FCC Statement

This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to Part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful
interference in a residential installation.
Any changes or modification made to this equipment void the user's authority to operate this
equipment.
This equipment generates, uses, and radiate radio frequency energy and, if not installed and used
in accordance with the instructions, may cause harmful interference to radio communications. However, there is
no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be determined by turning the equipment off and on, the
user is encouraged to try to correct the interference by one or more of the following measures:
* Reorient or relocate the receiving antenna.
* Increase the separation between the equipment and receiver.
* Connect the equipment into an outlet on a circuit different from that to which
the receiver is connected.
* Consult the dealer or an experienced radio/TV technician for help.
* All external cables connecting to this basic unit must be shielded.
This digital apparatus does not exceed the Class B limits for radio noise emissions from digital
apparatus as set out in the radio interference regulations or the Canadian Department of Communications.
This equipment is in conformity with the EMC directive.
C. D. C. Statement
C. D. C. Statement
C. D. C. Statement
C. D. C. Statement
C. D. C. Statement
CE Mark
CE Mark
CE Mark
CE Mark
CE Mark
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the iDEQ 210P and is the answer not in the manual?

Questions and answers

Related Manuals for Biostar iDEQ 210P

Summary of Contents for Biostar iDEQ 210P

  • Page 1: Fcc Statement

    FCC Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. Any changes or modification made to this equipment void the user’s authority to operate this equipment.

  • Page 2: Overview

    The information in this document is subject to change without notice and should not be construed as a commitment by the manufacturer. Product may not be exactly as photo shown. The manufacturer assumes no responsibility for any errors that might appear in this document. The software described in this document is furnished under a license and may be used or copied only in accordance with the terms of such license.

  • Page 3: Important Safety Information

    Important Safety Information Please read these safety instructions carefully. Please keep this User’s Manual for later reference. Please disconnect this equipment from AC outlet before cleaning. Don‘t use liquid or sprayed detergent for cleaning. Use moisture sheet or clothe for cleaning. For pluggable equipment, the socket-outlet shall be installed near the equipment and shall be easily accessible.

  • Page 4: Table Of Contents

    Table of Contents FCC Statement ... 1 Overview... 2 Important Safety Information ... 3 Section 1 Introduction... 5 Section 1 Introduction... 5 Section 1 Introduction... 5 Section 1 Introduction... 5 Section 1 Introduction... 5 1.1 Begin Your Tour In The DIY World ... 6 1.2 Checking the Equipments ...

  • Page 6: Begin Your Tour In The Diy World

    Begin Your Tour In The DIY World Begin Your Tour In The DIY World Begin Your Tour In The DIY World Begin Your Tour In The DIY World Begin Your Tour In The DIY World Congratulations on purchasing this cutting-edge Small Form Factor Congratulations on purchasing this cutting-edge Small Form Factor Congratulations on purchasing this cutting-edge Small Form Factor Congratulations on purchasing this cutting-edge Small Form Factor...

  • Page 7: Checking The Equipments

    Checking the Equipments Checking the Equipments Checking the Equipments Checking the Equipments Checking the Equipments This section describes the contents of your computer pages. Before This section describes the contents of your computer pages. Before This section describes the contents of your computer pages. Before This section describes the contents of your computer pages.

  • Page 10: Layout And Components Index

    Layout And Components Index Layout And Components Index Layout And Components Index Layout And Components Index Layout And Components Index J1394A1 JRJ45USB1 PCI1 AGP1 Wireless LAN Chip IEEE 1394 SATA Chip Chip SATA1 IDE1 IDE2 FDD1 SATA2 SPDIFI1 J1394B1 NOTE: “ ” represents the first pin. JCOM2D JCOM1 JKBMSV1...

  • Page 11: Component Index

    Component Index Component Index Component Index Component Index Component Index This section helps you to locate the components in the motherboard This section helps you to locate the components in the motherboard This section helps you to locate the components in the motherboard This section helps you to locate the components in the motherboard This section helps you to locate the components in the motherboard and to find the details about them easily.

  • Page 12: K8Nbp Motherboard Features

    K8NBP Motherboard Features K8NBP Motherboard Features K8NBP Motherboard Features K8NBP Motherboard Features K8NBP Motherboard Features In this section, you shall find all the information about the In this section, you shall find all the information about the In this section, you shall find all the information about the In this section, you shall find all the information about the In this section, you shall find all the information about the motherboard in your computer, including its features, various jumpers,...

  • Page 13: Main Memory

    Main Memory * Supports up to two DDR devices. * Supports 200/266/333/ 400 MHz (with ECC) DDR devices. * Maximum memory size is 2GB. Total Memory Size with Unbuffered DIMMs i t a On Board IDE * Supports four IDE disk drives. * Supports PIO Mode 5, Bride Mode and Ultra DMA 33/66/100/133 Bus Master Mode.
  • Page 14 Serial ATA/RAID * Chips: VT6420/VT6410 * Supports RAID 0, 1. * Supports 2 Serial ATA (SATA) ports. - Compliant with SATA 1.0 specification. - Data transfer rates up to 150 Mb/s. On Board AC’ 97 Sound Codec * Chip: ALC655. * Compliant with AC’97 specification.

