  • Page 1 Ref : NP52UGB...
  • Page 2 INDUSTRIAL SCIENTIFIC , even if it is involved in the sale of INDUSTRIAL SCIENTIFIC products. * INDUSTRIAL SCIENTIFIC cannot be held responsible for direct or indirect damage or be required to pay direct or indirect compensation resulting from the sale or use of any of its products IF THESE PRODUCTS HAVE NOT BEEN DEFINED AND CHOSEN BY INDUSTRIAL SCIENTIFIC FOR THEIR SPECIFIC USE.

  • Page 3: Table Of Contents

    CONTENTS DESCRIPTION..................6 1.1. General ..........................6 1.2. Rack ..........................7 1.3. The various printed circuit boards .................. 7 INSTALLATION AND CONNECTIONS..........8 Installation: recommendations ..................8 Electrical connections of the MX52 Unit (Fig. 8) ............8 2.2.1. Alternative power supply..................8 2.2.2.
  • Page 4 UTILIZATION..................25 4.1. List and functions of the various items of “USER” equipment for programming and calibration of the unit ........................ 25 4.1.1. Keypad (see Figures 26 and 4) ................25 4.1.2. Maintenance keys ....................26 4.1.3. Potentiometers ....................... 26 4.2. Menus..........................

  • Page 5: Description

    The equipment of the MX52 unit comprises line PCBs, each equipped with two channels. However, each channel is independent and can be connected to any type of INDUSTRIAL SCIENTIFIC detector provided that the PCB is suitably programmed. The number of line PCBs is always equal to the mixed even number greater than the number of channels used divided by two.

  • Page 6: Rack

    One relay common to channels for third thresholds or for all alarms (buzzer transmission), with positive or negative safety, contacts opened or closed at rest One relay common to channels for faults and failures, constant positive safety mode, contacts open or closed at rest. •...

  • Page 7: Installation And Connections

    Please ensure you read the paragraph: Special Specifications for use in Potentially Explosive Atmospheres in Accordance with European Directive ATEX 94/9/EC Installation: recommendations The MX52 unit can be installed in any premises without an explosive atmosphere. They should preferably be placed in a ventilated and monitored location (guardhouse, control room, instrumentation room, etc.).

  • Page 8: Dc Power Supply

    2.2.2. DC power supply Voltage: 21 to 30 V continue. The " - " from continue power supply is linked to earth (and earth being linked to frame). Maximum power: 240 W Maximum current in cable: 12.5 A Cable: 2 x 2.5 mm² or 2 x 4 mm² depending on length Location of terminal block: see Fig.

  • Page 9: 3-Wire Detectors 4-20 Ma: 3 Connecting Wires For Shielded Cable

    2.3.2. 3-wire detectors 4-20 mA: 3 connecting wires for shielded cable Resistance of detector / unit cable: 16 ohms maximum per wire, i.e. 32 ohms in loop (1 km for cable 3 x 1.5 mm²). Connection on MX52 unit: see Fig. 10. 2.3.3.
  • Page 10 These detectors can operate in standalone mode: 24 V DC power supply and direct utilization of relay contacts in accordance with the technical specification corresponding to the detector used. The current commercial designations are as follows: model 20/20 U - analog - type UV - 752002 (sensitive to UV radiation) model 20/20 UC - analog - type UV (sensitive to UV radiation) model 20/20 UB - µP technology - type UV - 772002 (sensitive to UV radiation) model 20/20 UBC - µP technology - type UV (sensitive to UV radiation)

  • Page 11: Co2 Detector Of Type "Ventostat Vt

    REMARK In the case of this application, the maximum of five flame detectors can be connected in the measuring loop. Example of the utilization of IR3 or UV/IR detectors equipped with connectors of type A with a local junction box and galvanic insulation (see Fig. 18). 2.3.6.

