Model
1190
Data
Collection
Platform
All Weather Inc. • 1065 National Drive • Sacramento, CA 95834 • USA • 800.824.5873 • www.allweatherinc.com
User's
Manual
1190-001
Rev. AA

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 1190 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for All Weather Inc 1190

  • Page 1 Model   1190 Data Collection Platform User’s Manual 1190-001 Rev. AA All Weather Inc. • 1065 National Drive • Sacramento, CA 95834 • USA • 800.824.5873 • www.allweatherinc.com...
  • Page 2 1190 Data Collection Platform User's Manual Copyright © 2011–2021, All Weather, Inc. All Rights Reserved. The information contained herein is proprietary and is provided solely for the purpose of allowing customers to operate and/or service All Weather, Inc. manufactured equipment and is not to be released, reproduced, or used for any other purpose without written permission of All Weather, Inc.
  • Page 3 1190 Data Collection Platform User's Manual Revision History Revision Date Summary of Changes Updated M403316-003 Sheet 4, M403316-019, 3000-A-019, and 3000-B-019 to reflect 2020 Feb 14 new Model 20981 UHF Data Radio installation. 2020 Apr 30 Added explanation of low-voltage battery cut-off device to Backup Battery option Updated 8339-FAA Ceilometer for both RS-232 and RS-485 connections based on v1.76...
  • Page 4: Table Of Contents

    1190 Data Collection Platform User's Manual TABLE OF CONTENTS 1. INTRODUCTION ......................... 1 2. INSTALLATION ........................2 2.1 DCP Installation ........................2 2.2 Sensor Wiring ........................2 2.3 Communication Connections ....................3 2.4 Serial Sensor Wiring ......................4 2.5 Power Wiring ......................... 4 3.
  • Page 5: Introduction

    User's Manual 1. INTRODUCTION The Model 1190 Data Collection Platform (DCP) is used with Automated Weather Observing Systems (AWOS) for collecting and processing sensor signals. Located at the sensor station, the DCP collects data from the sensors, performs error detection on the received information, converts the sensors’ data into engineering units, and transmits a message packet containing sensor data and status information to the Central Data Platform (CDP) once every five seconds.
  • Page 6: Installation

    2.1 DCP INSTALLATION  The Freezing Rain Sensor is connected to a serial The Model 1190 DCP mounts to the sensor tower sensor interface card that is accessed via H4. using Unistrut; the optional barometric pressure (Model 7150 or 7190) and radio kits mount inside the DCP 2.2.1 TB2—MARS Wiring...
  • Page 7: Communication Connections

    1190 Data Collection Platform User's Manual 2.2.7 TB3—Wind Direction Wiring 2.2.3 TB2—Temperature/Relative Humidity Wiring The wind direction sensor is wired to pins 1–3 of TB3. Either a Model 2020 Micro Response Vane or a The Model 5190 Temperature/Relative Humidity sen- Model 2100 Skyvane can be used.
  • Page 8: Serial Sensor Wiring

    1190 Data Collection Platform User's Manual 2. Pin 6 is data receive (RX), and should be con- Model 8339/8340 Ceilometers nected to the laptop’s data transmit (TX) line. 1. Connect the GREEN wire (RS-485 (+)) from the 3. Pin 7 is ground (GND).
  • Page 9 1190 Data Collection Platform User's Manual 2.5.2 DC, Battery Backup, and Solar When lit, the green BATT. CHARGE LED indicates that the battery is charged to operating levels and/or Power Wiring DC power is at normal levels. TB1 on the DCP backplane provides input power...
  • Page 10: Operation

    3. OPERATION 3.1 GENERAL 3.2 MAINTENANCE SWITCH The Model 1190 Data Collection Platform (DCP) is A maintenance switch (SW3) is located on the DCP designed for use with the All Weather, Inc. AWOS backplane, on the lower right side of the board. This aviation weather systems.
  • Page 11: Display Screens