  • Page 15: Bios & Software

    B. BIOS & Software B. BIOS & Software B. BIOS & Software B. BIOS & Software B. BIOS & Software BIOS * Award legal BIOS. * Supports APM1.2. * Supports ACPI. * Supports USB Function. * The setup procedures can be found in the Setup Driver CD. Software * Supports Warpspeeder , 9th Touch...

  • Page 16: Installation And Setup

    Installation and Setup Installation and Setup Installation and Setup Installation and Setup Installation and Setup In this section, you will learn how to install the CPU, DDR Module, In this section, you will learn how to install the CPU, DDR Module, In this section, you will learn how to install the CPU, DDR Module, In this section, you will learn how to install the CPU, DDR Module, In this section, you will learn how to install the CPU, DDR Module,...
  • Page 17 (2) System Fan Header: JSFAN1 Assignment Ground +12V FAN RPM Rate Sense (3) North Bridge Fan Header: JNFAN1 Assignment Ground +12V FAN RPM Rate Sense 3. Installing DDR Module 1. Unlock a DIMM slot by pressing the retaining clips outward. Align a DIMM on the slot such that the notch on the DIMM matches the break on the slot.
  • Page 18 5. Jumpers, Headers, Connectors & Slots: (1) Floppy Disk Connector: FDD1 (1) Floppy Disk Connector: FDD1 (1) Floppy Disk Connector: FDD1 (1) Floppy Disk Connector: FDD1 (1) Floppy Disk Connector: FDD1 The motherboard provides a standard floppy disk connector that supports 360K, 720K, 1.2M, 1.44M and 2.88M floppy disk types.
  • Page 19 * Clear CMOS Procedures: 1. Remove AC power line. 2. Set the jumper to "Pin 2-3 Close". 3. Wait for five seconds. 4. Set the jumper to "Pin 1-2 Close". 5. Power on the AC. 6. Reset your desired password or clear the CMOS data. (7) Front USB Headers: JUSB1/JUSB2 (7) Front USB Headers: JUSB1/JUSB2 (7) Front USB Headers: JUSB1/JUSB2...
  • Page 20 (10) Wake On LAN Header: JWOL1 (10) Wake On LAN Header: JWOL1 (10) Wake On LAN Header: JWOL1 (10) Wake On LAN Header: JWOL1 (10) Wake On LAN Header: JWOL1 This connector allows you to connect to a LAN card with Wake On LAN function. You can wake up the computer by remote control through a local area network.
  • Page 21 (9) Front Panel Connector: JPANEL1 (9) Front Panel Connector: JPANEL1 (9) Front Panel Connector: JPANEL1 (9) Front Panel Connector: JPANEL1 (9) Front Panel Connector: JPANEL1 The connector is for electrical connection to the front panel switches and LEDs. PWR_LED Pin Assignment Function 1 +5V Speaker...
  • Page 22 (11) Back Panel Connectors (11) Back Panel Connectors (11) Back Panel Connectors (11) Back Panel Connectors (11) Back Panel Connectors JAUDIO PS/2 Mouse Line In SPDIFO1 COM1 Speaker Out COM2 Mic In PS/2 IEEE 1394 Keyboard...

  • Page 24: Overview

    3.1 Overview 3.1 Overview 3.1 Overview 3.1 Overview 3.1 Overview Your computer offers the following connectors for peripheral device. Your computer offers the following connectors for peripheral device. Your computer offers the following connectors for peripheral device. Your computer offers the following connectors for peripheral device. Your computer offers the following connectors for peripheral device.

  • Page 25: Connecting Peripheral Devices

    3.2 Connecting Peripheral Devices 3.2 Connecting Peripheral Devices 3.2 Connecting Peripheral Devices 3.2 Connecting Peripheral Devices 3.2 Connecting Peripheral Devices Before you connect any peripherals, observe the following instructions. Before you connect any peripherals, observe the following instructions. Before you connect any peripherals, observe the following instructions. Before you connect any peripherals, observe the following instructions.

  • Page 26: Connecting Mouse And Keyboard

    Connecting monitor To connect a monitor, plug the monitor cable into the blue VGA port located on the rear panel of your computer. Connecting mouse and keyboard Most of mouse and keyboard are PS/2 compliant. However, lots of the latest keyboard and mouse use the USB connectors instead of PS/2.

  • Page 27: Connecting Usb Devices

    Connecting USB Devices Your computer is equipped with four standard USB 2.0 ports as the figure 3.5 shown. The USB 2.0 connector is backward compatible with the USB1.1. You can obtain USB-compatible devices such as USB mouse, USB keyboard, digital camera, scanner, flash disk...etc. Any device that supports this standard can be connected to this port.

  • Page 28: Connecting Audio Equipment

    Connecting IEEE1394 Devices Your computer is equipped with two IEEE1394 connectors as the figure 3.6 shown, which enhance the connectivity of the computer and allow users to connect more electronics devices such as desktop digital cameras, digital VCRs, high resolution color printers, scanners, set-top boxes, and more. The IEEE 1394 devices also support "hot plugging,"...

