICON gives a 2 year warranty on the antennas.

  • Page 7: The Three Types Of Antennas In The Bricon Range

    An own printer can be connected, 7 different lists can be printed. Modem / fax can be connected for the announcements. Little Little BRICON 100/500/1000 2.3.The three types of antennas in the BRICON range. 2.3.1. 2-field antenna. 28 cm wide registers on the total surface. 2.3.3. 4-field antenna.

  • Page 8: Programming The Antennas

    You can set up your language (see Set up your language.). 3.1. Programming the antennas. Before you can start with the Bricon Electronic Clocking Device, the antennas need to be programmed. Make the set up as demonstrated in item Set up. After the set up, follow the steps below.
  • Page 9 If this is not sufficient extra cable can be placed between the antennas.The Electronic Clock (EC) is also connected to the antennas.The maximum length of a set up is about 100 m. Between the first and the second antenna an adapter cable is placed. An end plug is placed on the last open end of the set up.
  • Page 10 3.2.1. Set up. Presentation of a simple set up. (*)The power supply and the number of adapter cables is depending on the electricity consumption of the complete network. (see Which power supply to use?.)
  • Page 11 3.2.2. Which power supply to use?. 3.2.2.1. Two types of power supply. Type of power supply Type 1= up to 1500 mA Type 2= up to 6000 mA 3.2.2.2. Calculation of the electricity consumption. Fill in the table below. Calculate the total electricity consumption : total Electronic clock x 70 mA =...
  • Page 12 The entrance to the inside of the loft must be smaller than the length of the antennas. A tunnel is not necessarry for BRICON antennas, the antenna registers over the whole surface ! It is recommended to slow down the pigeons the moment they enter the detection field .This to make sure...
  • Page 13 Figure 2 Top view Entrance Arrival board 2 cm. 5 cm. Detection field Antenna Cable Cable 3.3. Testing the antennas. After programming the antennas as explained in Programming the antennas, the system can be tested. Next steps need to be followed : - Little 1000 - When you connect the EC, wait for a long >Clocking...
  • Page 14 Repeat the last two steps for each antenna using another ring. 3.4. Coupling the electronic chip ring to the national foot ring. An advantage of the BRICON system is that the fancier can pre-couple his pigeons at home. When this pre-coupling is done he can already start using the sytem for training sessions.To take part in official races, the pre-...
  • Page 15 - MENU (5)- On the new display 5 submenus appear. (The 1.Race number between brackets indicates the 2.Use data number of submenus.) We only see 3 submenus. By pressing “↓” , or by entering >3.Options the figure before the submenu on the EC, a 4.Set up submenu can be selected.
  • Page 16 Are data below correct ? If the information is correct press <OK>. <C>NO <OK>YES BE-99-4210569 3.5. Clocking. 3.5.1. Clocking a race. Make a set up as dicribed in Set up. CLOCKING MODE When the EC is connected it automatically goes With 1 antenna.
  • Page 17 3.5.1.1.Extra functions during clocking. Nr:01 -Press“1”: the display shows al connected antennas. Press <C>. <C> ACTIVATE MODULE? - Press“2”: Press <OK> to activate the storing module. <C> NO <OK> YES CLOCK TRAINING? -Press “3”: Press <OK> for deactivating the clocking of training races (during the race). <C>...
  • Page 18 The clocked pigeons stay in the memory of the EC till they will be deleted manually (see Delete data from the BA. ). A pigeon can be clocked only once, to clock the pigeon again you need to delete his data ! 4.
  • Page 19 Attention: all released data need to be deleted before basketing can start ( see Delete data from the EC.) 4.2. Read. Function: This menu is used in the club to read the clock - Little 1000 - > Clocking This is the start-up menu. Menu Time : 16:14:16 - Little 1000 -...
  • Page 20 4.3. Placing bets. - Little 1000 - > Clocking This is the start-up display. Menu Time : 16:14:16 - Little 1000 - Clocking With the arrow “↓” on the display of the EC the ‘Menu’ is selected. > Menu Press <OK>. Time : 16:14:19 On the new display 5 submenus appear (the - MENU (5) -...
  • Page 21 4.4. Listing designated pigeons with the antenna. Here a designation list can be made. The big advantage is that a list of designated pigeons can be filled in at home. If this menu is used it is not important anymore to give the pigeons in line at the moment of basketing. Is this menu not used the pigeons should be basketed in line, first nominated first…...