  • Page 12: Other Detectors With Standardized Current Output

    INDUSTRIAL SCIENTIFIC “INTRINSIC SAFETY” BARRIERS Type of IS Reference Specific features INDUSTRIAL barrier SCIENTIFIC box reference Z787 / EX 6184703 To be fitted on DIN RAIL MTL787S+ 6797100 To be fitted in an For 2 clippers 6797192 approved box: MANDATORY...

  • Page 13: Connecting The Unit To External Devices

    Connecting the unit to external devices 2.4.1. Slaving controls The 16 measuring channels of the MX52 unit are each equipped with two relays which can be used to control external devices: sirens, solenoid valves, extractors, telephone calls, etc.. For each measuring channel, the relays are distributed in the following manner (see Fig. 7): a relay associated with the triggering of alarm 1, a relay associated with the triggering of alarm 2, use of open or closed contacts selected with a jumper (see Fig.

  • Page 14: Ma Current Outputs (Fig. 12)

    2.4.2. 4-20 mA current outputs (Fig. 12) For each measuring channel, the MX52 unit is equipped with a 4-20 mA output that can be used to retransmit measurements to a recorder or an external PLC. The maximum resistance in loop mode is 600 ohms.
  • Page 15 RS 485 OUTPUT (PINABLE ON FIG 29) Several MX52 units can be linked to a single computer, which is the "master" of the network. In this case, a "SLAVE NUMBER" (by programming/unit) is asigned to each MX52 unit. This RS 485 output can be galvanically insulated as an option. case : no galvanic insulation no mounted insulation component 2 polarization electrical resistances are programmed and welded...

  • Page 16: Remote Acknowledgement

    It is checked that, at least, all connections have been made and that the complete installation complies with current standards in force. CAUTION INDUSTRIAL SCIENTIFIC is not responsible for the compliance of the complete electrical safety system. The MX52 unit is switched on by means of circuit breakers * provided for that purpose and which ensure protection of the mains power unit.

  • Page 17: Switching On The Unit

    3.2. Switching on the unit CAUTION The handling operations and adjustments described in these paragraphs are strictly reserved for authorized personnel as they are liable to affect detection safety. To start up the MX52 unit, you must: swivel the front panel, press the ON/OFF button located to the bottom left-hand side of the FRONT circuit: see Figures 4 and 26 (item A).

  • Page 18: Operating Modes

    3.3. Operating modes 3.3.1. Audio warning device (buzzer) In normal operation, the audio warning device is triggered whenever a fault or an alarm appears. The audio warning device can be stopped by pressing the ACKNOWLEDGEMENT key or by remote acknowledgement. The buzzer makes a continuous or discontinuous sound (according to the programming of the unit) if an alarm threshold is exceeded.
  • Page 19 BLOCK DIAGRAM 1 NORMAL CYCLE WITH MANUAL CLEARING START Threshold Illumination of flashing exceeded alarm LED Time T1 Illumination of flashing exceeded alarm LED After T2 time Relay engaged Buzzer engaged Alarm Alarm acknowledged acknowledged LED extinguished LED steady mode Relay disengaged Buzzer stopped Buzzer stopped...
  • Page 20 BLOCK DIAGRAM 2 NORMAL CYCLE WITH AUTOMATIC CLEARING START Threshold exceeded Time T1 exceeded Alarm LED illuminated in steady mode After T2 time LED extinguished Relay disengaged Relay engaged Buzzer engaged...
  • Page 21 BLOCK DIAGRAM 3 PARKING CYCLE Alarm 3 operates in the same way as the normal cycle. The times defined for alarms 1 and 2 (time delays) are, in this case, used to define the minimum operating time for each relay. t AL1 tR1 R2 t AL2...

  • Page 22: Fault Thresholds

    3.3.4. Fault thresholds Processing of detector faults Each channel detects the following faults. For toxic and explosive gas detectors: line interrupted (0 mA), line short-circuited or excessive consumption, negative offset (more than 20% of measuring scale), line in calibration mode (2 mA) (if confirmed by programming). For detectors of the explosive gas type (4-20 mA and 340 mA) in normal mode and if the measurement is greater than 100% of the measuring scale, there are the following immediate results:...

