- Page 1 Manual english CRD400 INS Casambi LED-/Retrofit-Dimmer Document date: 09.07.2021 Document name: 10273_MA_en_A4_CRD400_20210709 Carl-Zeiss-Str. 10-14 Tel. +49(0)9721-7766 0 www.maintronic.de 97424 Schweinfurt / Germany Fax. +49(0)9721-7766 18 info@maintronic.de...
-
Page 2: Table Of Contents
1. Manual - English ..................2 1.1 Quick set-up . -
Page 3: Manual - English
MTC maintronic GmbH - Schweinfurt | Germany - www.maintronic.com Manual - English CRD400 - Casambi LED-/Retrofit-Dimmer Technical Features Product Item number Valid from version: (Hardware | Firmware) CRD400 INS 10.273 H2 | F1.0 Page CRD400 INS - Manual Date: 09.07.2021... - Page 4 MTC maintronic GmbH - Schweinfurt | Germany - www.maintronic.com Manual - Table of Download Content Determining the number of luminaires which can be connected CRD400INS > 10273_IN_de- Casambi Sensors and Parameters en_A4_CRD400INS_20210209.pdf Commissioning CRD400INS > 10273_MA_de_A4_CR D400_202010311.pdf Configure push-button input CRD400INS >...
-
Page 5: Quick Set-Up
MTC maintronic GmbH - Schweinfurt | Germany - www.maintronic.com Quick set-up STEPS for a quick set-up Step 1 Step 2 Product description Connection Step 3 Step 4 Calibration procedure Commisioning Step 5 Step 6 Operation Pushbutton configuration Page CRD400 INS - Manual... -
Page 6: Product Description
MTC maintronic GmbH - Schweinfurt | Germany - www.maintronic.com Product description Intended Use Content of this page Digital leading edge and trailing edge phase dimmer with automatic load detection for a single dimmed phase with a max. load of 380VA. Equipped with an additional push button input which Intended Use extends the dimmer with an fast analogue control. - Page 7 MTC maintronic GmbH - Schweinfurt | Germany - www.maintronic.com With the integrated strain relief the installation in a junction box is not necessary. Page CRD400 INS - Manual Date: 09.07.2021...
-
Page 8: Connections And Elements
MTC maintronic GmbH - Schweinfurt | Germany - www.maintronic.com Connections and elements Content of this page Connections Connections Load output 230V AC Wiring Connection diagram Elements Neutralleiter Neutralleiter Input Voltage 230V AC Related content Pushbutton input N Commissioning Pushbutton input L... - Page 9 MTC maintronic GmbH - Schweinfurt | Germany - www.maintronic.com Device-button Status-LED Page CRD400 INS - Manual Date: 09.07.2021...
-
Page 10: Calibration Procedure
MTC maintronic GmbH - Schweinfurt | Germany - www.maintronic.com Calibration procedure Content of this page Measuring (AdaptivDIM) Measuring (AdaptivDIM) When commissioning for the first time, the dimmer will calibrate accordingly to the connected load Meassure mode (duration max. 60 sec.). - Page 11 MTC maintronic GmbH - Schweinfurt | Germany - www.maintronic.com Lamp type - currently used dimming mode The load will be automatically calibrated (Adaptive DIM) and set to the best parameters. If a mode wants to be set manually or another light source is used, a new calibration can be started in the app (via the Measure mode parameter) and a calibration method is selected.
-
Page 12: Commissioning
MTC maintronic GmbH - Schweinfurt | Germany - www.maintronic.com Commissioning Content of this page To make sure that the functionality of the device is up to date, first of all you have to check if a new firmware is available. -
Page 13: Operation
MTC maintronic GmbH - Schweinfurt | Germany - www.maintronic.com Operation Content of this page Operation with Casambi Operation with Casambi The device can be controlled with Casambi via a smartphone or tablet or alternatively via a button Operation with device button input. - Page 14 MTC maintronic GmbH - Schweinfurt | Germany - www.maintronic.com All wiring and the pushbuttons must be insulated for the maximum supply voltage. Ensure the appropriate contact protection after installation. All push-buttons of the well-known switch manufacturers are suitable. A push-button style must be selected, before the button inputs may be configured.