  • Page 22 In a new EC 3 races are pre-programmed ( >97 : Race 1 race 1, race 2, race 3). New races can be 98 : Race 2 programmed via your BRICON CLUB 99 : Race 3 SYSTEM. Press <OK>. Use antenna to Select <OK>...
  • Page 23 If you want to put a pigeon on a position which was already taken, you have to enter the BE-00-5041173 position (in the example: position 1). All the following designated pigeons will automatically 0 to delete. move one place downwards. (This is the result Give position: of the example shown.
  • Page 24 4.5. Listing designated pigeons without antenna. Here a designation list can be made. The big advantage is that a list of designated pigeons can be filled in at home. If this menu is used it is not important anymore to give the pigeons in line at the moment of basketing. Is this menu not used the pigeons should be basketed in line, first nominated first…...
  • Page 25 BE-00-5041173 Desig. : The first designated pigeon is shown on the display. Press <OK> to see the next <C> Stop designated pigeon. <OK> Continue Designated... Print list ? Press <OK> to print the list of designations. <C> NO <OK> YES How many copies? Enter the number of copies.
  • Page 26 Pigeon : Choose the second designated pigeon from >BE-00-5041196 the list. With the vertical arrows you can scroll. BE-00-5041140 Only the pigeons from the pigeon list are BE-00-5269121 shown (see Options. ) and can be designated. Nr:BE-00-5269196 Check the number, give the position of the 0 to delete pigeon or confirm with <OK>...
  • Page 27 4.6. Delete the list of designations. - Little 1000 - > Clocking This is the start-up menu. Menu Time : 16:14:16 - Little 1000 - Clocking By pressing the arrow “↓” on the display of the EC the item “Menu” is selected >...
  • Page 28 4.7. Print the list of designations. Function: In this menu a list of designated pigeons can be printed from your - Little 1000 - > Clocking This is the start-up menu. Menu Time : 16:14:16 - Little 1000 - Clocking By pressing the arrow “↓”...
  • Page 29 How many copies? Enter the number of copies. A list of the designations for that race is printed . 5. Use data. 5.1. Viewing data from the EC Function: In this item training results and/or the race results which are listed in the EC can be viewed.
  • Page 30 When pigeons are clocked from a race/training we can see an overview. 00-5261478 P: 1 With the vertical arrows you can scroll. On the 10/07 11:25:27 display the ring number is shown, the place of Training arrival, the date of arrival, the time of arrival, Trap: 1 the (training) race and the antenna number the pigeon was clocked with.
  • Page 31 5.2. Delete data from the EC. Function: Here the results of a training and released data of a race can be deleted from the EC . - Little 1000 - > Clocking This is the start-up menu. Menu Time : 16:14:16 - Little 1000 - Clocking By pressing the arrow “↓”...
  • Page 32 Delete The released designations will also be deleted designations? Press <OK> to delete. <C> No <OK>Yes All released data is now deleted. 5.3. Printing data from the EC. - Little 1000 - > Clocking This is the start-up menu. Menu Time : 16:14:16 - Little 1000 - Clocking...
  • Page 33 8 submenus will appear on the display. Choose what kind of data you want to print. 1.”Overview”: prints out a complete overview of what is in the EC.(see The overview list in detail) 2.”T.clock list” prints the training results from the EC (see Training clocking list in detail.) 3.”R.clock list”...
  • Page 34 5.3.1.The overview list in detail. ------------------------------------------------------------------------------------------------------------------------------------------------ Overview list ------------------------------------------------------------------------------------------------------------------------------------------------ Date : 24/07/00 (1) Member : XXXX XXXX (2) Name : XXXX XX (3) X-Coordinate : XXXXXX (4) Y-Coordinate : XXXXXX (4) Print date : XX XX XX XX:XX:XX (1) ------------------------------------------------------------------------------------------------------------------------------------------------ Check : Basketing (5) Sync.
  • Page 35 5.3.2.Training clocking list in detail. ------------------------------------------------------------------------------------------------------------------------------------------------ List of the clocked pigeons. ------------------------------------------------------------------------------------------------------------------------------------------------ Race nr : _____ Date : XX/XX/XX (1) RACE: Training (10) Member : XXXX XXXX (2) Name : XXXXX XX (3) X-Coordinate : XXXXXX (4) Y-Coordinate : XXXXXX (4) Print date : XX/XX/XX XX:XX:XX (5) ------------------------------------------------------------------------------------------------------------------------------------------------...
