Commissionig
Ensure that the product is sitting properly on the suspended
ceiling frame (see Fig. 4). Replace any other ceiling tiles.
Replace fuse or circuit breaker and switch on. Your light is
now ready for use.
Technical data
Supply
240 V~, 50 Hz
Voltage:
Bulb
40W LED SMD, 4000K, UGR<19
Type:
The light source of this luminaire is not replaceable; when the light source reaches its end of life the whole
luminaire shall be replaced.
Conformity with all relevant EC Directive requirements.
The power supply is Double Insulated and does not require connection to an Earth circuit.
Waste electrical products should not be disposed of with household waste. Please recycle where facilities
exist. Check with your Local Authority or local store for recycling advice.
This product is rated at IP40.
40
IP
Accessories available
Surface mount kit - 81850
This kit will allow the panels to be mounted to the
ceiling when not being used in a suspended ceiling.
Care and Safety
We recommend cleaning with a soft dry cloth. Do not use solvents or abrasive cleaners as these could damage the finish.
For your safety, always switch off the power supply before cleaning.
V2 07/01/2020
Saxby Lighting. BH17 7BY
Fig. 4
Suspension kit - 81744
This kit will allow the panels to be suspended up to
1 metre from the ceiling.
Instruction manual
Stratus
81026
www.saxbylighting.com
UGR
<19
