TDT1000
Transducer Diagnostic Tester

Kit Includes

TDT1000
Test cable with terminal box for transducers with NO connector
Power charger with USB to Micro USB adapter
Carrying case
International wall-plug adapter kit
(UK, Australia, and Europe)
OEM test cables
(if purchased)
TDT Test Block
QUICK START GUIDE

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TDT1000 and is the answer not in the manual?

Questions and answers

Summary of Contents for Airmar TDT1000

  • Page 1 QUICK START GUIDE TDT1000 Transducer Diagnostic Tester Kit Includes • TDT1000 • Test cable with terminal box for transducers with NO connector • Power charger with USB to Micro USB adapter • Carrying case • International wall-plug adapter kit (UK, Australia, and Europe) •...
  • Page 2 LE-enabled iOS or Android device to connect to the TDT1000. CAUTION: The transducer must be connected to the TDT1000 through an OEM test cable. Do not connect the transducer directly to the TDT1000. CAUTION: The transducer and OEM test cable must be connected to the TDT1000 before starting a test.
  • Page 3 Tested utilizing the TDT tester block. Best results when test block is submerged in water. Utilizing the correct OEM test cable (sold separately), connect the TDT1000 to the transducer cable (Diagram 1). If the transducer does not have a connector, it must be connected through the terminal box.
  • Page 4 Start Test Press the icon on the SensorCheck app to begin the test. NOTE: If the SensorCheck app does not connect to TDT1000, see the back panel of this Quick Start Guide, Troubleshooting. SensorCheck automatically checks for Screen A Screen B Xducer ID®...
  • Page 5 (Screen A).  Out of Range, alter the If the results are test variables and retest multiple times to ensure the results are consistent. Email test results with your contact information to tdt1000@airmar.com before removing or replacing the transducer (Screen B).
  • Page 6 03/15/21 As Airmar constantly improves its products, all specifications are subject to change without notice. All Airmar products are designed to provide high levels of accuracy and reliability, however they should only be used as aids to navigation and not as a replacement for traditional navigation aids and techniques.
