INNOVAPLAS Lumi-o MAJESTIC 8000 Assembly Instructions

MAJESTIC 8000 WITH CLASSIC LADDER 6004
accessory box SKU # 8000
Contents of
SCREW KIT 140-0062
A B C D E
x4 x4 x4 x10 x6
x2
Install the step on a flat surface.
Do not jump or dive from the step or ladder.
Remove the step from water when temperatures drop below freezing.
In winter, the step should be stored in an area protected from snow.
Never lift the step by its handrails.
Use BATTERY operated tools to avoid electric shock near water.
Ensure no corrosive materials are added to the step or harware kit.
The step must be installed per manufacturer's instructions.
File off all stripped or sharp edges before assembly to avoid injuries
and liner damage.
The manufacturer is not responsible for damages or injuries caused
by improper installation or use of product.
To ease the installation of handrails and bolts, use a screwdriver to
line up the holes.
x6
WARNING
2257 route 139
Drummondville, Québec
J2A 2G2
WWW.INNOVAPLAS.COM
Contents of the ladder box
SCREW KIT 140-0050
F A G D B C
x2
x2 x2 x26 x4 x4
Security strap
x2
A
D
x4
A
x4
B
x4
C
x4
SKU # 6004
x2
x2
x4
x2
x2

Required tools

Phillips #2
Phillips #3
Step shell
1) Insert the two 39" posts into
the step recesses and secure
them in place with the bolts,
washers and nuts provided.
2) Slide the two spacers on the
top post. Do not secure yet.
3) Insert the handrail over the left
side posts. Secure it using the
screws provided.
MANUFACTURER WARRANTY
1 year on step and ladder
1 year on hardware.
REV. 03/05/2020 PN:
A weather-resistant
padlock is
recommended.
Maximum functional
width of 1/4 inch.
(not included)
3/8 drill bit
5/16 drill bit
Phillips bit
7/16 wrench
Sand
(not included)
PG:1
