Summary of Contents for Heatwave Sonoma SA7019
- Page 1 OWNER’S MANUAL Sonoma 3 Person Hemlock Corner Carbon Sauna SA7019 Ver. 9/20...
-
Page 2: Table Of Contents
TABLE OF CONTENTS ASSEMBLY TIPS & WARNINGS PARTS IDENTIFIER ASSEMBLY INSTRUCTIONS OPERATION INSTRUCTIONS FOR MP3 PLAYER ENJOYING YOUR SAUNA HEALTH & SAFETY WARNINGS CLEANING & MAINTANENCE TROUBLESHOOTING GUIDE 13-14 SAUNA USE DISCLAIMER REPLACEMENT PARTS WARRANTY INFORMATION If you would like a French version of this manual, please contact our Customer Service Department at 800-759-0977 or custserv@splashnetxpress.com Si vous voulez une version française d’un manuel, s'il vous plaît contacter notre service à... -
Page 3: Assembly Tips & Warnings
ASSEMBLY TIPS & WARNINGS • Before you begin, read all assembly instructions and safety warnings carefully. • This sauna requires at least 2 adults to complete assembly. • Remove all of the contents from boxes and verify that you have all of the parts shown on the Parts Note: Some parts may be pre-installed or pre-assembled. -
Page 4: Parts Identifier
PARTS IDENTIFIER (NOT TO SCALE) Illustrations Not to Scale FRONT PANEL LEFT BACK PANEL RIGHT BACK PANEL RIGHT FRONT PANEL LEFT FRONT PANEL WITH GLASS DOOR 6, 7 RIGHT & LEFT FRONT NARROW ROOF FLOOR FLOOR HEATER FRONT SIDE GLASS &... -
Page 5: Assembly Instructions
ASSEMBLY INSTRUCTIONS 1. Begin assembly by determining an appropriate location for your sauna – see ASSEMBLY TIPS & WARNINGS for details. Place the FLOOR PANEL on the oor in this location. 2. Place the FRONT PANEL WITH DOOR on the FLOOR PANEL, against the oor trim piece on the FLOOR and have second person hold in place to perform step 3. - Page 6 ASSEMBLY INSTRUCTIONS (CONT.) 4. Place the LEFT FRONT PANEL on the other side of the FRONT DOOR PANEL and engage three metal clips on side of door with three brackets as you did in Step 3. 5. Place the LEFT BACK PANEL PANEL on the FLOOR as shown and engage three buckles. Place the RIGHT BACK PANEL PANEL on the FLOOR in same manner and engage remaing buckles.
- Page 7 ASSEMBLY INSTRUCTIONS (CONT.) Plug in all bench heater plugs into wires from back wall. Make sure connections are tight. Attach the BENCH SEATS with (2 ea.) 2” SCREWS in pre-drilled holes into BENCH SUPPORT. Lift the ROOF above the sauna, feeding the heater cables on side & back walls, and the wire harnesses and power plug in back left corner, through the corresponding holes on perimeter of roof.
- Page 8 ASSEMBLY INSTRUCTIONS (CONT.) 10. Feed the main power cable through hole in ROOF and plug securely into receptacle on back of POWER SUPPLY box . Secure the ROOF COVER with (24) 3/4” SCREWS. 11. Attach the DOOR HANDLE through GLASS DOOR FRAME using (2) 2-3/8” (60MM) SCREWS. 12.
- Page 9 ASSEMBLY INSTRUCTIONS (CONT.) 13. Remove the back cover of the OXYGEN IONIZER by turning it as indicated. Unwrap and install the fragrance patch, then reattach the back cover. Attach the OXYGEN IONIZER in the designated position with (2) 3/4” SCREWS. Plug the power cable into the OXYGEN IONIZER. Note: Press ION to release negatively charged ions to purify the air &...
-
Page 10: Operation Instructions For Mp3 Player
OPERATION INSTRUCTIONS FOR MP3 PLAYER BLUETOOTH 1. Press “POWER” button to turn on MP3 player 2. Press “MODE” button until “AUH” appears on screen* *Other “MODE” options include radio, USB & SD 3. Phone Settings A. Select “SETTINGS” on B. Select “BLUETOOTH” C. -
Page 11: Enjoying Your Sauna
ENJOYING YOUR SAUNA 1. Prior to initial use, wipe down all interior surfaces of the sauna with a damp cloth. 3. Always drink plenty of water before, during and after your sauna session to stay properly hydrated. 4. A normal sauna session should last 30 minutes or less. 5. -
Page 12: Health & Safety Warnings
HEALTH & SAFETY WARNINGS 1. Review all instructions and warnings before operating your sauna. A sauna is not a toy. Seri- ous injury may result from negligence, intentional misuse and failure to follow safety instruc- tions. 2. Hyperthermia Danger: Hyperthermia occurs when the body absorbs more heat than it can emergency and requires immediate treatment to prevent disability or death. -
Page 13: Cleaning & Maintanence
CLEANING & MAINTENANCE 1. Always unplug the sauna and allow it to cool down before performing any cleaning or maintenance. 2. Use furniture polish or furniture oil when cleaning the sauna exterior. 3. The sauna interior surfaces should only be wiped down with a damp cloth. Do NOT use 4. -
Page 14: Sauna Use Disclaimer
TROUBLESHOOTING GUIDE (CONT.) Problem THE CONTROL PANEL DOES NOT WORK 1. Check that all the connections are tight. 2. If the numbers are scrambled or the buttons are unresponsive, Solution replace the Control Panel. 3. If the temperature indicator does not work or reads “--” or “EP”, replace the Control Panel. -
Page 15: Replacement Parts
REPLACEMENT PARTS Rev. 9/20 SA7019 SONOMA 3-PERSON HEMLOCK CORNER CARBON HEATERS SAUNA REF. # DESCRIPTION PART NUMBER QTY. CARTON FRONT PANEL WITH GLASS DOOR SAP7112 LEFT BACK WALL PANEL SAP7113 RIGHT BACK WALL PANEL SAP7114 RIGHT FRONT WALL PANEL SAP7115 LEFT FRONT WALL PANEL SAP7116 RIGHT FRONT SIDE GLASS... -
Page 16: Warranty Information
SAUNA WARRANTY REGISTRATION CARD 1. This sauna has a 7-Year Limited Warranty against defects in materials and workmanship from date of purchase. To receive the warranty, the card below must the wood structure*. Heating elements and all electronics are covered by a 5-Year Limited Warranty. The radio/CD player (if included with your sauna) is covered by a limited 1-Year Warranty.
