  • Page 1 USER MANUAL LX1100 PHOTO- RADIO METER MODEL HD2302...
  • Page 2 LX1100 PHOTO-RADIOMETER _____________________________________________________________________________________________ Input for probes, 8-pole DIN45326 connector. Battery symbol: displays the battery charge level. Function indicators. Secondary display line. DATA key: displays the maximum (MAX), the minimum (MIN) and the average (AVG) of current measurements. CLR key: resets the maximum, average, and minimum value of the captured measurements.

  • Page 3: Table Of Contents

    LX1100 PHOTO-RADIOMETER _____________________________________________________________________________________________ TABLE OF CONTENTS 1. GENERAL CHARACTERISTICS ......................... 5 2. DESCRIPTION OF THE FUNCTIONS ......................6 3. PROBES AND MEASUREMENTS ........................8 4. WARNINGS ................................9 5. INSTRUMENT SIGNALS AND FAULTS......................10 6. LOW BATTERY WARNING AND BATTERY REPLACEMENT ..............11 6.1 WARNING ABOUT BATTERY USE ..............................

  • Page 4: General Characteristics

    LX1100 PHOTO-RADIOMETER _____________________________________________________________________________________________ 1. GENERAL CHARACTERISTICS This Photo-Radiometer is a portable instrument, fitted with a large LCD display for visualization of the measured data. It measures: • illuminance; • luminance; • PAR; • irradiance (across VIS-NIR, UVA, UVB and UVC spectral regions or in the measured effective irradiance according to the UV action curve).

  • Page 5: Description Of The Functions

    LX1100 PHOTO-RADIOMETER _____________________________________________________________________________________________ 2. DESCRIPTION OF THE FUNCTIONS The Photo-Radiometer keyboard is composed of single-function keys, except the ON-OFF/Auto-OFF key that has two functions (see the description of the key below). The pressing of a key is accompanied by a short confirmation "beep": a longer "beep" sounds if the wrong key is pressed.
  • Page 6 LX1100 PHOTO-RADIOMETER _____________________________________________________________________________________________ It resets the maximum, average, and minimum value of the captured measurements. connected to the instrument is displayed, updating it with the acquisition of new samples; - by pressing this key again the minimum (MIN) value is displayed;...

  • Page 7: Probes And Measurements

    LX1100 PHOTO-RADIOMETER _____________________________________________________________________________________________ It displays the difference between the current value and that measured on pressing the key. The "REL" message is displayed on the left. To return to the normal measurement, press the key again. 3. PROBES AND MEASUREMENTS The instrument works with probes of the LP471…...

  • Page 8: Warnings

    LX1100 PHOTO-RADIOMETER _____________________________________________________________________________________________ 4. WARNINGS Do not bend the probe connectors or force them upward or downward. Do not bend or force the contacts when inserting the probe connector into the instrument. 3. The sensors and filters should not exceed the temperature limits established with consequent irreparable degradation of their characteristics.

  • Page 9: Instrument Signals And Faults

    LX1100 PHOTO-RADIOMETER _____________________________________________________________________________________________ 5. INSTRUMENT SIGNALS AND FAULTS The following table lists all of the indications displayed by the instrument in different operating and error situations:...

  • Page 10: Low Battery Warning And Battery Replacement

    LX1100 PHOTO-RADIOMETER _____________________________________________________________________________________________ 6. LOW BATTERY WARNING AND BATTERY REPLACEMENT The battery symbol on the display constantly shows the battery charge status. To the extent that batteries have discharged, the symbol "empties". When the charge decreases still further it starts blinking.

  • Page 11: Instrument Storage

    LX1100 PHOTO-RADIOMETER _____________________________________________________________________________________________ 7. INSTRUMENT STORAGE Instrument storage conditions: • Temperature: -25…+65°C. • Humidity: less than 90%RH without condensation. • Do not store the instrument in places where: - humidity is high; - the instrument may be exposed to direct sunlight;...

  • Page 12: Notes About Working And Operative Safety

    LX1100 PHOTO-RADIOMETER _____________________________________________________________________________________________ 8. NOTES ABOUT WORKING AND OPERATIVE SAFETY Authorized use The technical specifications as given in chapter TECHNICAL CHARACTERISTICS must be observed. Only the operation and running of the measuring instrument according to the instructions given in this operating manual is authorized. Any other use is considered unauthorized.

