Embest BeagleBone-HDMI Cape User Manual page 8

Embest Technology
Pin
8 DAT0_S
9 HDMI_TX0-
10 HDMI_CLK+
11 CLK_S
12 HDMI_CLK-
13 HDMICONN_CEC
14 NC
15 HDMICONN_I2CSCL
16 HDMICONN_I2CSDA
17 GND
18 5V
19 HPLG
2.3 Pin definition of LCD interface
Pin
1 BG0
2 BG1
3 BG2
4 LCD_DATA0
5 LCD_DATA1
6 LCD_DATA2
7 LCD_DATA3
8 LCD_DATA4
9 DGND
10 GG0
11 GG1
12 LCD_DATA5
13 LCD_DATA6
14 LCD_DATA7
15 LCD_DATA8
16 LCD_DATA9
17 LCD_DATA10
18 DGND
19 RG0
20 RG1
21 RG2
22 LCD_DATA11
Copyright © 2012 Embest Technology
Definition
GND
TMDS data 0-
TMDS data clock+
GND
TMDS data clock-
Consumer Electronics Control
NC
IIC master serial clock
IIC serial bidirectional data
GND
5V
Hot plug and play detect
Table 2 LCD interface
Definition
LCD Pixel data bit 0
LCD Pixel data bit 1
LCD Pixel data bit 2
LCD Pixel data bit 3
LCD Pixel data bit 4
LCD Pixel data bit 5
LCD Pixel data bit 6
LCD Pixel data bit 7
GND
LCD Pixel data bit 8
LCD Pixel data bit 9
LCD Pixel data bit 10
LCD Pixel data bit 11
LCD Pixel data bit 12
LCD Pixel data bit 13
LCD Pixel data bit 14
LCD Pixel data bit 15
GND
LCD Pixel data bit 16
LCD Pixel data bit 17
LCD Pixel data bit 18
LCD Pixel data bit 19
Description
Description