  • Page 23: Measuring Unit

    3.3.5. Measuring unit One minute after starting up, and if no test action is performed on the keypad, the unit successively scans all the channels in service and displays the measured values. Examples of display Channel 1 x x LEL CH4 Channel 2 x x x ppm CO Each channel is interrogated for 10 seconds.

  • Page 24: Utilization

    List and functions of the various items of “USER” equipment for 4.1. programming and calibration of the unit 4.1.1. Keypad (see Figures 26 and 4) This is equipped with four touch keys accessible without opening and swivelling the MX52 unit’s FRONT panel or opening and swivelling the FRONT panel for maintenance.

  • Page 25: Maintenance Keys

    - “Audio and visual” or “audio” clearing of an alarm - Exit from a current menu - Start a self- test manually - VALIDATE 4.1.2. Maintenance keys PROGRAMMING key (item B, Fig. 26): accessible after opening and swivelling the front panel. Combined with the “-”...

  • Page 26: Menus

    Menus 4.2. 4.2.1. The various menus and their functions The MX52 unit has five menus that are accessed by pressing the “Programming” key (item B, Fig. 26). These five menus are as follows: DESIGNATION FUNCTION “CHANNEL” programming - To program the whole configuration of a measuring channel (ON/OFF, range, alarm thresholds, etc.) “SIMULATION”...
  • Page 27 SCROLLING OF THE VARIOUS MENUS NORMAL DISPLAY Programming Programming Programming Programming Programming [Channel x x] Simulation Channel xx copy Unit Uploading REMINDER (Fig. 26) Programming key Keys used to move...

  • Page 28: Detailed Flow Diagrams Of Each Menu

    4.2.3. Detailed flow diagrams of each menu CHANNEL PROGRAMMING Remove on the programming socket before entering into programming Seuil Alarme 1 NORMAL [25] DISPLAY Programming : last channel displayed [Channe l xx] Channel xx ← [Off] → then ENTER : CHOICE OF RANGES Measuring range 100 300 1000 2000 xxxxU...
  • Page 29 Alarm 3 threshold : 0 to 2000 ← [75] → then ENTER Alarm 1 : Increasing Decreasing ← [Increasing] → then ENTER : Increasing Decreasing Alarm 2 ← [Increasing] → then ENTER : Increasing Decreasing Alarm 3 ← → then ENTER [Increasing] Cycle : Normal...
  • Page 30 Ack alarm 1 : Manual Automatic ← [Manual] → then ENTER : Manual Automatic Ack alarm 2 ← → then ENTER [Manual] : Time delay Mean Alarm 3 ← → [Time delay] then ENTER : Negative Positive Relay 1 safety ←...
  • Page 31 Relay 2 safety Negative Positive ← [Negative] → then ENTER Free Set to 0 Set to 1 Relay 1 ← ← → → then ENTER [Free] Free Set to 0 Set to 1 Relai 2 ← ← → → [Free] then ENTER Free...
  • Page 32 The MX52 unit can detect and indicatez (with a flashing Cal detection yellow LED) that a line has-been placed in CALIBRATION mode on the detector. [No] ← → then ENTER Channel xx Free display: A channel heading can be programmed [Premises 1 channel] U (in 13 characters maximum).
  • Page 33 Detector type (Bridge) (4-20 mA) (Fire) [Explosive] : Explosive Toxic Spec. tox. ← ← → → then ENTER End of menu (1) in case of "Up" fault : 3 "ga s" alarms and fault alarm are triggered. (2) In case of "Up" fault : only the fault alarm is triggered. INFORMATION This key can also be used to exit from the current menu.
  • Page 34 LIST OF UNITS DESIGNATION MEANING Lower explosive limit Percent parts per million parts per billion Unter Explosion Grenze (= LEL in German) Limite inférieure d’explosivité (= LEL in French) unit of pressure unit of pressure (millibar) relative humidity metres per second unit of weight (milligram) unit + flashing U free indication of unit...
  • Page 35 LIST OF GASES DESIGNATION MEANING Methane Carbon monoxide Hydrogen sulphide Nitrogen Nitric oxide Nitrogen dioxide Sulphur dioxide Chlorine Hydrogen Hydrochloric acid Hydrocyanic acid Ammonia Ethylene oxide Phosphine Hydrofluoric acid Freons Carbon dioxide Arsine Silane SiH4 Butane Propane Natural gas Ethylene Pentane Hexane Propylene...
  • Page 36 SIMULATION PROGRAMMING MENU NORMAL DISPLAY Programming [Simulation xx] ENTER Simulation on previously displayed and [validated] channel Programming [Simulation xx] Free labelled area Channel xx S = flashing to indicate that this channel is in LEL CH4 S simulation mode. To artificially vary measurement on the display ←...
  • Page 37 COPY PROGRAMMING NORMAL DISPLAY Programming Last channel displayed Copy channel xx ENTER Validation of menu Programming Validation of channel to be copied [Copy channel xx] : Copy the channel’s configuration to Copy channel another channel [Channel xx => xx] xx = indication of “Other channel ←...
  • Page 38 UNIT PROGRAMMING NORMAL DISPLAY Programming Unit ENTER Programming Validation of menu [Unit] Language Choice of languages: [French] : French English German Spanish → → + then ENTER Choice of transmission speed with Speed computer: [9600••] 1200 2400 4800 9600 19200 Bauds →...
  • Page 39 This is the time interval between exceeding of the AL threshold and triggering of the corresponding Response time visual alarm (LED). [00 : 00 : 00] Display the time using keys: ← → H mn sec → ENTER then In “Parking” mode: this is the time interval between Relay 1&2 stop T stopping of relay 1 and starting up of relay 2.
  • Page 40 UPLOADING PROGRAMMING Only INDUSTRIAL SCIENTIFIC personnel and personnel approved by INDUSTRIAL SCIENTIFIC can be made this operation. **************** ******* Display of menu Validation of utilization of ******* menu ********************* Display of menu **** confirmation ********************* Data transfer request Validation of data transfers...