  • Page 36 5.3.3.Race clocking list in detail. ------------------------------------------------------------------------------------------------------------------------------------------------ List of the clocked pigeons. ------------------------------------------------------------------------------------------------------------------------------------------------ Race nr : _____ Date : XX/XX/XX (1) RACE: XXXX (10) Member : XXXX XXXX (2) NAME : XXXX XX (3) X-Coordinate : XXXXXX (4) Y-Coordinate : XXXXXX (4) Print date : XX/XX/XX XX:XX:XX (5) ------------------------------------------------------------------------------------------------------------------------------------------------...
  • Page 37 5.3.4.The pigeon list in detail. ------------------------------------------------------------------------------------------------------------------------------------------------ pigeon list ------------------------------------------------------------------------------------------------------------------------------------------------ Date : XX/XX/XX Member : XXXX XXXX (2) Name : XXXX XX (3) X-Coordinate : XXXXXX (4) Y-Coordinate : XXXXXX (4) Print date : XX/XX/XX XX:XX:XX (5) ------------------------------------------------------------------------------------------------------------------------------------------------ Nr. El.-ring ID ring Nr.
  • Page 38 5.3.5. The race list in detail. ------------------------------------------------------------------------------------------------------------------------------------------------ Races ------------------------------------------------------------------------------------------------------------------------------------------------ Date : XX/XX/XX Member : XXXX XXXX (2) Name : XXXX XX (3) X-Coordinate : XXXXXX (4) Y- Coordinate : XXXXXX (4) Print date : XX/XX/XX XX:XX:XX (5) ------------------------------------------------------------------------------------------------------------------------------------------------ Nr. Race Nr.
  • Page 39 5.3.6. The list of designated pigeons in detail. ------------------------------------------------------------------------------------------------------------------------------------------------ List of designated pigeons ------------------------------------------------------------------------------------------------------------------------------------------------ Race nr : _____ Date : XX/XX/XX (1) RACE: XXXX (10) Member : XXXX XXXX (2) Name : XXXX XX (3) X-Coordinate : XXXXXX (4) Y-Coordinate : XXXXXX (4) Print date : XX/XX/XX XX:XX:XX (5) ------------------------------------------------------------------------------------------------------------------------------------------------...
  • Page 40 5.3.7.The basketing list in detail. ------------------------------------------------------------------------------------------------------------------------------------------------ Basketing list ------------------------------------------------------------------------------------------------------------------------------------------------ Race nr. : _____ Date : XX/XX/XX (1) RACE: XXXXXX (9) Member : XXXX XXXX (2) Name : XXXX XX (3) X- Coordinate : XXXXXX (4) Y- Coordinate : XXXXXX (4) Print date : XX/XX/XX XX:XX:XX (5) Strike IN: XX/XX/XX XX:XX:XX (6)
  • Page 41 5.3.8.The log book in detail. ------------------------------------------------------------------------------------------------------------------------------------------------ Log book ------------------------------------------------------------------------------------------------------------------------------------------------ Date : XX/XX/XX Member : XXXX XXXX (2) Name : XXXX XX (3) X- Coordinate : XXXXXX (4) Y- Coordinate : XXXXXX (4) Print date : XX/XX/XX XX:XX:XX (5) ------------------------------------------------------------------------------------------------------------------------------------------------ Ring : Time Eval Ring...
  • Page 42 5.4. Viewing the pigeonlist. - Little 1000 - > Clocking This is the start-up menu. Menu Time : 16:14:16 - Little 1000 - Clocking By pressing the arrow “↓” on the display of the EC the item “Menu” is selected >...
  • Page 43 5.5. Viewing races in the EC. - Little 1000 - > Clocking This is the start-up menu. Menu Time : 16:14:16 - Little 1000 - Clocking By pressing the arrow “↓” on the display of the EC the item “Menu” is selected >...
  • Page 44 6. Options 6.1. Viewing the pigeonlist. - Little 1000 - > Clocking This is the start-up menu. Menu Time : 16:14:16 - Little 1000 - Clocking By pressing the arrow “↓” on the display of the EC the item “Menu” is selected >...
  • Page 45 6.2. Delete data from the pigeon list. - Little 1000 - > Clocking This is the start-up menu. Menu Time : 16:14:16 - Little 1000 - Clocking By pressing the arrow “↓” on the display of the EC the item “Menu” is selected >...
