Programming aid CS1000 – S7 Table of Contents Table of Contents ........................4 Preface ............................ 5 Customer Service ......................... 6 Modifications to the Product ....................6 Warranty ..........................6 General Safety Precautions ................... 8 1.1 Obligations and Liability....................8 1.2 Explanation of Symbols and Warnings, etc..............8 1.2.1 Basic Symbols......................
Programming aid CS1000 – S7 Preface For you, as owner of a product manufactured by us, we have produced this manual, comprising the most important instructions for its operation and maintenance. It is intended to help you become acquainted with the proper/designated use of the product and use it properly.
Programming aid CS1000 – S7 Customer Service If you have any questions, suggestions, or encounter any problems of a technical nature, please contact us. When contacting us, please always include the model/type designation and part no. of the product: Fax: ++49 (0) 6897 509 846 Email: filtersysteme@hydac.com Modifications to the Product We would like to point out that changes to the product (e.g.
Page 6
Programming aid CS1000 – S7 ... and now for a few tips on using this documentation. The following example shows you how you can access the information you are looking for quick and easy. WHAT do I want to know? WHERE can I find the information I’m looking for? The documentation is subdivided into chapters and sections.
Programming aid CS1000 – S7 General Safety Precautions These operating instructions contain the key instructions for properly and safely operating the Obligations and Liability • The basic prerequisite for the safe and proper handling and operation of the CS is knowledge of the safety instructions and warnings.
Programming aid CS1000 – S7 1.2.1 Basic Symbols This symbol designates safety guidelines whose non-observance may pose a hazard to individuals. This symbol provides important notes for the proper handling of the CS. Non-observance of these instructions may lead to damage of the CS or its immediate surroundings.
Programming aid CS1000 – S7 Electrical Installation Block diagram Case M12x1, 8-pol., male, specified acc. IEC61984 / VDE0627 1 µF Internal Supply voltage 9 – 36 V DC supply Voltage voltages Regulator GND for supply voltage RS485 + RS485 - galvanically Not to be Not connected...
Programming aid CS1000 – S7 4.2.1 Wiring Diagram Schirm white Shield Blindage 24 V DC green Converter pink RS-485 + RS-485 blue RS-485 - grey Nicht angeschlossen Not to be connected Ne connexe pas brown SPS Eingang PLC Input SPS Entrée yellow 5 V DC Shield...
Programming aid CS1000 – S7 Operation of CS After the CS 1000 is switched on, "HYDAC CS 1000" is displayed in moving letters, then the firmware version is displayed for 2 seconds. WAIT99 WAIT0 This is followed by a countdown: The duration of the countdown is related to the measurement period set, e.g the countdown from 99 - 0 runs within the measurement period set (factory setting = 60 sec).
Programming aid CS1000 – S7 The keyboard consists of six buttons. These keys are used to operate the CS and to navigate through the menus (hierarchically structured). Keyboard Description one level down o.k. confirm changed value (lowest level) confirm when changes are to be saved or canceled (top level) one level up no value change change value at the lowest level (when display is blinking)
Page 13
Programming aid CS1000 – S7 Analog output ANA.OUT (CS 12xx) ANaOUT Select measurement Description category for analog output SAeMAX SAE A-D SAE class A/B/C/D (coded) SAE+T SAE class + temp. (Code) TEMP Fluid Temperature HDaISO ISO for HDA 5500 HDaSAE SAE for HDA 5500 ISO 4 ISO 4 code...
Programming aid CS1000 – S7 Analog output Depending on CS model, the analog output is available as a 4 – 20 mA or 0 – 10 V signal. The CS model code allows you to detect the analog output. CS Model code Analog output CS 1 x x x - A –...
Programming aid CS1000 – S7 SAE classes acc. to AS 4059 The following SAE classes can be output via the analog output: 6.1.1 HDA.SAE – Analog signal SAE The HDA.SAE signal consists of 6 values (START / SAE A / SAE B / SAE C / SAE D / Status) which are output sequentially.
Programming aid CS1000 – S7 6.1.1.1 HDA.SAE signal 1-4 table The current or voltage range is dependent on the contamination class according to SAE=0.0 – 14.0 (resolution 0.1 class). Current I SAE class / error Voltage U I< 4.00 mA Cable break U<...
Programming aid CS1000 – S7 6.1.1.2 HDA status signal 5 table The current or voltage of the output signal (5) is dependent on the status of the CS 1000 as shown in the table below: Current I Status Voltage U I = 5.0 mA CS is functioning correctly U = 2.5 V...
