Wiring

Having correctly identified the wiring from your existing light fitting, Pull the mains wire through the hole and connect to the
connection block(not supplied) in the following way.
NEUTRAL
EARTH (GREEN/YELLOW)
SWITCHED LIVE
Check that...
You have to correctly identified the wires.
The connections are tight.
No loose strands have been left out of the connection block.

Technical data

Supply
240 V~, 50 Hz
Voltage:
92311: 100W LED module, 6500K
Bulb
92515: 150W LED module, 6500K
Type:
92516: 200W LED module, 6500K
The light source of this luminaire is not replaceable; when the light source reaches its end of life the whole
luminaire shall be replaced.
Conformity with all relevant EC Directive requirements.
The is Class 1 product must be earthed.
Waste electrical products should not be disposed of with household waste. Please recycle where facilities
exist. Check with your Local Authority or local store for recycling advice.
This product is not suitable for dimming.
Caution! Risk of electric shock!
This product is rated at IP20.
20
IP
This product is rated at IK08.
08
IK

Care and Safety

We recommend cleaning with a soft dry cloth. Do not use solvents or abrasive cleaners as these could damage the finish.
For your safety, always switch off the power supply before cleaning.
Always disconnect the product from mains at least 10 minutes allowing to cool down before any maintenance or adjustment.
V1 19/03/2019
Saxby Lighting. BH17 7BY
BLUE (N)
GREEN/YELLOW
BROWN (L)
Instruction manual
GAGE
92311, 92515, 92516
www.saxbylighting.com
