IONFILTER ALISON User Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
ALISON
R

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ALISON and is the answer not in the manual?

Questions and answers

Related Manuals for IONFILTER ALISON

Summary of Contents for IONFILTER ALISON

  • Page 1 ALISON...

  • Page 2: Table Of Contents

    1. PRESENTATION ............................6 2. INTRODUCTION ............................7 2.1. WHAT IS REVERSE OSMOSIS? ....................7 2.2. HOW DOES THE MEMBRANE OF YOUR ALISON REVERSE OSMOSIS WORKS ? ....7 2.3. WATER POLLUTION ........................8 3. UNPACKING AND COMPONENTS ......................9 4.

  • Page 3: Presentation

    ALISON 1. PRESENTATION We would like to congratulate you on your choice of the ALISON reverse osmosis unit. Water quality is steadily deteriorating. In response to this, we have manufactured this small and compact domnestic osmosis unit in order that you may have access to pure, balanced water of the highest quality. Share the pure water produced by your ALISON reverse osmosis unit with your family and friends and recommend them to install a unit in their homes.

  • Page 4: Introduction

    ALISON 2. INTRODUCTION THE ALISON REVERSE OSMOSIS UNlTS OFFER YOU A BETTER QUALITY OF LlFE You will notice an improvement in the taste of your drinking water, and you can prepare better coffee, ice cubes and juices. Cooking with the purified water will improve the taste of food, and the water will be healthier for your children and good for your plants.

  • Page 5: Water Pollution

    ALISON 2.3. WATER POLLUTION Water is becoming more and more polluted due to domestic, agricultural and industrial waste. Domestic waste (human waste, waste water, chemical cleaning products), which has increased considerably due to the growing number of towns and villages near the traditional courses of rivers, often ends up in natural aquifers.

  • Page 6: Unpacking And Components

    The unit has been made with recyclable material. When the unit is scrapped, the electric power cable must be cut off. Never abandon the unit in the environment; it should be taken to a special material recovery centre where it can be recycled in accordance with the local regulations in force. ORIGINAL PACKAGEOF ALISON EQUIPMENT...
  • Page 7 ALISON LISTED REVERSE OSMOSIS MEMBRANE 220VAC/24VDC POWER SUPPLY (Ref. 2935) (Ref.2924/50 GPD, Ref.2925/75 GPD) 1/4” SUPPLY HOSE (Ref. 2720) CERAMIC TAP CONNECTION KIT (Ref.2650/Ref.2649) 1/4” DRAIN HOSE (Ref. 2721) 3/8” TAP CONNECTION HOSE 3/8” (Ref.2724) DRAIN KIT (Ref.2647) INSTRUCTIONS MANUAL...

  • Page 8: Description Of Elements

    ALISON 4. DESCRIPTION OF ELEMENTS storage tank minimum pressure gauge carbon post-filter carbon storage pre-filter tank pump turbidity pre-filter RO membrane container minimum inlet pressure gauge solenoid valve maximum pressure gauge auto-flushing solenoid valve PJK-260 card carbon pre-filter carbon pre-filter...

  • Page 9: Warnings Prior To The Installation Of Alison Reverse Osmosls Unlts

    The ALISON reverse osmosis unit is NOT a bacteriological unit that makes water drinkable. Do not connect with hot water (> 45°) In the case of the ALISON model, the pressure must be more than 3 kg/cm and less than 6 kg/cm .

  • Page 10: Views Of Alison And Alison-Pump

    ALISON 6. VIEWS OF ALISON AND ALISON-PUMP 7. OPERATION OF ALISON AND FLOWCHART The water coming from the public supply runs through connection kit (1) and flows through cut solenoid valve (2). From here goes to the water pre-treatment crossing a 5µ sediment filter(3) and two activated carbon filters (4 y 5), where the floating substances as well as chlorine and its byproducts are eliminated, together with some organics substances.
  • Page 11 ALISON From there the water flows through the reverse osmosis module (6), where the semi-permeable membrane is placed. The pressure of the water coming from public supply against the membrane makes it possible the reverse osmosis procedure. On one side, the pure water, after flowing through the check valve (7) is sent to a storage tank (11) and in other side, the water with salts in excess and unwanted substances is sent to the drain (13).

  • Page 12: Operation Of Alison-Pump And Flowchart

    ALISON 8. OPERATION OF ALISON-PUMP AND FLOWCHART Water flows through a connection kit (1) to a minimum pressure gauge (2) which stops the equipment if there is a cut in the public supply. Next, it flows through a cut solenoid valve (3), that closes the equipment when the storage tank is full.

  • Page 13: Front Panel

    ALISON 9. FRONT PANEL The front panel includes a button and four LEDs of different colour, which report about the status and events of the equipment. The blue led is always lighted on when the machine is plugged to mains. Otherwise there must be a power failure.

  • Page 14: Installation Of Alison And Alison-Pump Reverse Osmosis Equipments

    10. INSTALLATION OF ALISON AND ALISON-PUMP REVERSE OSMOSIS EQUIPMENTS Your ALISON and ALISON-PUMP reverse osmosis unitS rnust be fitted by an authorized technical service. Normally, the unit will be fitted under the kitchen sink or an adjoining piece of furniture. The work must be done as neatly as possible, leaving sufficient interconnection piping for its future maintenance.