    1190 Data Collection Platform User's Manual The second set of switches, SW2, is used to set the In the screen explanations below, unchanging screen station address, type of wind speed sensor, and the text is shown unbracketed, while explanations of the auxiliary input gain.
  • Page 12 1190 Data Collection Platform User's Manual 3.4.5 Screen 5 3.4.10 Screen 10 This screen displays the current temperature and dew This screen displays the status of the 83339-A point temperature in Fahrenheit and the relative Day/Night sensor if a Model 8364-E Visibility Sensor humidity (RH).
  • Page 13 1190 Data Collection Platform User's Manual 3.4.13 Screen 13 3.4.14 Screen 14 This screen displays fault information for the This screen displays status information for the 8364- E’s Ambient Light Sensor. visibility sensor. Visibility Failure Ambient Light Sensor {visibility sensor decoded error(s)}...
  • Page 14 1190 Data Collection Platform User's Manual 3.4.15 Screen 15 3.4.18 Screen 18 This screen displays the status of the 8364-E’s power This screen displays the reporting value in supplies. Candela of the Ambient Light Sensor. 8364-E Power Supplies Ambient Light Sensor...
  • Page 15 1190 Data Collection Platform User's Manual 3.4.22 Screen 22 Table 4 Present Weather Codes This screen displays cloud height sensor crc error as reported by Model 6490 counts and timeout error counts. CRC errors indicate that communication problems exist. Timeout errors...
  • Page 16 1190 Data Collection Platform User's Manual 3.4.25 Screen 25 3.4.29 Screen 29 This screen contains status information from the This screen reports any detected lightning strikes present weather interface computer. CRC errors more than 10 miles from the installation site, up to 30 indicate that the computer is communicating, but not miles away.
  • Page 17 1190 Data Collection Platform User's Manual 3.4.33 Screens 33 and 34 3.4.37 Screen 38 These two screens show the most recent status This screen shows the number of CRC errors and message received from the lightning sensor. The for- timeouts detected since the sensor was last powered mat of the status message is explained in the Model up.
  • Page 18 If you choose to run the tests, follow the instructions This series of screens allows a Model 8364-E on the succeeding screens until the test cycle is Visibility Sensor to be calibrated using the 1190 complete. DCP’s built-in keypad and display. This series of...
  • Page 19: Led Indicators

    Visibility Sensor’s Ambient Light Sensor (ALS) to be The green PWR. IN LED is lighted when a +15VDC calibrated using the 1190 DCP’s built-in keypad and power source is connected to TB4, pins 5 and 6. display. These screens are only displayed when a Model 8364-E with ALS is installed and commun- 3.5.2 BATT.
  • Page 20: Calibration

    1190 Data Collection Platform User's Manual 4. CALIBRATION No calibration is required with the Model 1190 Data Collection Platform.
  • Page 21: Maintenance

    5. MAINTENANCE No regular maintenance is required with the Model When performing maintenance on any other part of 1190 Data Collection Platform, other than verifying the system, remember to press the maintenance periodically that all cables are connected and in good switch (SW3) prior to beginning maintenance as condition.
  • Page 22: Warranty

    Circular 150/5220-16C. Any defect in design, materials, or workmanship that may occur during proper and nor- mal use during a period of 1 year from date of installation or a maximum or 2 years from shipment will be corrected by repair or replacement by All Weather Inc.
  • Page 23: Specifications

    1190 Data Collection Platform User's Manual 7. SPECIFICATIONS Parameter Specification Display 2 line × 20 character LCD CDP Communication Options RS-232, RS-485, UHF radio Baud Rate 9600 bps Serial Port Parameter Setting 8-N-1 (8 data bits, no parity, 1 stop bit) -40 to +60ºC...
  • Page 24 1190 Data Collection Platform User's Ma 7.1 SUPPORTED SENSORS  Model 2100, 2040/2040C/2040H/2040HC/2040HH/2040HHC, and Model 2020/2030 Wind Sensors  Model 5190 Temperature and Relative Humidity Sensor  Model 8190 Motor Aspirated Radiation Shield (MARS)  Model 7150 or 7190 Barometric Pressure Sensor ...
  • Page 25: Drawings

    1190 Data Collection Platform User's Manual 8. DRAWINGS The following pages contain drawings to aid in the use and maintenance of the Model 1190 DCP. M403316-003 DCP Assembly Drawing (including associated kits) M403316-019 DCP Wiring Diagram 1190-007 Installation Drawing, 1190 DCP Tower Mounting...
  • Page 41 allweatherinc...
  • Page 42 All Weather Inc. 1065 National Drive, Suite 1 Sacramento, CA 95834 1190-001 800.824.5873 February, 2021 www.allweatherinc.com Revision AA...
