Page 2: Table Of Contents
Table of Contents Table of Contents ............2 Tools Required ................. 3 Hardware Included ..............3 Safety Information ............2 Warranty ................. 2 Pre-assembly (continued) ..........4 1 Year Warranty ................. 2 Package Contents ..............4 What is Covered ................ 2 Assembly ............... -
Page 3: Pre-Assembly
Place all wooden parts on a clean , flat , and soft surface (e.g.carpet or rug) to prevent scratch and damage to parts . TOOLS REQUIRED Safety Phillips Level goggles screwdriver HARDWARE INCLUDED NOTE: Hardware notshown toactual size. Part Quantity Descrlption Screw Ø6*40mm Washer Washer Allen Key Screw Ø6*80mm Screw Ø6*70mm Screw Ø4*40mm HOMEDEPOT.COM Please contact 1-877-527-0313 for further assistance. -
Page 4: Pre-Assembly (Continued)
Pre-assembly (continued) PACKAGE CONTENTS Part Quantity Descrlption Backrest Frame Seat Panel Left Side Rail Right Side Rail Front Rail Left Leg Right Leg... -
Page 5: Assembly
Assembly Attach seat panel to backrest frame Use allen key (DD) to tighten 4 screws(EE) with washers(CC&BB) to fix seat panel(B) to backrest frame(A) HOMEDEPOT.COM Please contact 1-877-527-0313 for further assistance. - Page 6 Assembly (continued) Use allen key(DD) to drive screw(AA) with washers (CC&BB)as shown,make sure the seat panel(B) and backrest frame(A) more stable. HOMEDEPOT.COM Please contact 1-877-527-0313 for further assistance.
- Page 7 Assembly (continued) Attach left side rail(C) and right side rail(D) to the backframe legs,drive screw(GG) tightly. HOMEDEPOT.COM Please contact 1-877-527-0313 for further assistance.
- Page 8 Assembly (continued) Attach front rail(E) to left leg(F) and right leg(G) with screws(GG). HOMEDEPOT.COM Please contact 1-877-527-0313 for further assistance.
- Page 9 Assembly (continued) Attach left leg(F) to left side rail (C)and right leg(G) to right side rail (D) with screw(GG). HOMEDEPOT.COM Please contact 1-877-527-0313 for further assistance.
- Page 10 Assembly (continued) Fix left leg(F) and right leg(G) to seat panel (B) with screw(FF) and washers (CC&BB) by allen key(DD) BBx4 HOMEDEPOT.COM Please contact 1-877-527-0313 for further assistance.
-
Page 11: Maintenance
Maintenance Keep the product away from direct heat and sunlight . Prolonged exposure to heat sources may cause scorching, or even cause color to fade . Regular vacuuming or light brushing helps to remove dirt and prevent soil build-up, which increases the appearance of wear . Periodically (every 90 days) make sure that the screws arefully tightened . - Page 12 Questions, problems, missing parts? Before returning to the store, call Customer Service 8 a.m. – 7 p.m., EST, Monday – Friday, 9 a.m. – 6 p.m., EST, Saturday 1-877-527-0313 HOMEDEPOT.COM Retain this manual for future use.
