User Manual - ProVideo GUI v1.2.4

Table of Contents

1 Overview.........................................................................................................................................2
2 Connecting with a Device...............................................................................................................3
3 General navigation...........................................................................................................................5
3.1 Toolbar.....................................................................................................................................5
3.2 Sidebar.....................................................................................................................................6
3.3 System Settings Dialog............................................................................................................7
3.4 Debug Terminal.......................................................................................................................9
4 The Tabs.........................................................................................................................................11
4.1 In-Out Tab..............................................................................................................................11
4.2 Lens Driver Tab.....................................................................................................................15
4.3 Playback Tab..........................................................................................................................17
4.4 Black Level Tab.....................................................................................................................20
4.5 White Balance Tab.................................................................................................................21
4.6 Filter Tab................................................................................................................................22
4.7 Multi Color Controller Tab....................................................................................................23
4.8 Knee Function Tab.................................................................................................................24
4.9 Lookup Table Tab..................................................................................................................25
SSM500)........................................................................................................................................30
4.12 Output Tab...........................................................................................................................31
4.13 Info Tab................................................................................................................................33
4.14 Update Tab...........................................................................................................................35
