- Page 1 Embedded HMI-PLC XV-23x-57 Device Description 12/05 AWB2776-1581GB Think future. Switch to green.
- Page 2 None of this manual may be reproduced or processed, duplicated or distributed by electronic systems in any form (print, photocopy, microfilm or any other process) without the written permission of Moeller GmbH, Bonn. Subject to modifications. 12/05 AWB2776.1571GB © by Moeller GmbH...
- Page 3 No liability is accepted for claims for damages arising from a failure or functional defect in the device. All data specified in this document does not represent warranted properties in the legal sense. 12/05 AWB2776.1571GB © by Moeller GmbH...
-
Page 4: Table Of Contents
11 Display Technology, Backlight ................ 26 12 Maintenance and Repair................... 27 13 Disposal......................28 14 Technical Data....................29 15 EU Conformity/Safety ..................31 15.1 EMC ........................31 15.2 Explosion protection ................... 31 15.2.1 Zone 22, Category 3D ..................... 31 12/05 AWB2776.1571GB © by Moeller GmbH... -
Page 5: Explanation Of Symbols
Electrostatic discharge may damage or destroy electronic components. Information pictograms indicate the following: Important information about the product or the relevant section of the document, requiring the particular attention of the reader. Indicates important and instructional information. 12/05 AWB2776-1581GB © by Moeller GmbH... -
Page 6: Introduction
The PLC is programmed in compliance with the IEC1131 industrial standard. The Panel XV-23x-57 use the benefits of a seamless Ethernet and IT-based (WEB-based) automation solution and thus offer an unlimited range of possible applications. 12/05 AWB2776-1581GB © by Moeller GmbH... -
Page 7: Aim And Purpose Of This Document
2.3 L IST OF DOCUMENTS Subject Document Doc. No. Installation Installation instructions AWB2776-1568GB General wiring instructions Networks Networks in brief AWB2776-1569GB Windows CE PANEL with WindowsCE AWB2776-1553GB (this list of documents is not final) 12/05 AWB2776-1581GB © by Moeller GmbH... -
Page 8: Device Versions
Accessories (enclosed) • 8 fixing brackets for mounting the device • 8 hexagon-type threaded pins for fixing brackets • Sealing strip • Power supply connector • OS Flash fitted • Resistive touch pen (stylus) 12/05 AWB2776-1581GB © by Moeller GmbH... -
Page 9: Commissioning
VERVIEW OF THE TERMINALS Connector panel XV-230-57xxx Fieldbus Ethernet Supply (View MPI) Connector panel XV-232--57BAS System Port Ethernet Supply (RS232) Service side DIAG USB Device The DIAG and BFL terminals should only be used for service tasks 12/05 AWB2776-1581GB © by Moeller GmbH... - Page 10 Commissioning The Ethernet, fieldbus and Supply terminals are located on the right of the device when viewed from the rear. The terminal for the USB interface is located on the left of the device. 12/05 AWB2776-1581GB © by Moeller GmbH...
-
Page 11: General Notes On Cabling
Phönix Order No. 1757022; Supplied with unit (view from the wiring side) +24 VDC GND +24 VDC +24 VDC power supply Functional ground, connected to connector panel (connection not compulsory) Power supply 0V (isolated) 12/05 AWB2776-1581GB © by Moeller GmbH... -
Page 12: Ethernet
A crossover cable must be used for connecting one device with another. A 1:1 cable must be used when using a hub in the connection. Further information: Installation instructions, General wiring instructions [1] 12/05 AWB2776-1581GB © by Moeller GmbH... -
Page 13: Usb Device
Only use USB standard cables with a shield. When preparing the cables it must be ensured that the cable shield is correctly connected to the connector casing. The maximum permissible cable length is 5 m. Further information: Installation instructions, General wiring instructions [1] 12/05 AWB2776-1581GB © by Moeller GmbH... -
Page 14: Interface Variants
The terminating resistor must be provided externally, e.g. in the connector, and is not part of the device. The CAN connector is not provided with a supply for third-party devices. Further information: Installation instructions, General wiring instructions [1] 12/05 AWB2776-1581GB © by Moeller GmbH... -
Page 15: Mpi (Profibus Dp)
LINE B and TERM B. The 5V must not be used as a power supply for systems of other suppliers. It is neither overload nor short-circuit proof. Further information: Installation instructions, General wiring instructions [1] 12/05 AWB2776-1581GB © by Moeller GmbH... -
Page 16: System Port (Rs232)
Connector Clear to send 9pole DSub male Ring indicator Case Shield Cable shield The RS232 interface is not isolated. The maximum baud rate is 115200 Kbit/s. Further information: Installation instructions, General wiring instructions [1] 12/05 AWB2776-1581GB © by Moeller GmbH... -
Page 17: System Control Button (Ctrl)
