- Page 1 ViewScan Pro Quick Start Guide...
-
Page 2: Table Of Contents
Table of Contents Included Parts ................................... 2 Assembly Instructions: ..............................3 Camera Setup ..................................7 Startup Instructions ................................8 Login Instructions ................................9 Import License ................................. 10 Add Portal ..................................11 Aligning Camera ................................12 P a g e... -
Page 3: Included Parts
Included Parts • 2x ViewScan monolith pillars • 2x ViewScan feet • 1x ViewScan brace crossbar bottom channel • 1x ViewScan brace crossbar cover • 1x ViewScan power supply • 1x C7 Power Cable • 6x Leveling screws for feet and monolith •... -
Page 4: Assembly Instructions
Assembly Instructions: 1. Install leveling screws in ViewScan feet. 2. Mount ViewScan feet to ViewScan monolith pillars using large thread wing screws. 3. Unfold ViewScan monoliths and install silver captive thumb screws to secure them in the unfolded position. P a g e... - Page 5 4. Feed the cables through the ViewScan brace crossbar bottom channel on either side in the provided cutout. 5. Connect top crossbar to Monolith using x4 silver thumb screws P a g e...
- Page 6 6. Connect cables on either side of the ViewScan brace crossbar with the data cable. 7. Plug an ethernet cable into the ViewScan monolith’s top (Scanner) RJ45 terminal and terminate into either the provided PoE network switch or local network. 8.
- Page 7 9. Connect the provided 12V DC power supply into the ViewScan. 10. Turn on ViewScan power using the switch located on the side of the unit. P a g e...
-
Page 8: Camera Setup
Camera Setup 1. Attach the camera boom to the pillar that you are applying power and data to using the Large black knurled thumb screws. 2. Connect the ethernet cable running through the boom to the side of the ViewScan monolith right next to the boom mounting location. 3. -
Page 9: Startup Instructions
Startup Instructions 1. The setup instructions will be done on the user machine running ViewScan 2.0. P a g e... -
Page 10: Login Instructions
2. Turn on the machine and start the ViewScan Controller from the desktop. 3. When it opens wait for it to connect to the Server. a. If a server connection is unsuccessful click Start Server. Allow the controller to make a connection while the server starts up. 4. -
Page 11: Import License
3. You will be prompted to accept and EULA & to change the password. Complete both. Note: Store the new password in a safe place. Import License A ViewScan license allows for the application to run on a designated system. If you do not currently have a license, please reach out to our support for one. -
Page 12: Add Portal
2. Choose the license file with the type ‘vs_license’. 3. Click Upload License. A message will appear and alert you of a valid license format. Add Portal 1. Log into the Web Portal and visit the Settings page, then Portals then Add Portal. 11 | P a g e... -
Page 13: Aligning Camera
2. Fill in the Portal & Camera inputs with or without a camera then click Confirm. • The Portal should now be visible on the controller. 3. Check that the Monolith & Camera is turned on and go to the ViewScan Controller. 4. - Page 14 4. Click the following locations in this order: • Top-Left inner corner • Top-Right inner corner • Bottom-Right stabilizing foot edge • Bottom-Left stabilizing foot edge 5. Click Confirm Alignment, then Save Camera Settings, and finally Restart Scanner. 6. Allow the Scanner to perform a quick Restart. 7.
