Arlight LT3200-350 Quick Start Manual

Диммер LT3200-350
(12-36V, 350mA, 12.6W)
Диммер LT3200-700
(12-36V, 700mA, 25W)
LED Intelligent Dimmer
Forword
Thanks for choosing our LT-3200 Controller. Before
installation and use, we strongly recommend you
to read through this manual carefully. If device has been damaged during transport, please report it to
your supplier immediately. Please don't take any action without contacting your supplier first.
After-sales Service
From the day you purchase our products within a year, if being used properly in accordance with the
instruction, and quality problems occur, we provide free repair or replacement services except the fol-
lowing cases:
1. Any defects caused by wrong operations..
2. Any damages caused by unauthorized removal, maintenance, modifying circuit, incorrect connections
and replacing chips.
3. Any damages due to transportation, vibration etc after the purchase.
4. Any damages caused by earthquake, fire, lightning strike, pollution and abnormal voltage.
5. Any damages caused by negligence, inappropriate storing at high temperature and humidity environ-
ment or near harmful chemicals.
6. Product has been updated
Safety Warnings
1. Please don't install this controller in lightening, intense magnetic and high-voltage fields.
2. To reduce the risk of component damage and fire caused by short circuit, make sure correct connec-
tion
3. Always be sure to mount this unit in an area that will allow proper ventilation to ensure a fitting tem-
perature.
4. Check if the voltage and power adapter suit the controller & if anode or cathode definition is the same
as the controller's.
5. Don't connect cables with power on, make sure a correct connection and no short circuit checked with
instrument before power on.
6. Please don't attempt any repairs yourself; doing so will void your manufactures warranty.
For update information, kindly please consult with your supplier.
Function Brief
LT-3200 is an intelligent dimmer dedicated to adjust the brightness of LED light, adopted the most
advanced PWM (Pulse-Width Modulation) digital brightness-adjusting technology at present, users
can either turn around the knob manually or use the IR wireless remote control panel to control the
brightness infinitely; Suitable for installation of commercial and household 86-style socket; can install
the socket visibly outside the wall or inside the wall invisibly; can adjust the brightness of both low-
power and hi-power LED illumination lights, can meet different brightness requirements at different
time, and extend life tenure of LED, so energy-saving.
