Chapter 5
The demonstration in WinCE is similar to that in Linux system. There is also a WinCE
operating system stored in the CD-ROM for quick demonstration. The following steps will
lead you through the whole process.
1） Format a TF card as FAT32 file system;
2） Copy all the files under wince\image to TF card;
3） Insert TF card into the slot on BeagleBone, and then connect it to your PC
with a USB cable;
4） Press Space on your keyboard when the information in the following table
appears in the HyperTerminal window;
Hit space to enter configuration menu [2156] 3...
Hit space to enter configuration menu [3156] 2...
5） The EBOOT menu appears after you press Space. Please select the options
according to the following table;
--------------------------------------------------------------------------------
Main Menu
--------------------------------------------------------------------------------
[1] Show Current Settings
[2] Select Boot Device
[3] Select KITL (Debug) Device
[4] Network Settings
[5] SDCard Settings
[6] Set Device ID
[7] Save Settings
[9] Enable/Disable OAL Retail Messages
[a] Select Display Resolution
[b] Select OPP Mode
[0] Exit and Continue
Selection: 2
Copyright © 2012 Embest Technology
Demonstration in WinCE
Table 12 Press Space on your keyboard
Table 13 Booting menu