-
Page 15: Configure Push-Button Input
MTC maintronic GmbH - Schweinfurt | Germany - www.maintronic.com Configure push-button input Content of this page Push-button inputs can be individually assigned with desired functions. In order to do this, the following steps are necessary: Open Casambi app and tap on „... More“... -
Page 16: Dimming Characteristics
MTC maintronic GmbH - Schweinfurt | Germany - www.maintronic.com Dimming characteristics Content of this page Power rating of retrofit dimmers Power rating of retrofit dimmers Load cutting method Power output in percent Calculated Derating type power load Short circuit Noise emission Ohmic approx. -
Page 17: Dimming Curve
MTC maintronic GmbH - Schweinfurt | Germany - www.maintronic.com Dimming curve The used dimming curve can be selected, per default the linear curve is used. To achieve a Content of this page different dimming behavior, the dimming curve can be selected. The Casambi curves 3 and 4 are intended when several dimmers from different manufacturers are operated together. - Page 18 MTC maintronic GmbH - Schweinfurt | Germany - www.maintronic.com Casambi Casambi Log Compatibility mode Page CRD400 INS - Manual Date: 09.07.2021...
-
Page 19: Casambi Sensors And Parameters
MTC maintronic GmbH - Schweinfurt | Germany - www.maintronic.com Casambi Sensors and Parameters Content of this page Sensors Sensors With the sensors, various states can be queried and displayed in the Casambi APP. Parameters Casambi Description Can be Value Units... - Page 20 MTC maintronic GmbH - Schweinfurt | Germany - www.maintronic.com Load Number Show load number - max. Illuminants of the same type are 0... digits displayed System info The System Info is displayed with a text. If there is no error, the Text text is “O.K.”.
-
Page 21: Reset To Factory Default Settings
MTC maintronic GmbH - Schweinfurt | Germany - www.maintronic.com Reset to factory default settings Content of this page The dimmer can be reset via the device button and the settings will be restored to the factory default settings. For a reset, the device must not be paired with a Casambi network. -
Page 22: Page Tree | Appendix
MTC maintronic GmbH - Schweinfurt | Germany - www.maintronic.com Page tree | Appendix Page tree search Page index Bereichsindex Gesamtzahl der Seiten: 39 ... 0 ... 0 ... 0 ... 10 ... 4 ... 2 ... 2 ... 1 ... 1 ... - Page 23 MTC maintronic GmbH - Schweinfurt | Germany - www.maintronic.com Seite: Determining the number of luminaires which can be connected Seite: Einmessvorgang The determination about the number of connectable AdaptivDIM Beim erstmaligen Inbetriebnehmen wird sich der luminaires is always related to "identical manufacturer/type Dimmer auf die angeschlossene Last einmessen (Dauer max.
- Page 24 Für einen Reset darf das Gerät nicht mit have placed in us. We, the team of maintronic, wish you a lot of einem Casambi Netzwerk gekoppelt sein. Schritt-für-Schritt- fun with this product.
-
Page 25: Safety Information | General Information
Legals The division building automation and all associated products are products of MTC maintronic® GmbH (hereafter maintronic). All rights reserved, as well as mistakes and typing errors. The trademarks and trade names mentioned in this document are the property of their respective owners. - Page 26 MTC maintronic GmbH - Schweinfurt | Germany - www.maintronic.com WARNING The signal word "WARNING" indicates a possibly imminent danger. If it is not avoided, death or very serious injuries may result. CAUTION The signal word "CAUTION" indicates a possibly imminent danger. If it is not avoided, slight or minor injuries may result.
- Page 27 MTC maintronic GmbH - Schweinfurt | Germany - www.maintronic.com Waste disposal In accordance with European Directive 2002/96/EC (it`s) not longer usable electronic devices and defective or used batteries (European Directive 2006/66EG) must collected separately and disposed by an environmentally sound recycling.
-
Page 28: Symbol Explanation
MTC maintronic GmbH - Schweinfurt | Germany - www.maintronic.com Symbol explanation Symbol explanation | Symbol Erklärung Icon Beschreibung | Description Icon Beschreibung | Description Die Zahl zeigt die Anzahl der Ausgangs- Astro Funktion - steuert Szenen nach Kanäle des Gerätes an. - Page 29 MTC maintronic GmbH - Schweinfurt | Germany - www.maintronic.com Nullpunktschalter - Das Gerät schaltet Schutzklasse III - Schutz durch beim Nulldurchgang der Sinuswelle ein Kleinspannung bzw. auch wieder aus. Protection class III - protection throught Zero-cross switch supplied from a seperated extra-low-...
- Page 30 MTC maintronic GmbH - Schweinfurt | Germany - www.maintronic.com The number indicates how much space Tasteingang (in TE) the device takes up on a DIN rail. Push-button input Unterputzgehäuse - In Funk Tasteingang Installationsdosen oder in Geräte der Wireless Push-button input...
