Specifications

3-Phase Line Voltage ..................................190 - 480 VAC
......................................................................(475 - 600 VAC Optional)
......................................................................(95 - 120 VAC Optional)
Frequency ..................................................50* or 60 Hz
Low Voltage (% of set point)
•Trip ................................................................90% ±1%
•Reset ............................................................93% ±1%
High Voltage (% of set point)
•Trip ................................................................110% ±1%
•Reset ............................................................107% ±1%
Voltage Unbalance (NEMA)
•Trip ................................................................2 - 8% Adjustable
•Reset ............................................................Trip setting minus 1% (5 - 8%)
......................................................................Trip setting minus .5% (2 - 4%)
Trip Delay Time
•Low & High Voltage and Unbalance ............1 - 30 seconds adjustable
•Single Phasing Faults (>25% UB) ................1 second fixed
Restart Delay Time
•After a Fault ..................................................1 - 500 seconds adjustable
•After a Complete Power Loss ......................1 - 500 seconds adjustable
Output Contact Rating
•1-Form C ......................................................10 A General Purpose @240 VAC
......................................................................Pilot Duty 480VA @ 240 VAC, B300
Power Consumption ..................................6 Watts (Max.)
Weight ..........................................................14 oz.
Enclosure ......................................................polycarbonate
Terminal Torque............................................6lbs-in.
Wire Type ......................................................Stranded or solid 12-20 AWG, one per terminal
Safety Marks
•UL..................................................................UL508
•CE ................................................................IEC 60947-6-2
Standards Passed
•Electrostatic Discharge (ESD) ......................IEC 1000-4-2, Level 3, 6kV contact, 8kV air
•Radio Frequency Immunity, Radiated ..........150 MHz, 10V/m
•Fast Transient Burst......................................IEC 1000-4-4, Level 3, 3.5 kV input power & controls
Surge
•IEC ................................................................IEC 1000-4-5, Level 3, 4kV line-to-line;
......................................................................Level 4, 4kV line-to-ground
•ANSI/IEEE ....................................................C62.41 Surge and Ring Wave Compliance
......................................................................to a level of 6kV line-to-line
•Hi-potential Test ............................................Meets UL508 (2 x rated V +1000V for 1 minute)
Environmental
Temperature Range........................................Ambient Operating: -20° - 70° C (-4° - 158°F)
......................................................................Ambient Storage: -40° - 80° C (-40° - 176°F)
Class of Protection ........................................IP20, NEMA 1 (FINGER SAFE)
Relative Humidity ..........................................10-95%, non-condensing per IEC 68-2-3
*Note: 50 Hz will increase all delay timers by 20%
SymCom warrants its microcontroller based products against defects in material or workmanship for a
period of five (5) years from the date of manufacture. All other products manufactured by SymCom shall
be warranted against defects in material and workmanship for a period of two (2) years from the date of
manufacture. For complete information on warranty, liability, terms, returns, and cancellations, please
refer to the SymCom Terms and Conditions of Sale document.
