NEO-ANGLE SHOWER
Operators' Manual
DOUCHE NÉO-ANGULAIRE
Guide de l'utilisateur
Customer Service / Service à la clientèle : 1-866-206-0888
Our Customer service sta is available to help you. For help with product assembly, to report damaged or
missing parts, or for any other information about this product, please call our toll-free number.
SAVE THIS MANUAL
Keep this manual and the original sales invoice in a safe, dry place for future reference.
Notre personnel du service à la clientèle est disponible pour vous aider. Pour obtenir de l'aide pour le montage
de votre produit, pour signaler des pièces endommagées ou manquantes, ou pour toute autre information à
propos de ce produit, veuillez composer notre numéro sans frais.
CONSERVEZ CE GUIDE
Conservez ce guide avec la facture d'origine dans un endroit sûr et sec pour référence future.
Product picture
Product picture
Photo du produit
Photo du produit
Model/Modèle : 70845000-01-02-03
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Uberhaus 70845000-01-02-03
Summary of Contents for Uberhaus 70845000-01-02-03
- Page 1 Model/Modèle : 70845000-01-02-03 Product picture Product picture Photo du produit Photo du produit NEO-ANGLE SHOWER Operators’ Manual DOUCHE NÉO-ANGULAIRE Guide de l'utilisateur Customer Service / Service à la clientèle : 1-866-206-0888 Our Customer service sta is available to help you. For help with product assembly, to report damaged or missing parts, or for any other information about this product, please call our toll-free number.
- Page 2 Bottom-Drip Seal- Left Bottom-Drip Seal- Right...
- Page 3 PARTS LIST Wall Channel Stationary Panel-Left Door Seal (Hinge-Side) Bottom Drip Seal-Right Bottom Drip Seal-Left Shower Base Door Pull Bar Magnetic Door Seal Strips Stationary Panel-Right Shower Wall-Right Glass Door Panel Shower Wall- Left Door Handle Glass Clamp M4X30 Truss Head Screw ST4.2X10 Self-Drilling Screw Door Pull Bar Screw M8X18 Door Clamp Screw M6X16...
- Page 4 1.BASE INSTALLATION PREPARATION It is very important to make sure that the Base is level and properly supported. To compensate for any irregularities in your floor,adjust the legs underneath the base by turning the screw until the correct position is reached. WARNING! Walls in your bathroom must be leveled and square for an optimall installation.
- Page 5 Put some water into the base to test the base and make sure there's no hydrops found 2.SHOWER WALL ASSEMBLY OP T I ONAL...
- Page 6 3A.BASE INSTALLTION WITH SHOWER WALL Please note:Throughout these instructions,installation is shown with the optional shower wall. The installation may also be done with tiled and properly waterproofed walls. In new constructions,complete the tiled wall installation before installing the shower . The installation procedure is the same for installation on tiled walls.
- Page 7 3B.BASE INSTALLTION ON TILED WALL Attention:in a new construction, the shower base should be installed before installing the tiles Attention:in a new construction, the shower base should be installed before installing the tiles Tile Drywall Shower base About 25-30mm SIDE SECTION VIEW...
- Page 8 4.WALL CHANNELS POSITIONING Use a level to plumb wall channels against the edges of the shower enclosure. Mark all mounting holes with a pencil on the inside of the wall channel. Repeat on the other side. OUTSIDE INSIDE...
- Page 9 5.WALL CHANNELS INSTALLATION Remove wall channels and drill holes at each mounting hole location. Repeat on the other side. After drilling,insert wall anchors. Replace wall channels and secure to walls with M4X30 truss head screws. Repeat on the other side.
- Page 10 6.GLASS DOOR INSTALLATION When installing glass panels,make sure that you have a firm grip on the glass. Insert the back of glass panel into the wall channel as shown.Repeat on the other side. When orienting the glass panels,make sure that bent channels are on the outside of the shower. NOTE:If glass panels have a pattern, the pattern should go to the outside.
- Page 11 7. LEFT OR RIGHT HINGE INSTALLATION LEFT-SIDE HINGES Pivot block mounting holes on left RIGHT-SIDE HINGES Pivot block mounting holes on right...
- Page 12 8.GLASS DOOR PULL BAR INSTALLATION First decide whether you want the door to open on the right (hinges on the left side) or open on the left (hinges on the right side). Please note:For information purposes,the shower illustrated throughout this manual has hinges on the left side. Push screw through hole in cup-end of snap cap washer,then screw in.
- Page 13 9.STATIONARY PANEL INSTALLATION Make sure that the shower enclosure is sitting flat and even on the base. With the 3.2 drill bit provided,drill holes through each of the six holes in the wall panels and into the wall channels. Secure the shower to the wall channel with ST3.3X13 self-drilling screws.
- Page 14 10.INSTALL DOOR HINGES Please note:Use the allen key to install hinges on the glass door. Install hinges as shown. Install the door handle as shown. 11.INSTALL GLASS DOOR Install glass door as shown. Please note:Keep a firm grip on the glass door during the installation,until door is secured on its hinges.
- Page 15 12.DOOR SEAL STRIPS INSTALLATION Install the door seal strips as shown...
- Page 16 13.CAULKING WARNING! Silicone sealer must be only applied on the outside of the shower to prevent leaks. Allow silicone to dry 48 hours.
- Page 17 Warranty Shower Clear tempered glass door: 70845000 2 years Frosted tempered glass door: 70845001 2 years Shower base: 70845002 3 years 2-piece ABS acrylic enclosure: 70845003 3 years Following the conditions and the terms described below, RONA guarantees that the product is in conformity with its specifications and at the moment of the sale, the product is free from vice and/or manufacturing defects.
