- Page 1 IMPORTANT! READ AND FOLLOW THESE INSTRUCTIONS CAREFULLY AND KEEP FOR FUTURE REFERENCE. 3-IN-1 PLAYPEN BB31PLYPENA...
-
Page 3: Safety And Warnings
SAFETY & WARNINGS READ ALL INSTRUCTIONS BEFORE ASSEMBLY AND USE OF THIS PLAYPEN. FAILURE TO FOLLOW THESE INSTRUCTIONS MAY RESULT IN SERIOUS INJURY OR DEATH. Note: This gate is designed to protect your baby or pet from danger when installed in staircases, kitchens, fireplaces, doorways and hallways. - Page 4 WARNING When used as a playpen This playpen complies with EN 12227:2010. • WARNING: This product is intended for use with children from 6-24 months or small to medium sized pets. • WARNING: Do not place the playpen close to an open fire or other heat source. •...
- Page 5 • If the safety fence is used at the bottom of the stairs, it should be positioned at the front of the lower tread possible. When used as a playpen or a safety fence • Adult assembly required. Install only according to instructions this user guide. •...
- Page 6 COMPONENTS A Safety panels & gate B Plastic wall anchor (x8) C Screw (x8) D Wall bracket (x4) Tools Required Drill Bit Phillips head Drill Pencil (Æ2mm & Æ5mm) screwdriver...
- Page 7 ASSEMBLY Ensure all packaging material has been removed. Loosen the tension knobs by rotating anti-clockwise and unfold the panels.
- Page 8 INSTALLING AS SAFETY FENCE The safety fence can be adjusted to suit hallways from 73cm up to 370cm wide. • Measure the width of your hallway. • Remove or add additional panels to suit your desired width. Removing panels: • Release the two latches on the panel using a small pointed object.
- Page 9 Securing to wall Step 1: • Press the button on the end pole latch and insert the wall bracket until it snaps securely in place. • Repeat for the 3 remaining wall brackets. Step 2: Place the wall brackets up against your wall and mark the screw positions. (Note: the distance between the two wall brackets must be at least 65cm.) 65cm...
- Page 10 Step 3a: Securing to wall studs or wooden surface Using a Æ2mm drill bit, drill the holes for the wall brackets. Step 3b: Securing to plaster and non-wooden surfaces • Using a Æ5mm drill bit, drill out the holes for the wall brackets. •...
- Page 11 Step 4: • Press the button on the bottom of wall brackets and detach from the end poles. • Using the supplied screws secure the 4 wall brackets to your wall. Step 5: • Press the button on the end pole latch and insert it into wall bracket until it snaps securely in place.
- Page 12 INSTALLING AS PLAYPEN Step 1: • Release the two latches on the panel using a small pointed object. • Detach the panel from the end poles.
- Page 13 Step 2: • Connect the panels together adding in any unused panels. • Place the playpen in your desired position. Step 3: Tighten the tension knobs by rotating clockwise. (Note: always check the tension knobs are secure before each use.)
-
Page 14: Operation
OPERATION Opening the gate • Press the 2 buttons on the gate at the same time. • Pull the gate upwards until is unlatches from the lock, then open the gate. • Ensure the gate is securely latched when it closing it. Folding up the safety fence Step 1: Loosen the tension knobs by rotating anti-clockwise. - Page 15 Step 2: Press the button on the bottom of the wall brackets and pull the panels away from the wall Step 3: The fence can now be folded away for storage.
-
Page 16: Specifications
SPECIFICATIONS Net weight 13kgs Gross weight 14kgs Safety fence width 73cm - 370cm Panel width 65cm Panel heigh 74.5cm Material Iron tube ABS plastic... - Page 17 NOTES...
- Page 20 Need more information? We hope that this user guide has given you the assistance needed for a simple set-up. For the most up-to-date guide for your product, as well as any additional assistance you may require, head online to help.kogan.com...