  • Page 41: Setting The Mx52 Unit Into Service

    REMINDER The handling operations and adjustments described in this chapter must be performed by authorized personnel only, as they are liable to affect detection safety. Once the measuring unit has been switched on, it can be programmed (1), its measuring channels can be programmed (1) according to the detectors used and calibrations can be made on the unit and detectors.

  • Page 42: Copy

    These recommendations are based on safe work procedures, industry best practises, and regulatory standards to ensure worker safety. Industrial scientific is not responsible for setting safety practices and policies. * For new installations it may be prudent to carry out bump tests frequently at first (perhaps weekly), increasing the time intervals (to, perhaps, monthly or more) as confidence grows with experience in the installation concerned, on the basis of the maintenance record.
  • Page 43 REMARK The authorized wind speed is increased to 4.1 m/s when the detector is fitted with a weather protective device. • Prepare the measuring channel for calibration: Open and swivel the front panel of the MX52 unit. Manually set the channel to be calculated using keys + and - on the MX52 keypad (item D, Fig.
  • Page 44 NOTE For this category of explosive gas detectors, the unit’s display panel indicates 100 DIVISIONS for 100 LEL of an explosive gas. Example: If the reference gas is a 2.5% methane concentration, i.e. 50% LEL of methane, adjust to obtain a display of 50 DIVISIONS.
  • Page 45 CAUTION If the detector and the measuring channel are calibrated at the same time, the detector must be left in normal operating mode but the MX52 unit must be set to calibration mode in order to inhibit the relays. ⇒ Consult the technical manual for the detector concerned. Open the detector (with integrated electronics) in order to gain access to the 4 mA adjustment and sensitivity (20 mA) potentiometers and to the terminals used to check its 4-20 mA output current.