  • Page 29: Connecting Printer

    * "Headphone" jack: Use this jack to connect stereo headphone or amplified speakers to your computer. * "Microphone" jack: Use this jack to connect microphone. * "Line-in" jack: Use this jack to enjoy stereo audio from the external source such as CD/Tape player and other audio appliance.

  • Page 30: Connecting Lan

    Connecting LAN You can connect your computer with another computer system or get on broadband Internet connection by using the LAN port. Connect your LCD PC to a network as follows: * The LAN jack is located on the back of your LCD-PC. * Plug an RJ-45 network cable in the LAN jack.

  • Page 32: Installing Drivers And Utilities

    4.1 Installing Drivers and Utilities 4.1 Installing Drivers and Utilities 4.1 Installing Drivers and Utilities 4.1 Installing Drivers and Utilities 4.1 Installing Drivers and Utilities Driver Setup We provide an installation wizard, Driver CD Installation Utility (SETUP.EXE), located in the root of Driver CD to let users install some common used drivers conveniently.

  • Page 33: Installing Utilities

    8. Follow the installing instructions to finish the installation. 9. Click on the next driver you want to install. 10. Repeat steps 6 to 8 until you have installed all the drivers the utility has for you. * If the Driver and utility installation CD does not auto run, please follow the next steps after you place the CD into the optical drive.

  • Page 36: System Does Not Start

    5.1 System Does Not Start 5.1 System Does Not Start 5.1 System Does Not Start 5.1 System Does Not Start 5.1 System Does Not Start * No LEDs light and no sound can be heard from the computer: * Make sure the power cable is plugged in securely. Inspect the cables to make sure there is no visible damage.

  • Page 37: Keyboard And Mouse Problems

    5.2 Keyboard and Mouse Problems 5.2 Keyboard and Mouse Problems 5.2 Keyboard and Mouse Problems 5.2 Keyboard and Mouse Problems 5.2 Keyboard and Mouse Problems * Keyboard doesn't take input, but mouse pointer moves when mouse is moved: * Make sure the keyboard, mouse or receiver is connected when you start the computer. * If you inadvertently start the system with the keyboard disconnected, shut down the system by pressing and holding the power button on the system unit for at least four seconds.

  • Page 38: Usb Devices Problems

    5.3 USB Device Problems 5.3 USB Device Problems 5.3 USB Device Problems 5.3 USB Device Problems 5.3 USB Device Problems * Plug in any USB device but the display shows up as an unknown device in the Device Manager * Install the driver for your USB device. * Then plug in your USB device.

  • Page 39: Software Problems

    5.4 Software Problem 5.4 Software Problem 5.4 Software Problem 5.4 Software Problem 5.4 Software Problem Good software is tested thoroughly before you receive it. However, software Good software is tested thoroughly before you receive it. However, software Good software is tested thoroughly before you receive it. However, software Good software is tested thoroughly before you receive it.

  • Page 42: General Maintenance

    6.1 General Maintenance 6.1 General Maintenance 6.1 General Maintenance 6.1 General Maintenance 6.1 General Maintenance Before you install any computer component, we recommend that you read the following instructions. * Electrostatic discharge can damage the components of your computer. Do not remove a component from its protective packaging until you are ready to install it.

  • Page 43: Safe Use Of The System

    6.2 Safe Use of The System 6.2 Safe Use of The System 6.2 Safe Use of The System 6.2 Safe Use of The System 6.2 Safe Use of The System To ensure that you can use your computer safety and cor- rectly and increase the working lifetime of your computer, please read the following instructions.

  • Page 46: Installing Motherboard

    Appendix Appendix Appendix Appendix Appendix Installing Mainboard Installing Mainboard Installing Mainboard Installing Mainboard Installing Mainboard Before installing mainboard, users have to remove the two-side and top Before installing mainboard, users have to remove the two-side and top Before installing mainboard, users have to remove the two-side and top Before installing mainboard, users have to remove the two-side and top Before installing mainboard, users have to remove the two-side and top panels.

  • Page 47: Installing Mainboard

    * Then use the screwdriver to remove the two screws on the top of front cover panel. Installing Mainboard * Insert the mainboard into the base of the chassis and place it close to the back panel. * After fixing the mainboard on the base of the chassis, you will find there are six mounting hole of screws both on the computer chassis and the mainboard.
  • Page 48 * Connect the cable of LEDs indicator and front panel switches to "JPANEL1" connector on the Mainbord. * Connect the cable of system fan to "JSFAN1" connector on the mainboard. * Connect the cable to the floppy, CD-ROM and HDD. * Place the CD-ROM bracket and and fix it with 2 screws.
  • Page 49 * Place HDD bracket. * Fix it with one screw. * Place the front panel back and fix it with four screws to complete the installation of mainboard. * Note: The figures show the locations of the connectors on P4SBA motherboard. Please refer to section 2, the Motherboard layout of K8NBP for the correct locations of the connectors.
