Arlight CT305RL DMX512 RGB LED Manual

RGB/DMX-512 декодер С305 OS
(12/24V, 180/360W, IR-ДУ)

Product specification

• Meets DMX512(1990)
• Max.5A/CH output
• IR Remote control
• Apply to verious of LED Driver
Summarize
Welcome to use CT305RL DMX512 RGB LED controller. CT305RL, a controller with the advanced
micro-computer control technology, converts the DMX-512/1990 digital signal widely used in inter-
national to the analog signal. Output 1~3 channels for option and each channel able to achieve 256
gradations, and also it can be used as the connector between PC digital-light controller and analog
light modulator. It is mainly used for the controlling of buildings & lights applied LED. Also, it is able to
change the DMX control & self-changing program freely by IR remote and make it be with many kinds
of changing effect.

Product Features

• Meets DMX512/1990
• 256 gradations and full-color control
• 3 output channels and constant voltage Mx.5A per channel
• It can achieve asynchronous color changing effect under working with DMX control system
• With many kinds of self-changing effect, and it is able to adjust the speed, brightness...etc
• Mode,suspend protection,output short circuit protection
• With IR remote function, and the red LED will be flashing once the IR signal found.
• Easy to connect and install
• With the light color selected mechanism, and be able to control the light with 1~3 colors
• Setting the DMX address freely
• Modularizing and can be matched with different LED module neatly
• Custom-made

Tech-parameter

Decode CH.
Signal Input
Signal output
Power Supply
Power Dis.
Power output
IR Romote distance ≤10m
Work Temp.
Size:
Weight:
3CH
DMX-512/1990 standard digital signal
0~24V , Max. 5A
DC12~24V
<1W
12V: <180W; 24V: <360W
0~70°C
175(mm)*45(mm)*35(mm),(can be custom-made)
≤300g