The Control button is located on the side of the CompactFlash slot. Ensure the accessibility of the device when it is mounted. Viewed from the rear, the Control button is accessible on the left. Control button 12/05 AWB2776-1581GB © by Moeller GmbH... -
Page 18: System Settings
Device Description Embedded HMI-PLC XV-23x-57 Hardware System Settings YSTEM ETTINGS This is where network, display, date/time settings etc. are entered. These can be set via Start ⇨ Programs ⇨ Control Panel. Further information: PANEL with WindowsCE [3] 12/05 AWB2776-1581GB © by Moeller GmbH... -
Page 19: Compactflash Slot
We recommend the use of the CompactFlash cards supplied by Moeller GmbH in order to ensure trouble-free operation. Moeller GmbH cannot offer support and does not accept any liability for consequential damage arising from the use of CompactFlash cards offered by other suppliers. -
Page 20: Function And Control Leds
ONTROL The XV-23x-57 is provided with the following LEDs for monitoring functions on the unit: ACT and LINK Ethernet ETHERNET LINK (green) Active network connected and detected ACT (yellow) Flashing Ethernet active (data traffic) 12/05 AWB2776-1581GB © by Moeller GmbH... -
Page 21: Mounting Instructions
Mounting techniques not listed in this description should only be carried out with the permission of the supplier. The maximum torque for tightening the fixing brackets is 0.15 Nm. 12/05 AWB2776-1581GB © by Moeller GmbH... -
Page 22: Standard Front
The 4 additional fixing brackets are required for mounting to IP65 or in the Ex Zone 22. These brackets are positioned in the middle of each side. Groove for seal Holes for fixing brackets (central for IP65 mounting) 12/05 AWB2776-1581GB © by Moeller GmbH... -
Page 23: Mechanical Dimensions
Hardware Device Description Embedded HMI-PLC XV-23x-57 Mounting instructions 9.3 M ECHANICAL DIMENSIONS 12/05 AWB2776-1581GB © by Moeller GmbH... -
Page 24: Front Panel Cutout, Standard Front
TANDARD FRONT Front panel cutout: 198.0 +1/-0 mm x 142.0 +1/-0 mm 198.0 +1/-0 The front panel must not exceed a maximum thickness of 5mm due to the clamping range of the fixing brackets. 12/05 AWB2776-1581GB © by Moeller GmbH... -
Page 25: Notes On The Touch Screen
Only clean the touch foil with a non-abrasive cleaning material. Do not expose the front of the device to solvents which may corrode and destroy the foil (foil material: polyester (PET); Carrier plate: aluminum). The touch panel must only be actuated with a special pen or with a finger. 12/05 AWB2776-1581GB © by Moeller GmbH... -
Page 26: Display Technology, Backlight
Therefore avoid the frequent switching on and off of the backlight or the entire system. Minimising the brightness required is more effective than reducing the frequent on/off switching. Further information: PANEL with WindowsCE [3] 12/05 AWB2776-1581GB © by Moeller GmbH... -
Page 27: Maintenance And Repair
EPAIR Repairs Repairs should only be carried out by the manufacturer or authorized repair centres. In this case, please contact your local PANEL dealer or the Technical Support at Moeller GmbH (manufacturer address chapter 15). The warranty is not applicable if any modifications are made to the device that are not described in this document. -
Page 28: Disposal
• The LCD unit is fitted with a fluorescent tube for the backlight. This contains mercury. Materials, device Housing: Front plate: Front glass: Glass with foil (touch sensor) Foil: Materials, packaging Boxes: Cardboard Transport protection: PET Plastic bag: 12/05 AWB2776-1581GB © by Moeller GmbH... -
Page 29: Technical Data
Protection against reverse polarity Fuse protection Yes (PTC, electronic) Potential isolation Power consumption max. 8 W Inrush max. 2.0A Real-time clock Battery type CR2032 (190 mA/h) maintenance-free (battery backup) Backup time >10 years (in de-energized state) 12/05 AWB2776-1581GB © by Moeller GmbH... - Page 30 Fall test: IEC68-2-32 EMC (CE) EN 61000-6-2, EN 61000-6-4 EN 61000-6-3 EN 61131-2 Safety EN60950 UL60950 (UL) Explosion protection Zone 22, Category 3D (CE) Product standards EN 50178, Electrical equipment for use in electrical installations 12/05 AWB2776-1581GB © by Moeller GmbH...
-
Page 31: Eu Conformity/Safety
Electrical apparatus for explosive gas atmospheres. General requirements EN 50281-1-1 Electrical apparatus for use in the presence of combustible dust Part 1-1: Electrical apparatus with protection by enclosures – design and testing EN 13463-1 Non-electrical equipment for potentially explosive atmospheres 12/05 AWB2776-1581GB © by Moeller GmbH... - Page 32 Device Description Embedded HMI-PLC XV-23x-57 Hardware EU Conformity/Safety Moeller GmbH Industrieautomation Hein-Moeller-Str. 7-11 D-53115 Bonn +49 (0228) 602-0 +41 (0228) 602-2275 E-Mail info@moeller.net Internet http://www.moeller.net 12/05 AWB2776-1581GB © by Moeller GmbH...