  • Page 13: Technical Characteristics

    LX1100 PHOTO-RADIOMETER _____________________________________________________________________________________________ 9. TECHNICAL CHARACTERISTICS 9.1 TECHNICAL CHARACTERISTICS OF THE PHOTO-RADIOMETER Instrument Dimensions (Length x Width x Height) 140 x 88 x 38 mm Weight 160 g (complete with batteries) Material Display 2x4½ digits plus symbols Visible area: 52x42mm...

  • Page 14: Technical Characteristics Of Photometric And Radiometric Probes Complete With Sicram Module Equipped With The Instruments

    LX1100 PHOTO-RADIOMETER _____________________________________________________________________________________________ 9.2 TECHNICAL CHARACTERISTICS OF PHOTOMETRIC AND RADIOMETRIC PROBES COMPLETE WITH SICRAM MODULE EQUIPPED WITH THE INSTRUMENTS ILLUMINANCE measurement probe LP 471 PHOT complete with SICRAM module and equipped with the Instrument Measurement range (lux): Resolution (lux): α (temperature coefficient) f6(T) : <0.05% K Spectral range : in agreement with standard photopic curve V(λ)
  • Page 15 LX1100 PHOTO-RADIOMETER _____________________________________________________________________________________________ LUMINANCE measurement probe LP 471 LUM 2 complete with SICRAM module and equipped with the Instrument Measurement range (cd/m2): Resolution (cd/m2): Optical angle : 2° α (temperature coefficient) f6(T Spectral range : in agreement with standard photopic curve V(λ) ): <0.05% K...
  • Page 16 LX1100 PHOTO-RADIOMETER _____________________________________________________________________________________________ Quantum radiometric probe for the measurement of the photon flow across the chlorophyll range PAR LP 471 PAR complete with SICRAM module and equipped with the instrument Measurement range (μmol/m2s): Resolution (μmol/m2s): : 400 nm…700 nm Spectral range Calibration uncertainty : <5%...
  • Page 17 LX1100 PHOTO-RADIOMETER _____________________________________________________________________________________________ IRRADIANCE measurement probe LP 471 RAD complete with SICRAM module and equipped with the instrument Measurement range (W/m2): Resolution (W/m2): : 400 nm…1050 nm Spectral range Calibration uncertainty : <5% f2 (response according to the cosine law) : <6%...
  • Page 18 LX1100 PHOTO-RADIOMETER _____________________________________________________________________________________________ IRRADIANCE measurement probe LP 471 UVA complete with SICRAM module and equipped with the instrument Measurement range (W/m2): Resolution (W/m2): : 315 nm…400 nm (Peak 360 nm) Spectral range Calibration uncertainty : <5% f2 (response according to the cosine law) : <6%...
  • Page 19 LX1100 PHOTO-RADIOMETER _____________________________________________________________________________________________ IRRADIANCE measurement probe LP 471 UVB complete with SICRAM module and equipped with the instrument Measurement range (W/m2): Resolution (W/m2): : 280 nm…315 nm (Peak 305 nm) Spectral range Calibration uncertainty : <5% f2 (response according to the cosine law) : <6%...
  • Page 20 LX1100 PHOTO-RADIOMETER _____________________________________________________________________________________________ IRRADIANCE measurement probe LP 471 UVC complete with SICRAM module and equipped with the instrument Measurement range (W/m2): Resolution (W/m2): : 220 nm…280 nm (Peak 260 nm) Spectral range Calibration uncertainty : <5% f2 (response according to the cosine law) : <6%...
  • Page 21 LX1100 PHOTO-RADIOMETER _____________________________________________________________________________________________ Measurement probe LP 471 ERY OF EFFECTIVE TOTAL IRRADIANCE (Weff/m2) weighted according to the UV action curve (CEI EN 60335-2-27) complete with SICRAM module and equipped with the instrument Measurement range (Weff /m2): Resolution (Weff /m2): : UV action curve for erythema measurement (250 nm…400 nm)

  • Page 22: Order Codes

    PHOTO-RADIOMETER _____________________________________________________________________________________________ 10. ORDER CODES HD2302.0K (LX1100) The kit is composed of the instrument HD2302.0, 3 1.5V alkaline batteries, operating manual, and case. The probes must be ordered separately. 10.1 PROBES COMPLETE WITH SICRAM MODULE ➢ LP 471 PHOT Photometric probe for ILLUMINANCE measurement complete with SICRAM module, spectral response in agreement with standard photopic vision, diffuser for cosine correction.
