MAJESTIC 8000 WITH CLASSIC 6004
Contents of SKU box # 8000
SCREW KIT 140-019
x4
x4
x10
x4
x4
x1
WARNING
Do not dive or jump from step or ladder.
Use BATTERY operated tools to avoid electric shocks.
Install step on flat surface, following the manufacturers
instructions.
Remove step from pool during freezing climate season.
Manufacturer cannot be held responsible for injuries
caused by abusive use of product.
Ask your city about specific regulations that apply to
your above-ground pool and ladder.
250 industrial blv,
St-Germain (Québec),
Canada J0C1K0
x2
x6
Contents of the ladder box SKU # 6004
SCREW BAG 558-001
x4 x4
x2
x2
x2
x22
Majestic step
(not incl.)
Sand
A
x4
x4 x4 x4
x4
x2
x2
Security strap
x2
Tools Required
A weather resistant padlock
is recommended.
Maximum functional
width is 1/4 inch.
1) Insert the two 39" posts into
the step recesses and secure
them in place with the bolts,
washers and nuts provided.
2) Slide the two spacers on
the top post. Do not secure yet.
3) Insert the handrail over the
left side posts. Secure it using
the screws provided.
Snap the post cover.
x2
x1
x1
x2
(not included)
5/16"
Drill Bit
PG. 1
REV. 02/02/10
Advertisement
Table of Contents
Related Manuals for INNOVAPLAS MAJESTIC 8000
Summary of Contents for INNOVAPLAS MAJESTIC 8000
- Page 1 MAJESTIC 8000 WITH CLASSIC 6004 Contents of the ladder box SKU # 6004 Contents of SKU box # 8000 SCREW KIT 140-019 SCREW BAG 558-001 x4 x4 Security strap WARNING Majestic step Tools Required (not included) A weather resistant padlock is recommended.
- Page 2 1) Make sure to leave a 1) Slide the platform on the flanged post. 4) Once inserted in the 1/4" clearance between spacers, use the 29.25" 2) Insert the 29.25" hollow post, the bottom spacer, and hollow post as a pivot to on the other side, through the the top of the step.
- Page 3 1) Trace a line on each post at 39 inches from the ground for 48'' & 1) Slide the platform downwards and let it sit on the top seat of 52'' pools. If you have a 54'' pool, trace a line at 40.5'' from the ground. the pool.
- Page 4 MAJESTIC 8005 Majestic step Sand Contents of box # sku 8005 (not included) SCREW KIT 8005MJ08 WARNING Tools required (not included) Do not dive or jump from step or ladder. Use BATTERY operated tools to avoid electric shocks. Install the pool step on a flat surface Remove step from pool during freezing climate season.
- Page 5 2) Secure the 1) Fill the counterweight counterweight to cover with the the brim with sand. screws provided. 1) Slowly submerge the step into the pool. Make sure you do not damage the pool liner in the process. CAUTION* To prevent a pool liner puncture, install all Step Cup as specified and keep a minimum of 1"inch gap between the pool liner and the rear underside of the step.
