- Page 1 REDDI-BILT BARBECUES ASSEMBLY MANUAL & PARTS LIST MANUEL DE MONTAGE & LISTE DE PIECES 1159-94 1159-97 RETAIN FOR FUTURE REFERENCE VEUILLEZ CONSERVER POUR REFERENCE ULTERIEURE 1-800-265-2150 info@omcbbq.com S18791 REV A 01/08...
- Page 10 KEY # ITEM # DESCRIPTION 34120194 CASTING BOTTOM 10473-E392 CASTING TOP 10081-BM60 NAMEPLATE 10958-E404A TOP CASTING INSERT 10571-6 HEAT INDICATOR 10240-15 HINGE PIN S21237 HINGE SPACER S21233 HITCH PIN CLIP 38170121 GRID - PORCELAIN 10222-T425 FLAV-R-WAVE 10225-E391 GRID - WARMING RACK S10017 BURNER/VENTURI ASSY 10342-244...
- Page 11 KEY # ITEM # DESCRIPTION S13005 BURNER ROTISSERIE S21362 SPRING Y-11990 HEX NUT 10696-109 REARBURNER-ORIFICE LP 10696-160 REARBURNER-ORIFICE NG S21420 PUSH NUT S21084 SCREW - #14x3/4 10338-390 HANDLE 10892-15 CASTOR Y-11561 BOLT – 1/4:20 x 1 3/4 Y-11546 SCREW- 1/4-20 X 5/8 Y-11545 SCREW –...
