© 2007. All rights reserved. Black Box Corporation.
MultiLink and MultiLink II Media Converters
Make better use of your fiber optic runs
Make better use of your fiber optic runs
with these Layer 2 copper-to-fiber converters.
with these Layer 2 copper-to-fiber converters.
FREE 24-hour Tech Support: 724-746-5500
blackbox.com
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Black Box MultiLink LB1350A-ST
Summary of Contents for Black Box MultiLink LB1350A-ST
- Page 1 © 2007. All rights reserved. Black Box Corporation. MultiLink and MultiLink II Media Converters Make better use of your fiber optic runs Make better use of your fiber optic runs with these Layer 2 copper-to-fiber converters. with these Layer 2 copper-to-fiber converters.
- Page 2 High-Density Media Switch (LB9030A) Converter II Chassis (LMC5201A) with 10-/100-Mbps Module (LMC5119C) MultiLink Media Converter, Managed Multimode ST (LB1350A-ST) Department A Department B Redundant Link Application MultiLink II Media Converter, Managed Multimode SC (LB1302A-SC) Express Ethernet Switch (LB9021A) Main fiber link...
- Page 3 4/24/2007 724-746-5500 #26437 OVERVIEW The MultiLink and MultiLink II are sophisticated Layer 2 media converters that enable you to not only extend your network over fiber, but to combine two, three, or four copper ports over a single or dual fiber link. Because you’re getting more use from each fiber optic cable, you save on cabling costs.
- Page 4 (FTTD) applications. You can connect four homes or workstations to a fiber optic backbone over one pair of fibers with the MultiLink. MultiLink II The BLACK BOX MultiLink II features two copper ports ® and two fiber ports. The buffered twisted-pair ports offer VLAN protection between them.
- Page 5 Class A, VCCI Class; ICES; EMC; CE Conversion Method — Buffered Media Domain (BMD) Distance (Maximum) — LB1350A-SC, LB1350A-ST, LB1351A-ST: 2 km (1.2 mi.); LB1350A-SM15, LB1351A-SM15: 15 km (9.3 mi.); LB1350A-SM40, LB1351A-SM40: 40 km (24.9 mi.) Hardware Type — Store-and-forward, wire-speed, non-blocking switch MIBs Supported —...
