  • Page 1 Manual www.ltech-led.com...

  • Page 2: Product Features

    Product Features ● Adopt latest DALI standard protocol IEC62386 ● Support switch and dimming function. ● Powered by DALI bus. ● Easy to set DALI address. ● Support group, unicast, broadcast mode. Technical specs Name: DALI knob panel Working Temp: -10°C~55°C...
  • Page 3 Mounting & Dismounting Instructions Base Baseplate Knob panel Typical base are as follow: European Style 86 Type Dismount...

  • Page 4: Product Size

    Product Size Unit：mm Key Functions Terminals 10 levels ： rotary switch 16 levels ： rotary switch Power and signal combination sockets Turn the knob clockwise, the brightness increases. Turn the knob counterclockwise, the brightness decreases.Turn the knob counterclockwise to the end, the dimmer will be turned off(A click can be heard).
  • Page 5 DALI Address Settings X = (0-6): unicast mode; X = 7: group mode; X = 8 or 9: broadcast mode. Via rotary switch, you can set 64 unicast address (0-63), 16 group address (0-15) and broadcast address. Unicast mode address: 0-63) E.g.: Set initial address to 40 in unicast mode.

  • Page 6: Wiring Diagram

    Wiring Diagram LED strip DALI bus power supply COB spotlight COB spotlight COB spotlight Update time: 15/09/2020_A1...