Programming aid CS1000 – S7 ISO Code acc. to 4406:1999 The following ISO values can be output via the analog output: 6.2.1 HDA.SAE – Analog signal ISO The HDA.ISO signal consists of 4 measured values (START / ISO 6 / ISO 6 / ISO 14 / ISO 21 / Status) which are output sequentially.
Programming aid CS1000 – S7 6.2.1.1 HDA.ISO signal 1-4 table The current 4 -20 mA or voltage 2 - 10 V of the output signal is dependent on the ISO contamination class 0.0 - 25.28 (resolution 1 class) as shown in the table below: Current I ISO code Voltage U...
Programming aid CS1000 – S7 The current (I) or voltage (U) can be calculated for a given ISO contamination class as follows: I = 4 mA + ISO code * (20 mA - 4 mA) / 25.28 U = 2 V + ISO code * (10 V - 2 V) / 25.28 The ISO contamination class can be calculated for a given current I or voltage U as follows: ISO code = (I - 4 mA)*(25.28 / 16 mA) ISO code = (U - 2 V)*(25.28 / 8 V)
Programming aid CS1000 – S7 ISO code acc. to 4406:1987 (CS 13xx only) The following ISO values can be output via the analog output: 6.3.1 HDA.SAE – Analog signal ISO The HDA.ISO signal consists of 5 measured values (START / ISO 4 / ISO 6 / ISO 14 / ISO 21 / Status) which are output sequentially.
Programming aid CS1000 – S7 6.3.1.1 HDA.ISO signal 1-4 table The current 4 - 20 mA or voltage 2 - 10 V of the output signal is dependent on the ISO contamination class 0.0 - 25.28 (resolution 1 class) as shown in the table below: Current I Voltage U ISO code...
Programming aid CS1000 – S7 The current (I) or voltage (U) can be calculated for a given ISO contamination class as follows: I = 4 mA + ISO code * (20 mA - 4 mA) / 25.28 U = 2 V + ISO code * (10 V - 2 V) / 25.28 The ISO contamination class can be calculated for a given current I or voltage U as follows: ISO code = (I - 4 mA)*(25.28 / 16 mA) ISO code = (U - 2 V)*(25.28 / 8 V)
Programming aid CS1000 – S7 National Aerospace Standard NAS 1638 (CS 13xx, only) The following NAS values can be output via the analog output: 6.4.1 HDA.NAS – Analog Signal NAS The HDA.NAS signal consists of 5 measured values (NAS 2 / NAS 5 / NAS 15 / NAS 25 / Status) which are output sequentially.
Programming aid CS1000 – S7 6.4.1.1 HDA signal 1-4 table The current or voltage range is dependent on the contamination class according to NAS=0.0 – 14.0 (resolution 0.1 class). Current I NAS class / error Voltage U I< 4.00 mA Cable break U<...
Programming aid CS1000 – S7 6.4.1.2 HDA status signal 5 table The current or voltage of the output signal (5) is dependent on the status of the CS 1000 as shown in the table below: Current I Status Voltage U I = 5.0 mA CS is functioning correctly U = 2.5 V...
Programming aid CS1000 – S7 Controller concept Module overview The following illustrated modules are based on the output of the HDA+ISO class at the analog output of the CS as 4 - 20 mA signal! Should you require the output at the analog output as HDA+SAE / HDA+NAS or an 0 –...
Programming aid CS1000 – S7 UDT1 Module - Data evaluation Address Name Type Starting value Comment +42.0 Evaluation_greater than_4um STRUCT +0.0 Specification_Parameter_Limitv REAL 2.400000e+001 limit specification for evaluation +4.0 seconds +6.0 minutes +8.0 HOUR hours +10.0 YEAR years +12.0 Memory_Max value REAL 0.000000e+000 Memory...
Programming aid CS1000 – S7 FC12 Module - Call up CS1000 Module: FC321 Initialization Network: Module call-up for every CS 1000 utilized, 3 timers, 1 counter and 1 DB must be reserved. ------------------------------------------- The DB is generated with the UDT1. The "Siemens Scale Module"...
Programming aid CS1000 – S7 FC12 Module - Evaluation Name Data Address Comment type Blink1s Bool BlinkMarker 1 second Input_PEW Word Analog periphery input word (Analog Input) Timer1 Timer Timer for pause time Timer2 Timer Timer for error monitoring Timer3 Timer Timer for Reset Counter1...
Programming aid CS1000 – S7 Visualization examples Presentation of the measured values Presentation of the measured values in separate visualization page Operating message Green: OK Red: NOK Display of the maximum value for each contamination channel Defining limit values Entering the Limit values HYDAC Filtertechnik GmbH Page 45...