  • Page 46 Delete data ... Enter your password. Standard 0000 (four times zero). This Password: password can be changed. (see Change Password.) Press <OK>. Delete Designations? Press <OK> to delete designations. <C> NO <OK> YES Select the pigeon you want to remove. With Pigeon : the vertical arrows you can scroll in the list.
  • Page 47 - SETUP (5) - >1.Printer Setup Select “Printer Set-up” 2.Clock 3.Antenna Press <OK>. 4.Basketing 5.Other -PRINTER SET - >1.Copies Select “Copies.” 2.Page lenght Press <OK>. 3.Auto print Number of pages The standard value is 2. Current: 2 Press <OK> to change the number of pages. <C>Esc<OK>Chang Number of pages Enter the new number of printouts (f.e.
  • Page 48 - MENU (5) - On the new display 5 submenus appear (the 1.Race number between brackets indicates the 2.Use data number of submenus). We only see 3 submenu’s. By pressing the “↓” key or simply 3.Options through pressing the number of the submenu >4.Set up on the keyboard of the EC, the submenu will 5.PC Interface...
  • Page 49 7.3. Set Auto print. Printing a basketing list is time-consuming (depending on the printer). In this menu you can set up ‘automatical printout’ of the basketinglist after basketing. - Little 1000 - > Clocking This is the start-up menu. Menu Time : 16:14:16 - Little 1000 - Clocking...
  • Page 50 Automatic When <C> is pressed no basketing list will printing when be printed. The basketing list can be made afterwards and/or on another location (see basketing? Print data from the EC). <C> NO <OK> Yes Automatic printing when The ‘automatical printout’ is switched off. basketing?C.:NO <C>Esc <OK>Chang 7.4.
  • Page 51 - SETUP (5) - 1.Printer Setup >2.Clock Select “Clock” 3.Antenna Press <OK>. 4.Basketing 5.Other - CLOCK - Select “Set time”. >1.Set Time Press <OK>. 2.Clock Type Date : 11/07/00 The current date and time are shown on the Time : 10:31:45 display.
  • Page 52 7.5. Set the clock type. This menu is used to select the clock type. There are three different methods of basketing: 1. Using the atomclock. 2. Using manual settings. 3. Using a masterclock. - Little 1000 - > Clocking This is the start-up menu. Menu Time : 16:14:16 - Little 1000 -...
  • Page 53 Make a selection. Press 1 for ‘Atomclock’ (used by most of the European countries, the clubsystem is using a 1. Atomclock Motherclock witch get synchronised 2. Manual automatically ). Press 2 for ‘Manual’ (each clock time needs to 3. Masterclock be set manual, for basketing and for read as Make your choice well).
  • Page 54 - BASKETING - >1.Basket Nb. Select “Basket Nb” 2.Use M/min Press <OK>. 3.Basketing:FOS Enter basketnr.? The default setting is ‘NO’, the basketingnumber will not be asked during basketing. Current: NO Press <OK> to change the setting. <C>Esc<OK>Chang Enter basketnr.? Press <OK> to ask for the basket number during basketing.
  • Page 55 - SETUP (5) - 1.Printer Setup 2.Clock Select “Basketing” 3.Antenna Press <OK>. >4.Basketing 5.Other - BASKETING - 1.Basket Nb. Select “Use M/min.” >2.Use M/min Press <OK>. 3.Basketing:FOS The default setting is ‘YES’, the speed will be Use M/min.? calculated by read and printed on the ‘Race clocking list’.
  • Page 56 7.8. Set your language. - Little 1000 - > Clocking This is the start-up menu. Menu Time : 16:14:16 - Little 1000 - Clocking By pressing the arrow “↓” on the display of the EC the item “Menu” is selected >...
  • Page 57 7.9. Change password. - Little 1000 - > Clocking This is the start-up menu. Menu Time : 16:14:16 - Little 1000 - Clocking By pressing the arrow “↓” on the display of the EC the item “Menu” is selected > Menu Press <OK>.
  • Page 58 BRICON electronic clocks Input 12Volts. Power consume Little100 70 mA Power consume Little 500 70 mA Power consume Little 1000 70 mA Connections Little 100/500/1000 RS485 Connections 1000 Centronics, RS232 Capacity 100 100 pigeons Capacity 500 500 pigeons Capacity 1000...
  • Page 59 The BRICON CLUBSYSTEM is homologated by your federation. Abuse of this device or lending it to a third party, who is not part of the management or who is not working personnel, is an offence. For extra information or service contact your agent.
