WARNING
Improper installation, adjustment,
alteration, service or maintenance
can cause injury or property
damage.
Read the installation, operation
and maintenance instructions
thoroughly before installing or
servicing this equipment.
DANGER
Failure to follow these
instructions could result in fire
or explosion that could cause
property damage, personal
injury or death.
DANGER
DO NOT use gas grill for indoor
cooking or heating. TOXIC fumes
can accumulate and cause
asphyxiation. DO NOT use in or on
boats or recreational vehicles.
WARNING
FOR YOUR SAFETY:
For outdoor use only, and
shall not be sued in a building,
garage or any other enclosed
area.
Gas BBQ for Outdoor Use
SAVE THESE INSTRUCTIONS FOR FUTURE REFERENCE.
IF YOU ARE ASSEMBLING THIS UNIT FOR SOMEONE
ELSE, GIVE THIS MANUAL TO HIM OR HER TO SAVE FOR
FUTURE REFERENCE.
FOR CUSTOMER SERVICE：
CALL 1-877-631-2845 (TOLL-FREE)
10:00 A.M. – 7:00 P.M. (EST), MONDAY-FRIDAY
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 10107997 and is the answer not in the manual?

Questions and answers

Related Manuals for Broil King 10107997

Summary of Contents for Broil King 10107997

  • Page 1 Gas BBQ for Outdoor Use WARNING Improper installation, adjustment, alteration, service or maintenance can cause injury or property damage. Read the installation, operation and maintenance instructions thoroughly before installing or servicing this equipment. DANGER Failure to follow these instructions could result in fire or explosion that could cause property damage, personal injury or death.

  • Page 2: Grill Operation

    Grill Operation 1-2-3 Before Grilling Step 1 Keep your grill a safe distance away from buildings.* Step 2 Always perform a Leak Test on all connections * Step 3 Keep children away from the grill. During Grilling (To avoid tripping safety valves, please follow these instructions carefully.) Step 1 Open the lid and turn the gas cylinder on slowly.

  • Page 3: Table Of Contents

    Table of Contents For Your Safty ........................4 Illustrated Part List......................7 Assembly Instructions......................7 Operating the Grill......................10 Checking for Leaks......................11 Lighting the Grill.......................11 Care and Maintenance.....................14 Troubleshooting......................15 Warranty Program......................16 SQ280 Owner’s Manual...

  • Page 4: For Your Safty

    For Your Safety Dear Valued Customer, Congratulations on your new barbecue grill purchase! You’ve made the right choice. In this manual, you will find assembly instructions, suggestions for grilling and helpful hints, as well as guidelines for the safe operation, proper care and use of your grill.
  • Page 5 Safe Locations for Use Of This Outdoor Grill DANGER Never use this outdoor grill inside any building, garage, shed or breezeway, or inside any boat, trailer or recreational vehicle to prevent a possible fire and to prevent the possibility of carbon monoxide poisoning or asphyxiation. WARNINGS Do not use this appliance under overhead combustible surface or covered area (e.g., awnings, umbrellas, porches or gazeboes).
  • Page 6 GENERAL INFORMATION 1. A propane gas cylinder is required for operation. 2. This gas grill is NOT intended for commercial use. 3. Don't obstruct the ventilation opening of the cylinder enclosure. 4. The precaution to be taken in the case of blockage of the Venturi(s). Illustrated Parts List A, Body Assembly…….1PC B, Cooking Grid………...2PCS...

  • Page 7: Illustrated Part List

    Part Description (QTY) Part Description (QTY) Part Description (QTY) Body Assembly…………...1PC Cooking Grid…………..2PCS Grease Cup………………1 PC Leg Handle……………..…1 PC Wheel Cover………..…. 2PCS Wheel…………………….2PCS Heat Shield……………… 1 PC oil cup ...…1 PC Hardware list AA:2PCS BB:2PCS CC:1PC Screw driver Bolt ST4X15 Flat Washer DD:2PCS EE:1PC...
  • Page 8 Step 2 a) Insert the leg handle (D) into the hole on the cart of the body assembly (A), screw two bolts (AA) in to each pre-drilled hole. Tighten by screwdriver until secure. Step 3 a) Unlock the hasp on the body assembly (A) and leg as shown in the illustration.
  • Page 9 Step 6 a) Put the heat shield (G) onto the heat shield support in the body assembly (A). b) Put the two cooking grids (B) on the support of the body assembly (A). c) Slide the grease cup (C) into the guide underneath the body assembly (A).

  • Page 10: Operating The Grill

    Fully Assembled View Right Side Left Side Operating the Grill CAUTION: Use only the regulator provided. If a replacement is necessary, call our customer service center. The use of unauthorized parts can create an unsafe condition and environment. The propane gas supply cylinder used must be a) Constructed and marked in accordance with the Specifications for LP Gas Cylinders of the U.S.

  • Page 11: Checking For Leaks

    the burner and burner ports. Connect regulator valve and hand tighten firmly. Disconnect the propane cylinder from the regulator valve when the grill is not in use. DO NOT obstruct the flow of combustion air or ventilation air to the grill. Arrange the propane cylinder for vapor withdrawal and equipped with a listed overfill prevention device (OPD).
  • Page 12 Lighting the Main Burner WARNING: Attempting to light the burner with the lid closed may cause an explosion. Make sure there are no obstructions of airflow to the gas unit. Spiders and insects can nest and clog the burner/venturi tube at the nozzle. A clogged burner tube can lead to a fire beneath the appliance.
  • Page 13 FIG. A FIG. B FIG. C Normal: Soft blue flames with yellow tips Poor combustion: Wavy, yellow Out of adjustment: Noisy hard blue between 2.5-5cm (1-2”) high. flames- too little air. flames – too much air Flare-ups: “Flare-ups” sometimes occur when food drippings fall onto the hot heat plate or burner and ignite. Some flaring is normal and desirable as it helps impart the unique flavors associated with grilled foods.

  • Page 14: Care And Maintenance

    Care and Maintenance Always allow the grill to completely cool off before covering the grill to prevent corrosion from condensation. Caution: All cleaning and maintenance should be done when the grill is cool, with the fuel supply turned off at the control dial and the propane cylinder disconnected.

  • Page 15: Troubleshooting

    Troubleshooting Problem Possible Cause Prevention/Cure Burner will not light using a match. No gas flow. Check if propane cylinder is empty. If empty, replace. Obstruction of gas flow. Clear burner tube. Disengagement of burner to valve. Reengage burner and valve. Spider webs or insect nest in venturi.

  • Page 16: Warranty Program

    Warranty Program Proof of purchase is required to access this warranty program, which is in effect from the date of purchase. If unable to provide proof of purchase or after the warranty has expired, customers will be subject to parts, shipping and handling fees. Full 30-Day Warranty Any missing parts can be replaced at no charge within 30 days from the date of purchase with a valid proof of purchase.