  • Page 15: Start Up Of Alison Series

    ALISON 11. START UP OF ALISON SERIES Once the equipment has been installes, the start-up must be accomplished. To do this, follow these procedure: 1- Remove the covers: With the aid of a flat screwdriver, insert the tip of it in the slot of the assembly clips (white colour), and pull down.
  • Page 16 ALISON Pull out the Front Cover partially and unplug the connector from the LEDs PCB attached to it. Once it has been unplugged, pull out the Front Cover completely. LEDs PCB Connector Purge of carbon filters: Unplug the feed to the membrane container and the outlet tubo from the carbon pre-filter, and take it to the kitchen sink or to a bucket, opne the water inlet tap and plug to the mains.
  • Page 17 ALISON 11. Close the storage tank, and open again the public supply inlet. Wait 15 minutes and check that there a no leakages in the pluggings. If there are leakages, seal with teflon tape tightening by hand. Now the stop by the pressure of storage tank can be adjusted. This must be done in the maximum pressure gauge with a nº...

  • Page 18: Maintenance

    ALISON 12. MAINTENANCE It is important that the maintenance of your unit is carried out by an official ALISON service, which will use original replacement parts and will offer you a maintenance contract and a service guarantee. Any handling of the unit or use of a non-original replacement part by a company or person other than our distributors shall invalidate both the guarantee carried by the ALISON unit and your official distributor's guarantee.

  • Page 19: Alison Original Spare Parts

    ALISON 13. ALISON ORIGINAL SPARE PARTS Sediment Pre-filter FT-82 (Ref. 5459) Carbon Pre-filter FT-83 (Ref. 5467) 50 GPD Reverse Osmose Membrane (Ref. 2924) Carbon Last Post-filter FT-86 (Ref. 5475) 75 GPD Reverse Osmose Membrane (Ref. 2925) Cermic Faucet Lengthener (Ref. 2619) American Fridge T type Connector (Ref.

  • Page 20: Reduction Of Salts And Other Substances

    ALISON 14. REDUCTION OF SALTS AND OTHER SUBSTANCES INORGANIC ORGANIC Membrane TFC DDT ............ 99% ENDRINS ........... 99% SODIUM ........90-95% LINDANE..........99% CALCIUM ........93-98% METHOXYCHLOR ......99% MAGNESIUM ........ 93-98% TOXAPHENE ........99% ALLUMINIUM ........ 93-98% 2,4-D ..........96% COPPER ........

  • Page 21: Effects Of Pressure And Temperature On Reverse Osmosis

    ALISON 15. EFFECTS OF PRESSURE AND TEMPERATURE ON REVERSE OSMOSIS The rejection percentage of the membrane is normally 95% of salts, but when there are differences in the quality of the water, its temperature or pressure, this percentage may vary.

  • Page 22: Warranty

    The parts which have been replaced within the warranty are held in property by IONFILTER . The validity of the warranty starts in the date of purchase. For any claim within the warranty period it is required the purchase invoice. If any problem is reported during the warranty period, get in touch with your Dealer to replace immediately the defective part and ensure the correct operation of the equipment.

  • Page 23: Technical Features

    1 bar Minimum pressure 40º C Maximum temperature 2º C Minimum temperature TDSmax: 2000ppm Weight of ALISON : 11 kg Weight of ALISON-PUMP : 13,13 kg Production: Without counterpressure, at T=25º C, TDS= 250ppm, with softened water, 15% Conversion and inlet pressure of 3,4 bar: 189 l/day (flows may vary ±20%)

  • Page 24: Servicing Reports

    ALISON 18. SERVICING REPORTS TYPE OF SERVICE STAMP DATE Full Maintenance Repair Extra Disinfection Other Full Maintenance Repair Extra Disinfection Other Full Maintenance Repair Extra Disinfection Other Full Maintenance Repair Extra Disinfection Other Full Maintenance Repair Extra Disinfection Other Full Maintenance...
  • Page 25 ALISON TYPE OF SERVICE STAMP DATE Full Maintenance Repair Extra Disinfection Other Full Maintenance Repair Extra Disinfection Other Full Maintenance Repair Extra Disinfection Other Full Maintenance Repair Extra Disinfection Other Full Maintenance Repair Extra Disinfection Other Full Maintenance Repair Extra Disinfection...
  • Page 26 ALISON DATE TYPE OF SERVICE STAMP Full Maintenance Repair Extra Disinfection Other Full Maintenance Repair Extra Disinfection Other Full Maintenance Repair Extra Disinfection Other Full Maintenance Repair Extra Disinfection Other Full Maintenance Repair Extra Disinfection Other Full Maintenance Repair Extra Disinfection...
  • Page 27 “CE” CONFORMITY DECLARATION Tratamientos de Agua V.D.F, S.L. - Ionfilter C/ Aiguafreda 8 Pol. Ind. L’Ametlla Park 08480 L’AMETLLA DEL VALLÈS ( Barcelona ) WE DECLARE under our sole responsibility that: The reverse osmosis system for the water filtration intended for human...

  • Page 28: Spare Parts Identification

    19. SPARE PARTS IDENTIFICATION...

  • Page 29: List Of Spare Parts

    20. LIST OF SPARE PARTS Nº Reference Quantity Description 5467 Pre-carbon bayonet cartridge 5475 Post-carbon bayonet cartridge 2783 1/4” bsp x 1/4” JG Straight plug ---- Leds card support (according models) ---- Front cover (colours according models) ---- Front housing (colours according models) ---- Top fastening cover (according models) 2638...
  • Page 30 IONFILTER ESPAÑA Pol Ind. L’Ametlla Park c/Aiguafreda 8 08480 L’Ametlla del Vallès Barcelona (Spain) T +34 902 305 310 F +34 936 934 330 comercial@ionfilter.com www.ionfilter.com...