  • Page 46: Ma Output Adjustment For A Measurement Channel

    • Adjust the detector sensitivity: Inject the calibration gas using the gas injection pipe (or a remote calibrating fixed device) in the same conditions as those applicable for the synthetic air (zero adjustment). When the measurement has stabilized (on the local display panel or on the detector internal terminals (current measurement)), act on the detector’s internal sensitivity potentiometer (see the manual for the detector concerned) in order to set the value (on the detector display panel) corresponding to the concentration of the reference gas or the corresponding current (terminals).

  • Page 47: Maintenance

    REMINDER The handling operations and adjustments described in this chapter must be performed by authorized personnel only, as they are liable to affect detection safety. Periodic / preventive maintenance 6.1. 6.1.1. On the MX52 unit The MX52 measuring unit requires practically no surveillance. It is, however, recommended that the facilities available on the MX52 unit should be used to regularly test the appliance’s essential functions, as follows: Use the TEST key to check the correct operation of all the LEDs and the buzzer.

  • Page 48: Failures: Causes And Remedies

    Our company is at your disposal to supply you with standard gas or an annual surveillance contract (preventive maintenance). Under this contract, our specialists guarantee the perfect operation of your installation. No adjustment is to be made between INDUSTRIAL SCIENTIFIC servicing operations. This avoids any additional workload for the user’s maintenance services.
  • Page 49 Channel in maintenance mode Return the channel to normal for more than 30 minutes. operation by pressing the Calibration key (Item C, Fig. 26). Fault indicator light on (in The measurement is higher To acknowledge the alarm, steady mode) and SUP than 100% of the measuring the measuring channel must displayed.
  • Page 50 Faulty electrical connections. Short-circuit or open the relay contact (as applicable) on the MX52 terminal block (Fig. 12) and, if the slaving controls still do not work, the connections must be checked on the MX52 connector and on the slaving systems.

  • Page 51: Scrapping Of Mx52

    Fluorescent display panel 6133521 On/Off switch 6153436 Maintenance screwdriver 6145845 CAUTION It is mandatory that replacement parts must be guaranteed INDUSTRIAL SCIENTIFIC FRANCE original parts as, if this is not the case, the safety of the equipment could be affected.

  • Page 82: Detailed Technical Characteristics

    MANUFACTURER INDUSTRIAL SCIENTIFIC 62000 ARRAS - FRANCE - Overall dimensions: rack 3U 19” - Function: measuring unit - Capacity: 16 measuring channel - Measurement: continuous - Storage temperature: -20°C to +55°C - Operating temperature: -10°C to +45°C - Relative humidity: 0 to 95% humidity, no condensation...
  • Page 83 RELAY OUTPUTS - 2 independent measurement alarm relays per channel - 1 common relay for alarm 3 or audio alarm transfer - 1 common fault relay SIGNAL OUTPUTS - 4-20 mA analog per channel, maximum load resistance = 600 Ω - Serial: RS 485 / J BUS , common MISCELLANEOUS OUTPUTS Alarm remote acknowledgement...

  • Page 84: Accordance With European Directive Atex 94/9/Ec

    The MX52 detection device designed to measure explosive gasses and oxygen complies with the requirements of European Directive ATEX 94/9/EC on potentially explosive atmospheres. As a result of its metrological performance, as tested by the research and testing organisation INERIS, the MX52 device, is classified as a safety device when used with INDUSTRIAL SCIENTIFIC CEX300 and OLC/OLCT 20, 40, 50 and 60 series detectors.
  • Page 85 Where the user connects a brand of detector other than INDUSTRIAL SCIENTIFIC to the MX52 device, he must check carefully that the transfer curve is fully compatible with the device input characteristics, to ensure that the data generated by the detector is correctly interpreted.
  • Page 86 Where the user connects a brand of detector other than INDUSTRIAL SCIENTIFIC to the MX52 device, he must check carefully that the transfer curve is fully compatible with the device input characteristics, to ensure that the data generated by the detector is correctly interpreted.
